Page 4361 of 5135
A66060
E13
E2 ( −)
THA (+)
ECM Connector
A66060
E 13
E2 ( −)
PCR
1 (+)
ECM Connector
PCR2 (+)
−
DIAGNOSTICS ECD SYSTEM (1CD −FTV)(From September, 2003)
05 −519
AVENSIS Supplement (RM 1045E)
15 INSPECT ECM(THA VOLTAGE)
(a) Start the engine.
(b) Measure the voltage between the specified terminals of
the E13 ECM connector.
Standard:
Tester ConnectionConditionSpecified Condition
THA (E 13− 31) −
E2 (E 13− 28)Idling, intake air tempera-
ture at 20 ˚ C (68 ˚ F)0.5 to 3.4 V
NG Go to step 2 1
OK
1 6 INSPECT ECM(PCR 1 AND PCR2 VOLTAGE)
(a) Start the engine.
(b) Measure the voltage between the specified terminals of
the E13 ECM connector.
Standard:
Tester ConnectionConditionSpecified Condition
PCR 1 (E 13− 26) −
E2 (E 13− 28)Idling1.8 to 2. 1 V
PCR2 (E 13− 33) −
E2 (E 13− 28)Idling1.2 to 1.5 V
NG Go to step 22
OK
REPLACE ECM (See page 10− 29)
Page 4362 of 5135
S01196S01699
30
20
10
5
3
02040 0.1 1
0.3
0.2 0.52
60 80100 −20
(−4) (104) (140) (176) (32) (68) (212)
A81700
Ohmmeter
Acceptable
Temperature_C(_F)
Resistance K
A56992
E2
PIM
VC T5
Wire Harness Side:
Manifold Absolute
Pressure Sensor Connector
Front View
A81088
PIM
VC
E2E12ECM Connector E13
05−520
− DIAGNOSTICSECD SYSTEM (1CD−FTV)(From September, 2003)
AVENSIS Supplement (RM1045E)
17 INSPECT ENGINE COOLANT TEMPERATURE SENSOR
(a) Remove the engine coolant temperature sensor.
(b) Measure the resistance between the terminals.
Standard:
2.32 to 2.59 kat 20_C (68_F)
0.310 to 0.326 kat 80_C(176_F)
NOTICE:
If you check the engine coolant temperature sensor in wa-
ter, be careful not to allow water to contact the terminals.
After checking, dry the sensor.
HINT:
Alternate procedure: Connect an ohmmeter to the installed en-
gine coolant temperature sensor and read the resistance. Use
an infrared thermometer to measure the engine temperature in
the immediate vicinity of the sensor. Compare these values to
the resistance/temperature graph. Change the engine temper-
ature (warm up or allow to cool down) and repeat the test.
(c) Reinstall the engine coolant temperature sensor.
NG REPLACE ENGINE COOLANT TEMPERATURE
SENSOR
OK
REPAIR OR REPLACE HARNESS OR CONNECTOR
18 CHECK HARNESS AND CONNECTOR(MANIFOLD ABSOLUTE PRESSURE
SENSOR−ECM)
(a) Disconnect the T5 manifold absolute pressure sensor
connector.
(b) Disconnect the E13 and E12 ECM connectors.
(c) Check the resistance between the wire harness side con-
nectors.
Standard (Check for open):
Tester ConnectionSpecified Condition
PIM (T5−2)−PIM (E12−28)
VC (T5−3)−VC (E13−18)Below1
E2 (T5−1)−E2 (E13−28)
Standard (Check for short):
Tester ConnectionSpecified Condition
PIM (T5−2) or PIM (E12−28)−Body ground
VC (T5−3) or VC (E13−18)−Body ground10kor higher
E2 (T5−1)orE2(E13−28)−Body ground
g
(d) Reconnect the manifold absolute pressure sensor con-
nector.
(e) Reconnect the ECM connectors.
Page 4363 of 5135
A78431
Crankshaft Position Sensor Component Side:
C4
− DIAGNOSTICSECD SYSTEM (1CD−FTV)(From September, 2003)
05−521
AVENSIS Supplement (RM1045E)
NG REPAIR OR REPLACE HARNESS OR
CONNECTOR
OK
REPLACE MANIFOLD ABSOLUTE PRESSURE SENSOR
19 INSPECT CRANKSHAFT POSITION SENSOR
(a) Disconnect the C4 crankshaft position sensor connector.
(b) Measure the resistance between terminals1and 2.
Standard:
Tester ConnectionSpecified Condition
121,630 to 2,740at cold1−22,065 to 3,225at hot
NOTICE:
”Cold” and ”Hot” shown above mean the temperature of
the coils themselves. ”Cold” is from−10_C(14_F) to 50_C
(122_F) and ”Hot” is from 50_C(122_F) to100_C(212_F).
(c) Reconnect the crankshaft position sensor connector.
NG REPLACE CRANKSHAFT POSITION SENSOR
OK
REPAIR OR REPLACE HARNESS OR CONNECTOR
Page 4364 of 5135
A84847
EP1EP2VPA2
VCP1
VPA1VCP2 A20
Wire Harness Side (RHD):
Front View Accelerator Pedal Position Sensor
Connector
A84847
EP1
EP2VPA2
VCP1
VPA1 VCP2 A20 Accelerator Pedal Position Sensor
Connector
Wire Harness Side (LHD):
Front View
A81091
E9
ECM ConnectorVPA
VCPA
VPA2
EPA2
VCP2EPA
05−522
− DIAGNOSTICSECD SYSTEM (1CD−FTV)(From September, 2003)
AVENSIS Supplement (RM1045E)
20 CHECK HARNESS AND CONNECTOR(ACCELERATOR PEDAL POSITION
SENSOR−ECM)
(a) Disconnect the A20 accelerator pedal position sensor
connector.
(b) Disconnect E9 the ECM connector.
(c) Check the resistance between the wire harness side con-
nectors.
Standard (Check for open) (RHD):
Tester ConnectionSpecified Condition
VPA1(A20−5)−VPA (E9−22)
EP1(A20−1)−EPA (E9−28)
VCP1(A20−4)−VCPA (E9−26)Below1VPA2 (A20−2)−VPA2 (E9−23)Below1
EP2 (A20−3)−EPA2 (E9−29)
VCP2 (A20−6)−VCP2 (E9−27)
Standard (Check for open) (LHD):
Tester ConnectionSpecified Condition
VPA1(A20−5)−VPA (E9−22)
EP1(A20−3)−EPA (E9−28)
VCP1(A20−6)−VCPA (E9−26)Below1VPA2 (A20−2)−VPA2 (E9−23)Below1
EP2 (A20−1)−EPA2 (E9−29)
VCP2 (A20−4)−VCP2 (E9−27)
Standard (Check for short) (RHD):
Tester ConnectionSpecified Condition
VPA1(A20−5) or VPA (E9−22)−Body ground
EP1(A20−1) or EPA (E9−28)−Body ground
VCP1(A20−4) or VCPA (E9−26)−Body ground10korhigherVPA2 (A20−2) or VPA2 (E9−23)−Body ground10kor higher
EP2 (A20−3) or EPA2 (E9−29)−Body ground
VCP2 (A20−6) or VCP2 (E9−27)−Body ground
Standard (Check for short) (LHD):
Tester ConnectionSpecified Condition
VPA1(A20−5) or VPA (E9−22)−Body ground
EP1(A20−3) or EPA (E9−28)−Body ground
VCP1(A20−6) or VCPA (E9−26)−Body ground10korhigherVPA2 (A20−2) or VPA2 (E9−23)−Body ground10kor higher
EP2 (A20−1) or EPA2 (E9−29)−Body ground
VCP2 (A20−4) or VCP2 (E9−27)−Body ground
(d) Reconnect the accelerator pedal position sensor connec-
tor.
(e) Reconnect the ECM connector.
NG REPAIR OR REPLACE HARNESS OR
CONNECTOR
OK
REPLACE ACCELERATOR PEDAL ASSY (ACCELERATOR PEDAL POSITION SENSOR)
(See page10−66 of Pub. No. RM1018E AVENSIS REPAIR MANUAL)
Page 4365 of 5135
30
20
1 0
5
3
2
1
0.5
0.3
0.2
0. 1
−20 0
20 40 60
80 100
F 1474 1(− 4) ( 104) ( 140) ( 176)
(32) (68) (2 12)
30
20
1 0
0.5
0.3
0.2
0. 1
−20
20 40 60
80 100
F 1474 1(− 4) ( 104) ( 140) ( 176)
(32) (68) (2 12)
A56276
Temperature _ C( _ F)
Resistance k
Acceptable
A79038
E2S PCR2 VC2
VC PC E2
Fuel Pressure Sensor
Component Side:
F16
−
DIAGNOSTICS ECD SYSTEM (1CD −FTV)(From September, 2003)
05 −523
AVENSIS Supplement (RM 1045E)
21 INSPECT DIESEL TURBO INLET AIR TENPERATURE SENSOR
(a) Remove the diesel turbo inlet air temperature sensor.
(b) Measure the resistance between the terminals.
Standard:
2.21 to 2.65 k at 20 _C (68 _F)
(c) Reinstall the diesel turbo inlet air temperature sensor.
NG REPLACE DIESEL TURBO INLET AIR TENPERATURE SENSOR
OK
REPAIR OR REPLACE HARNESS OR CONNECTOR
22 INSPECT COMMON RAIL ASSY(FUEL PRESSURE SENSOR)
(a) Disconnect the F 16 fuel pressure sensor connector.
(b) Measure the resistance between each terminal of the fuel
pressure sensor connector.
Standard:
Tester ConnectionSpecified Condition
PC (F 16− 5) − E2 (F 16− 4)16.4 k or less
PCR2 (F 16− 2) − E2S (F 16− 3)16.4 k or less
PC (F 16− 5) − VC (F 16− 6)3k or less
PCR2 (F 16− 2) − VC2 (F 16−1 )3k or less
(c) Reconnect the fuel pressure sensor connector.
NG REPLACE COMMON RAIL ASSY (FUEL PRES- SURE SENSOR) (See page 11− 67)
OK
Page 4366 of 5135
A80452
PCR1E
13
ECM Connector
E
12PCR2
E2VCS
E2S
VC
A80453
E2
PCR2
F
16
Wire Harness Side:
Fuel Pressure Sensor Connector
VC2
PCE2S
VC
Front View
05 −524
−
DIAGNOSTICS ECD SYSTEM (1CD −FTV)(From September, 2003)
AVENSIS Supplement (RM 1045E)
23 CHECK HARNESS AND CONNECTOR(FUEL PRESSURE SENSOR − ECM)
(a) Disconnect the F 16 fuel pressure sensor connector.
(b) Disconnect the E 12 and E 13 ECM connectors.
(c) Check the resistance between the wire harness side con-
nectors.
Standard (Check for open):
Tester ConnectionSpecified Condition
PCR1 (E 13− 26) − PC (F 16− 5)
PCR2 (E 13− 33) − PCR2 (F 16− 2)
VCS (E 12− 2) − VC2 (F 16−1 )Below1VC (E 13−1 8)− VC (F 16− 6)Below 1
E2 (E 13− 28) − E2 (F 16− 4)
E2S (E 12−1 )− E2S (F 16− 3)
Standard (Check for short):
Tester ConnectionSpecified Condition
PCR 1 (E 13− 26) or PC (F 16− 5) − Body ground
PCR2 (E 13− 33) or PCR2 (F 16 − 2) − Body ground
VCS (E 12− 2) or VC2 (F 16 −1 )− Body ground10 k or higherVC (E 13−1 8) or VC (F 16− 6) − Body ground10k or higher
E2 (E 13− 28) or E2 (F 16− 4) − Body ground
E2S (E 12−1 ) or E2S (F 16− 3) − Body ground
(d) Reconnect the fuel pressure sensor connector.
(e) Reconnect the ECM connectors.
NG REPAIR OR REPLACE HARNESS OR CONNECTOR
OK
24 REPLACE ECM (See page 10− 29)
NG REPLACE INJECTION OR SUPPLY PUMP ASSY
(See page 11− 58)
OK
END
Page 4367 of 5135
A81015
Engine
Room
R/B No. 1W
9ECM
W
E912
1 2
B
B−W22 1
3
Battery4
2 DH 6
B−R B−R
C11
Combination
Meter Assy
Check
Engine
Warning
Light AM2
IG2
AM2
Driver
Side
J/B
FL MAINEngine
Room
R/B
No. 3
3B 1A 1B−R
IE41
(LHD)IP11
(RHD)
18 DA
J8C
(LHD)J26A
(RHD)J8C
(LHD)J26A
(RHD) J/CB−W IGNI13
Ignition
Switch
− DIAGNOSTICSECD SYSTEM (1CD−FTV)(From September, 2003)
05−497
AVENSIS Supplement (RM1045E)
CHECK ENGINE WARNING LIGHT CIRCUIT
CIRCUIT DESCRIPTION
If the ECM detects a trouble, the CHK ENG is illuminated. At this time, the ECM records the DTC in its
memory.
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
Troubleshoot each trouble symptom in accordance with the chart below .
Reference:
ResultProceed to
CHK ENG remains onStart inspection from step 1
CHK ENG is not illuminatedStart inspection from step 3
05B62−07
Page 4368 of 5135
A65748ECM ConnectorE9
05
−498
−
DIAGNOSTICS ECD SYSTEM (1CD−FTV)(From September, 2003)
AVENSIS Supplement (RM1045E)
1 CLEAR DTC
(a) Connect the hand −held tester to the DLC 3.
(b) Turn the ignition switch to ON and turn the hand −held tester ON.
(c) Select the item ”DIAGNOSIS / OBD/MOBD / DTC INFO / CURRENT CODES”.
(d) Read DTCs.
(e) Select the item ”DIAGNOSIS / OBD/MOBD / DTC INFO / CLEAR CODES”.
(f) Clear the DTCs.
(g) Check that the CHK ENG is not illuminated. Standard: CHK ENG is not illuminated.
OK REPAIR CIRCUIT INDICATED BY OUTPUT DTC(See page 05 −299)
NG
2 CHECK HARNESS AND CONNECTOR(CHECK FOR SHORT IN WIRE HARNESS)
(a) Disconnect the E9 ECM connector.
(b) Turn the ignition switch to ON.
(c) Check that the CHK ENG is not illuminated. Standard: CHK ENG is not illuminated.
(d) Reconnect the ECM connector.
OK REPLACE ECM (See page 10− 29)
NG
CHECK AND REPAIR HARNESS AND CONNECTOR
3 CHECK CHK ENG CONDITION
(a) Check that the CHK ENG is illuminated when the ignition switch is turned to ON. Standard: CHK ENG is illuminated.
OK SYSTEM OK
NG
4 INSPECT COMBINATION METER ASSY(CHECK ENGINE WARNING LIGHT CIRCUIT)
NG REPAIR OR REPLACE BULB OR COMBINATION
METER ASSEMBLY
OK
CHECK AND REPAIR HARNESS AND CONNECTOR (COMBINATION METER −ECM)
