− DIAGNOSTICSELECTRONIC CONTROLLED AUTOMATIC
TRANSAXLE [ECT] (U151E)05−537
AVENSIS Supplement (RM1045E)
(b) Measure the time lag.
(1) When the shift lever is shifted while the engine is idling, there will be a certain time lapse or lag
before the shock can be felt. This is used for checking the condition of the direct clutch, forward
clutch, and1st and reverse brake.
NOTICE:
SPerform the test at the normal operating ATF temperature 50 to 80˚C(122 to176˚F).
SBe sure to allow1minute interval between tests.
SPerform the test three times, and measure the time lags. Calculate the average value of the three
time lags.
(2) Connect an hand−held tester to the DLC3.
(3) Fully apply the parking brake.
(4) Start and warm up the engine and check idle speed.
Idle speed: approx. 700 rpm (In N position and A/C OFF)
(5) Shift the lever from N to D position. Using a stop watch, measure the time from when the lever
is shifted until the shock is felt.
Time lag: ND less than1.2 seconds
(6) In the same way, measure the time lag for NR.
Time lag: NR less than1.5 seconds
Evaluation (If NDorNR time lag is longer than the specified):
ProblemPossible cause
ND time lag is longer
SLine pressure is too low
SForward clutch worn
SNo.1one−way clutch not operating properly
SU/D (Underdrive) one−way clutch not operating
SU/D (Underdrive) brake worn
NR time lag is longer
SLine pressure is too low
SReverse clutch worn
S1st and reverse brake worn
SU/D (Underdrive) brake worn
