ENGINE CONTROL SYSTEM ECD SYSTEM (1CD−FTV)(From September, 2003)
10 −19
AVENSIS Supplement (RM1045E)
ECD SYSTEM (1CD −FTV)(From September, 2003)
ON −VEHICLE INSPECTION
1. INSPECT MASS AIR FLOW METER
(a) If you have the hand −held tester:
Check the operation.
(1) Connect the hand −held tester to the DLC3.
(2) Turn the ignition switch to ON.
(3) Select the item ”DIAGNOSIS / OBD / MOBD / DATA
LIST” on the hand −held tester.
(4) Blow air into the mass air flow (MAF) meter, then
check that the MAF reading in DATA LIST fluctu-
ates.
If the operation is not as specified, check the MAF meter
(see page 10 −22), wiring and ECM.
(b) If you have no hand −held tester:
Check the operation.
(1) Turn the ignition switch to ON.
(2) Connect the positive tester probe of a voltmeter to
terminal VG of the ECM, and the negative tester
probe of the voltmeter to terminal EVG of the ECM.
(3) Blow air into the MAF meter, then check that the voltage fluctuates.
If the operation is not as specified, check the MAF meter
(see page 10 −22), wiring and ECM.
2. INSPECT INTAKE SHUTTER
(a) Listen to the operating sounds of the throttle control mo- tor.
(1) Turn the ignition switch to ON.
(2) Listen to the operating sounds while turning the ac-
celerator pedal position sensor lever.
If a collision sound is heard, check the throttle control motor.
If no sound is heard, check the wire harness and ECM.
(b) If you have the hand −held tester:
Inspect the throttle position sensor.
(1) Connect the hand −held tester to the DLC3.
(2) Turn the ignition switch to ON.
(3) Select the item ”DIAGNOSIS / OBD / MOBD / DATE LIST” on the hand held −tester.
