Page 4769 of 5135
−
AUTOMATIC TRANSMISSION / TRANS TRANSMISSION OIL COOLER (U151E)
40−27
AVENSIS Supplement (RM1045E)
5. ADD COOLANT (SEE PAGE 16− 7)
6. ADD AUTOMATIC TRANSAXLE FLUID (SEE PUB. NO. RM 1018E, PAGE 40 −2)
7. INSPECT AUTOMATIC TRANSAXLE FLUID (SEE PUB. NO. RM 1018E, PAGE 40 −2)
Page 4770 of 5135
40189−01
D25831
SST
D25832
SST
D25833
SST
40 −24
−
AUTOMATIC TRANSMISSION / TRANS FRONT DIFFERENTIAL OIL SEAL (U151E)
AVENSIS Supplement (RM1045E)
FRONT DIFFERENTIAL OIL SEAL (U 151E)
REPLACEMENT
1. REMOVE FRONT WHEELS
2. REMOVE ENGINE UNDER COVER RH
3. REMOVE ENGINE UNDER COVER LH
4. DRAIN AUTOMATIC TRANSAXLE FLUID
(a) Remove the drain plug and gasket, and drain ATF.
(b) Install a new gasket and the drain plug. Torque: 47 N m (480 kgf cm, 35 ft lbf)
5. REMOVE FRONT DRIVE SHAFT ASSY RH (SEE PAGE 30 −4)
6. REMOVE FRONT DRIVE SHAFT ASSY LH (SEE PAGE 30 −4)
7. REMOVE TRANSAXLE HOUSING OIL SEAL
(a) Using SST, pull out the oil seal. SST 09308 −00010
8. REMOVE DIFFERENTIAL SIDE BEARING RETAINER OIL SEAL
(a) Using SST, pull out the oil seal.
SST 09308 −00010
9. INSTALL TRANSAXLE HOUSING OIL SEAL
(a) Using SST and a hammer, drive in a new oil seal. SST 09316 −60011 (09316 −00011)
Oil seal drive in depth:
0 á 0.5 mm (0 á0.020 in.)
(b) Coat the lip of the oil seal with MP grease.
Page 4771 of 5135
D25834
SST
−
AUTOMATIC TRANSMISSION / TRANS FRONT DIFFERENTIAL OIL SEAL (U151E)
40−25
AVENSIS Supplement (RM1045E)
10. INSTALL DIFFERENTIAL SIDE BEARING RETAINER
OIL SEAL
(a) Using SST and a hammer, drive in a new oil seal. SST 09649 −17010, 09950 −70010 (09951 −07150)
Oil seal drive in depth:
0 á 0.5 mm (0 á 0.020 in.)
(b) Coat the lip of the oil seal with MP grease.
11 . INSTALL FRONT DRIVE SHAFT ASSY LH (SEE PAGE 30 −4)
1 2. INSTALL FRONT DRIVE SHAFT ASSY RH (SEE PAGE 30 −4)
1 3. INSTALL FRONT WHEELS
Torque: 103 N m( 1,050 kgf cm, 76 ft lbf)
1 4. ADD AUTOMATIC TRANSAXLE FLUID (SEE PUB. NO. RM 1018E, PAGE40 −2)
1 5. INSPECT AUTOMATIC TRANSAXLE FLUID (SEE PUB. NO. RM 1018E, PAGE40 −2)
1 6. CHECK ABS SPEED SENSOR SIGNAL
(a) ABS WITH EBD & BA &TRAC & VSC SYSTEM (SEE PUB, NO. RM1018E, PAGE 5 −756)
Page 4772 of 5135
40188−01
C91925
D30865
AT0103
C91927
− AUTOMATIC TRANSMISSION / TRANSTRANSMISSION VALVE BODY ASSY (U151E)
40−19
AVENSIS Supplement (RM1045E)
TRANSMISSION VALVE BODY ASSY (U151E)
REPLACEMENT
1. REMOVE ENGINE UNDER COVER LH
2. DRAIN AUTOMATIC TRANSAXLE FLUID
(a) Remove the drain plug and gasket, and drain ATF.
(b) Install a new gasket and the drain plug.
Torque: 47 Nm (479 kgfcm, 35 ftlbf)
3. REMOVE AUTOMATIC TRANSAXLE OIL PAN
SUB−ASSY
(a) Remove the 18 bolts, oil pan and gasket.
NOTICE:
Some fluid will remain in the oil pan. Remove all of the oil
pan bolts, and carefully remove the oil pan assembly.
(b) Remove the 2 magnets from the oil pan.
(c) Examine the particles in the oil pan.
(1) Collect any steel chips with the removed magnets.
Look at the chips and particles in the pan and on the
magnets carefully to see the type of wear which
might be found in the transaxle.
Steel (magnetic): bearing, gear and plate wear
Brass (non−magnetic): bearing wear
4. DISCONNECT TRANSMISSION WIRE
(a) Disconnect the 7 shift solenoid valve connectors.
(b) Remove the bolt and lock plate, and disconnect the ATF
temperature sensor.
Page 4773 of 5135
C91931
C91932
C91933
F46566
40−20
− AUTOMATIC TRANSMISSION / TRANSTRANSMISSION VALVE BODY ASSY (U151E)
AVENSIS Supplement (RM1045E)
5. REMOVE VALVE BODY OIL STRAINER ASSY
(a) Remove the 3 bolts and oil strainer.
NOTICE:
Be careful that some fluid will come out of the oil strainer.
(b) Remove the O−ring from the oil strainer.
6. REMOVE TRANSMISSION VALVE BODY ASSY
(a) Support the valve body assy and remove the 17 bolts and
the valve body assy.
NOTICE:
Be careful not to drop the check ball body, spring and accu-
mulator piston.
(b) Remove the check ball body and spring.
Page 4774 of 5135
D30644
F46566
D30644
AB
B
C
D
− AUTOMATIC TRANSMISSION / TRANSTRANSMISSION VALVE BODY ASSY (U151E)
40−21
AVENSIS Supplement (RM1045E)
(c) Remove the 5 bolts, 3 lock plates and 7 shift solenoid
valves.
7. INSTALL TRANSMISSION VALVE BODY ASSY
(a) Install the spring and check ball body.
(b) Install the 7 shift solenoid valves and 3 lock plates with
the 5 bolts.
Torque:
Bolts A, B:11N·m (110 kgf·cm, 8 ft.lbf)
Bolts C, D: 6.6 N·m (67 kgf·cm, 58 in. lbf)
Bolt length:
Bolt A:16 mm (0.63 in.)
Bolt B: 57 mm (2.24 in.)
Bolt C: 20 mm (0.79 in.)
Bolt D:12 mm (0.47 in.)
Page 4775 of 5135
C91933
A
B
CB
B
B
A
CCC
L
L
C
B
C91932
C91931
C91927
40−22
− AUTOMATIC TRANSMISSION / TRANSTRANSMISSION VALVE BODY ASSY (U151E)
AVENSIS Supplement (RM1045E)
(c) Align the groove of the manual valve with the pin of the
lever.
(d) Install the 17 bolts.
Torque:11Nm(110 kgfcm, 8 ftlbf)
NOTICE:
SPush the valve body against the accumulator piston
spring and the check ball body to install it.
SFirst, temporarily tighten those bolts marked byLin
the illustration because they are positioning bolts.
Bolt length:
Bolt A: 25 mm (0.984 in.)
Bolt B: 57 mm (2.244 in.)
Bolt C: 41mm (1.614 in.)
8. INSTALL VALVE BODY OIL STRAINER ASSY
(a) Coat a new O−ring with ATF.
(b) Install the O−ring to the oil strainer.
(c) Install the oil strainer with the 3 bolts.
Torque:11Nm(110 kgfcm, 8 ftlbf)
9. INSTALL TRANSMISSION WIRE
(a) Coat an O−ring with ATF.
(b) Install the ATF temperature sensor with the lock plate and
bolt.
Torque: 6.6 Nm (67 kgfcm, 58 in.lbf)
(c) Connect the 7 shift solenoid valve connectors.
Page 4776 of 5135
D30865
C91925
−
AUTOMATIC TRANSMISSION / TRANS TRANSMISSION VALVE BODY ASSY (U151E)
40−23
AVENSIS Supplement (RM1045E)
10. I NSTALL AUTO M AT I C TRANSAXLE O I L PAN
SUB −ASSY
(a) Install the 2 magnets to the oil pan.
(b) Apply seal packing to the 18 bolts. Seal packing:
THREE BOND 1344 or equivalent
(c) Install a new gasket, the oil pan and 18 bolts to the trans- axle case.
Torque: 7.8 N m (80 kgf cm, 69 in. lbf)
NOTICE:
Apply seal packing to the bolts and tighten them within 10
minutes of application.
11 . ADD AUTOMATIC TRANSAXLE FLUID (SEE PUB. NO. RM 1018E, PAGE 40 −2)
1 2. INSPECT AUTOMATIC TRANSAXLE FLUID (SEE PUB. NO. RM 1018E, PAGE 40 −2)
1 3. RESET MEMORY (SEE PAGE 05 −54 1)
