Page 153 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 031E7±03
± SERVICE SPECIFICATIONSSTARTING & CHARGING
03±33
AVENSIS REPAIR MANUAL (RM1018E)
TORQUE SPECIFICATION
1ZZ±FE/3ZZ±FE:
Part TightenedNmkgfcmftlbf
Starter assy x Transaxle housing3737

Page 154 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 031E6±01
03±32
± SERVICE SPECIFICATIONSSTARTING & CHARGING
AVENSIS REPAIR MANUAL (RM1018E)
STARTING & CHARGING
SERVICE DATA
1ZZ±FE/3ZZ±FE:
Starter assy
Rated voltage and output power
Specified

Page 155 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 031E5±01
± SERVICE SPECIFICATIONSIGNITION
03±31
AVENSIS REPAIR MANUAL (RM1018E)
TORQUE SPECIFICATION
1ZZ±FE/3ZZ±FE:
Part TightenedNmkgfcmftlbf
Spark plug x Cylinder head1818413
Ignition coil

Page 156 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 031E4±01
03±30
± SERVICE SPECIFICATIONSIGNITION
AVENSIS REPAIR MANUAL (RM1018E)
IGNITION
SERVICE DATA
1ZZ±FE/3ZZ±FE:
Spark plug
Recommended spark plug DENSO made
NGK made
Electrode gap K16R±U1

Page 157 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 031H6±01
03±28
± SERVICE SPECIFICATIONSLUBRICATION
AVENSIS REPAIR MANUAL (RM1018E)
TORQUE SPECIFICATION
1ZZ±FE/3ZZ±FE:
Part TightenedNmkgfcmftlbf
Oil pressure switch x Cylinder head1515311
O

031H6±01
03±28
± SERVICE SPECIFICATIONSLUBRICATION
AVENSIS REPAIR MANUAL (RM1018E)
TORQUE SPECIFICATION
1ZZ±FE/3ZZ±FE:
Part TightenedNmkgfcmftlbf
Oil pressure switch x Cylinder head1515311
Oil pan drain plug x Oil pan3737727
Oil pump x Cylinder block9.09280 in.lbf
1AZ±FE:
Part TightenedNmkgfcmftlbf
Oil pressure switch x Cylinder head1515311
Oil pan drain plug x Oil pan2525018
Oil pump x Cylinder block1919515
Timing chain guide x Cylinder block9.09280 in.lbf
Chain vibration damper No.1 x Cylinder block9.09280 in.lbf
Oil pan sub±assy x Cylinder block9.09280 in.lbf
Transverse engine engine mounting insulator x Cylinder block5253038
Engine service cover bracket RH x Body w/o Air conditioning
RHD (w/ Air conditioning) steering position type9.0
9.092
9280 in.lbf
80 in.lbf
Cooler bracket RH x Body LHD (w/ Air conditioning) steering position type9.09280 in.lbf
Engine x wire7.07162 in.lbf
Oil reservoir bracket No. 1 x Body8.08271 in.lbf
Cooler refrigerant suction hose No. 1 x cooler bracket No, 1
LHD (w/ Air conditioning) steering position type9.09280 in.lbf
Return tube x Body8.08271 in.lbf
Ignition coil assy x Cylinder head cover9.09280 in.lbf
Vane pump x Cylinder block3737727
Engine cover sub±assy x Cylinder block7.07162 in.lbf
Front wheel RH1031,05076
1AZ±FSE:
Part TightenedNmkgfcmftlbf
Oil pressure switch x Cylinder head1515311
Oil pan drain plug x Oil pan2525018
Oil pump x Cylinder block1919515
Timing chain guide x Cylinder block9.09280 in.lbf
Chain vibration damper No.1 x Cylinder block9.09280 in.lbf
Oil pan sub±assy x Cylinder block9.09280 in.lbf
Transverse engine engine mounting insulator x Cylinder block5253038
Engine service cover bracket RH x Body RHD steering position type9.09280 in.lbf
Cooler bracket RH x Body LHD steering position type9.09280 in.lbf
Engine x wire7.07162 in.lbf
Oil reservoir bracket No. 1 x Body8.08271 in.lbf
Cooler refrigerant suction hose No. 1 x cooler bracket No, 1
LHD steering position type9.09280 in.lbf
Return tube x Body8.08271 in.lbf
Ignition coil assy x Cylinder head cover9.09280 in.lbf
Vane pump x Cylinder block3737727
Engine cover sub±assy x Cylinder block7.07162 in.lbf
Front wheel RH1031,05076
1CD±FTV:
Part TightenedNmkgfcmftlbf
Oil drain plug x Oil pan sub±assy No. 23435025
Oil pump x Cylinder block3132023

Page 158 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual ± SERVICE SPECIFICATIONSLUBRICATION
03±29
AVENSIS REPAIR MANUAL (RM1018E)Part Tightenedftlbf kgfcm Nm
Crankshaft position sensor x Oil pump assy8.89078 in.lbf
Oil pan sub±assy x Cylinder bloc

Page 159 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 031HN±01
± SERVICE SPECIFICATIONSSEAT
03±71
AVENSIS REPAIR MANUAL (RM1018E)
SEAT
TORQUE SPECIFICATION
Part TightenedNmkgfcmftlbf
FRONT SEAT
Seat Inner belt assy x Seat adjuster assy4242831
Sea

Page 160 of 5135

TOYOTA AVENSIS 2005 Service Repair Manual 031I3±01
03±70
± SERVICE SPECIFICATIONSINSTRUMENT PANEL/METER
AVENSIS REPAIR MANUAL (RM1018E)
INSTRUMENT PANEL/METER
TORQUE SPECIFICATION
Part TightenedNmkgfcmftlbf
Instrument Panel Reinforcem
