Page 3433 of 5135
760WD±01
B67161
Clip
B67162
Clip
B67163
Double±sided Tape
76±30
± EXTERIOR/INTERIOR TRIMREAR SPOILER (WAGON MODELS)
AVENSIS REPAIR MANUAL (RM1018E)
REAR SPOILER (WAGON MODELS)
REPLACEMENT
HINT:
The installation is in the reverse order of the removal.
1. REMOVE BACK DOOR TRIM PANEL ASSY UPPER
(a) Remove the 4 clips and door trim panel.
(b) Remove the 4 hole plugs.
2. REMOVE REAR SPOILER
(a) Disconnect the stop lamp connector.
(b) Remove the 6 nuts and clip.
(c) Using a heat light, heat the spoiler.
Heating temprature: 40 ± 60C (104 ± 140F)
NOTICE:
Do not heat the spoiler excessively.
(d) Lightly lift the spoiler at the right end or the left end.
(e) Cut the tape.
(1) Tie both piano wire ends to a wooden block or simi-
lar object.
(2) Cut the tape by pulling the piano wire.
NOTICE:
If reusing the rear spoiler, take care not to damage it.
Be careful not to damage the back door.
(f) Remove the spoiler.
3. INSTALL REAR SPOILER
(a) Clean the surface on the back door where the spoiler is
to be attached.
(1) Using a heat light, heat the back door contact sur-
face.
Heating temprature: 40 ± 60C (104 ± 140F)
NOTICE:
Do not heat the back door excessively.
Page 3434 of 5135
B67164
Double±sided Tape
± EXTERIOR/INTERIOR TRIMREAR SPOILER (WAGON MODELS)
76±31
AVENSIS REPAIR MANUAL (RM1018E)
(2) Remove the tape from the back door.
(3) Wipe off the stains with cleaner.
(b) When reusing the spoiler:
Clean the spoiler.
(1) Using a heat light, heat the spoiler.
Heating temprature: 20 ± 30C (68 ± 86F)
NOTICE:
Do not heat the spoiler excessively.
(2) Remove the tape from the spoiler.
(3) Wipe off the stains with cleaner.
(c) Install the spoiler.
(1) Using a heat light, heat the door and spoiler.
Heating temperature:
Door40 ± 60C (104 ± 140F)
Spoiler20 ± 30C (68 ± 86F)
NOTICE:
Do not heat the door and spoiler excessively.
(2) Apply new double±sided tape to the spoiler, as
shown in the illustration.
(3) Remove the peeling paper from the spoiler.
NOTICE:
Be careful that dirt or foreign objects do not stick to the
adhesive part when removing the peeling paper.
(4) Install the spoiler with the 6 nuts.
Torque: 9.8 Nm (99 kgfcm, 87 in.lbf)
NOTICE:
Do not apply excessive force onto the spoiler. Instead, ap-
ply steady pressure with your thumbs.
(5) Connect the stop lamp connector.
(6) Install the 4 hole plugs.
Page 3435 of 5135
760WB±01
B67627
ClipNut
±
EXTERIOR/INTERIOR TRIM BACK DOOR GARNISH SUB±ASSY
OUTSIDE(WAGON MODELS)76±29
AVENSIS REPAIR MANUAL (RM1018E)
BACK DOOR GARNISH SUB±ASSY OUTSIDE(WAGON
MODELS)
REPLACEMENT
HINT:
The installation is in the reverse order of the removal. However, when there is a special point concerning
the installation, it is indicated.
1.REMOVE BACK DOOR TRIM PANEL ASSY UPPER (See page 75±45)
2.REMOVE BACK DOOR SIDE GARNISH LH (See page 75±45)
3.REMOVE BACK DOOR SIDE GARNISH RH (See page 75±45)
4.REMOVE BACK DOOR TRIM BOARD ASSY (See page 75±45)
5.REMOVE DOOR PULL HANDLE (See page 75±45)
6. REMOVE BACK DOOR GARNISH SUB±ASSY OUTSIDE
(a) Remove the 5 nuts, clip and back door garnish.
7. INSTALL BACK DOOR GARNISH SUB±ASSY OUTSIDE
(a) Install the garnish with the 5 nuts and clip.
Torque: 4.9 N m (50 kgf cm, 43 in. lbf)
Page 3436 of 5135
760WA±01
B67627
ClipNut
76±28±
EXTERIOR/INTERIOR TRIM BACK DOOR GARNISH SUB±ASSY
OUTSIDE(LIFTBACK MODELS)
AVENSIS REPAIR MANUAL (RM1018E)
BACK DOOR GARNISH SUB±ASSY OUTSIDE(LIFTBACK
MODELS)
REPLACEMENT
HINT:
The installation is in the reverse order of the removal. However, when there is a special point concerning
the installation, it is indicated.
1.REMOVE BACK DOOR TRIM PANEL ASSY UPPER (See page 75±40)
2.REMOVE BACK DOOR SIDE GARNISH LH (See page 75±40)
3.REMOVE BACK DOOR SIDE GARNISH RH (See page 75±40)
4.REMOVE BACK DOOR SIDE GARNISH CLIP (See page 75±40)
5.REMOVE BACK DOOR TRIM BOARD ASSY (See page 75±40)
6.REMOVE BACK DOOR GARNISH SUB±ASSY OUTSIDE (See page 75±40)
(a) Remove the 5 nuts, clip and garnish.
7. INSTALL BACK DOOR GARNISH SUB±ASSY OUTSIDE
(a) Install the garnish with the 5 nuts and clip. Torque: 4.9 N m (50 kgf cm, 43 in. lbf)
Page 3437 of 5135
760W9±01
B67626
NutClip
±
EXTERIOR/INTERIOR TRIM LUGGAGE COMPARTMENT DOOR GARNISH
SUB±ASSY OUTSIDE(SEDAN MODELS)76±27
AVENSIS REPAIR MANUAL (RM1018E)
LUGGAGE COMPARTMENT DOOR GARNISH SUB±ASSY
OUTSIDE(SEDAN MODELS)
REPLACEMENT
HINT:
The installation is in the reverse order of the removal. However, when there is a special point concerning
the installation, it is indicated.
1.REMOVE BACK DOOR TRIM COVER (See page 75±32)
2. REMOVE LUGGAGE COMPARTMENT DOOR GARNISH SUB±ASSY OUTSIDE
(a) Remove the 6 nuts, clip and garnish.
3. INSTALL BACK DOOR GARNISH SUB±ASSY OUTSIDE
(a) Install the garnish with the 6 nuts and clip.
Torque: 4.9 N m (50 kgf cm, 43 in. lbf)
Page 3438 of 5135
760WE±01
B67742
B67741
Front Side
Rear Side 1.3 (0.051)
mm (in.) A
A A ± A
4.8 (0.189)
1.5 (0.059)
A ± AA
A
4.6 (1.811)
76±26
± EXTERIOR/INTERIOR TRIMROOF DRIP SIDE FINISH MOULDING CENTER LH
AVENSIS REPAIR MANUAL (RM1018E)
ROOF DRIP SIDE FINISH MOULDING CENTER LH
REPLACEMENT
HINT:
Use the same procedures on the RH side as on the LH side.
1. REMOVE ROOF DRIP SIDE FINISH MOULDING
CENTER LH
(a) Put the protective tape around the circumference of the
moulding.
(b) Using a remover for the roof moulding, release the disen-
gage the clips both in the front and rear ends of the mould-
ing, and then remove the moulding.
NOTICE:
Do not remove the clips.
If that the clips are damaged or removed accidentally,
exchange them for supplied ones.
2. INSTALL ROOF DRIP SIDE FINISH MOULDING
CENTER LH
NOTICE:
Only when exchanging the clips.
(a) Remove the tape that remains on the mounting surface
of the body, and then clean the surface with white gaso-
line.
(b) Using a heat light, heat up the clip installation surfaces of
the body and moulding.
Heating temperature:
Body40 ± 60C (104 ± 140F)
Moulding20 ± 30C (68 ± 86F)
NOTICE:
Do not heat the moulding and body excessively.
(c) Set the supplied clips in the positions as shown in the il-
lustration and press±fit them by hand to install them.
NOTICE:
Install the moulding when 30 minutes or more have passed
after press±fitting the clips.
HINT:
Initial hardening time: 30 minutes
Perfect hardening time: 24 hours
Page 3439 of 5135
760W8±01
B67156
B67157
B67155
Clip
Clip
Clip
± EXTERIOR/INTERIOR TRIMROCKER PANEL MOULDING LH
76±25
AVENSIS REPAIR MANUAL (RM1018E)
ROCKER PANEL MOULDING LH
REPLACEMENT
HINT:
The installation is in the reverse order of the removal.
Use the same procedures on the RH side as on the LH side.
1. REMOVE FRONT WHEEL
2. REMOVE REAR WHEEL
3. REMOVE SIDE MUDGUARD FRONT LH
(a) Remove the 2 screws and mudguard.
(b) Remove the 2 screws and wheel house plate.
4. REMOVE REAR WHEEL HOUSE PLATE FRONT LH
(a) Remove the 2 screws and wheel house plate.
5. REMOVE ROCKER PANEL MOULDING LH
(a) Remove the 3 screws, 12 clips and moulding.
Page 3440 of 5135
760W7±01
B67608
Tape
Tape
76±24
±
EXTERIOR/INTERIOR TRIM REAR DOOR BELT MOULDING ASSY LH
AVENSIS REPAIR MANUAL (RM1018E)
REAR DOOR BELT MOULDING ASSY LH
REPLACEMENT
HINT:
The installation is in the reverse order of the removal.
On the RH side, use the same procedures as on the LH side.
1.REMOVE REAR DOOR WINDOW REGULATOR HANDLE ASSY (See page 75±22)
2.REMOVE REAR DOOR TRIM BASE LH (See page 75±22)
3. REMOVE POWER WINDOW REGULATOR SWITCH ASSY REAR (W/ POWER WINDOW) (See page 75±22)
4.REMOVE REAR DOOR TRIM BOARD SUB±ASSY LH (See page 75±22)
5.REMOVE REAR DOOR GLASS WEATHERSTRIP INNER LH (See page 75±22)
6.REMOVE REAR DOOR SERVICE HOLE COVER LH (See page 75±22)
7. REMOVE REAR DOOR BELT MOULDING ASSY LH
(a) Put protective tape under the moulding.
(b) Using a screwdriver or moulding remover, pry out theclaws and remove the moulding.
HINT:
Tape the screwdriver tip before use.
