Page 4681 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 14−94− ENGINE MECHANICAL VALVE CLEARANCE (1CD−FTV)(From September, 2003) AVENSIS Supplement (RM1045E) (d) Using SST, tighten the nut of the injection pipe on the in- jector side. SST 09023 −1

Page 4682 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual A93405 2to7mm (0.0787 to 0.2756 in.)0to2mm (0 to 0.0787 in.) 5to13mm (0.1969 to 0.5118 in.) Turbocharger Side: Air Hose No. 2 Side: A87967 Upward 90_ Clamp Bolt Turbocharger Side: Air Hose No. 2 Side:

Page 4683 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual A57526 Adjusting Shim Selection Chart (Intake) New Shim Thickness mm (in.) Shim No.Thickness 01Shim No.Thickness 03 05 07 09 11 13 1519 21 23 25 27 2.500(0.0984) 2.550 (0.1004) 2.600 (0.1024) 2.650 (0

Page 4684 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual A57527 Adjusting Shim Selection Chart (Exhaust) New Shim Thickness mm (in.) Shim No.Thickness 01Shim No.Thickness 03 05 07 09 11 13 1519 21 23 25 27 2.500(0.0984) 2.550 (0.1004) 2.600 (0.1024) 2.650 (

Page 4685 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 141ND−01 A57063 Measure Point for Belt Deflection and Tension Alternator Crankshaft Compressor P/SP/S Alternator Crankshaft A/C Equipped A/C Not Equipped − ENGINE MECHANICAL ENGINE (1CD−FTV)(Fro

Page 4686 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual A61173 B A TA C A52006 A09593 SST (Attachment) 14−88 − ENGINE MECHANICALENGINE (1CD−FTV)(From September, 2003) AVENSIS Supplement (RM1045E) (b) Inspect the generator V−ribbed belt. (1) Check t

Page 4687 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual A61174 SST Compression Gauge − ENGINE MECHANICALENGINE (1CD−FTV)(From September, 2003) 14−89 AVENSIS Supplement (RM1045E) (2) Connect SST (a compression gauge) to SST (the attachment). SST 09992

Page 4688 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 141BS−02 A77421 Cut Position A77422SST 14 −86 − ENGINE MECHANICAL ENGINE REAR OIL SEAL (2AZ −FSE) AVENSIS Supplement (RM1045E) ENGINE REAR OIL SEAL (2AZ −FSE) REPLACEMENT 1. REMOVE AUTOMATI
