Page 1233 of 5135
05C5V±01
3
2
145678
910111213141516
DLC3
A04550
C93955
05±1184
±
DIAGNOSTICS SUPPLEMENTAL RESTRAINT SYSTEM
AVENSIS REPAIR MANUAL (RM1018E)
PRE±CHECK
1.DIAGNOSIS SYSTEM
(a)Check the DLC3. (1)The vehicle's ECM conforms to ISO 9141±2 forcommunication protocol. The terminal arrangement
of the DLC3 complies with ISO 15031±3 and meets
the ISO 9141±2 format.
Terminal No.Connection/Voltage or ResistanceCondition
7Bus + Line/Pulse generationDuring Transmission
4Chassis Ground Body Ground/1 or lessAlways
16Battery Positive Body Ground/9 ± 14 VAlways
HINT:
If the display shows UNABLE TO CONNECT TO VEHICLE
when you connect the cable of the hand±held tester to the
DLC3, turn the ignition switch to the ON position and operate
the hand±held tester, there is a problem either on the vehicle
side or tool side.
If communication is normal when the tool is connected to
another vehicle, inspect the DLC3 on the original vehicle.
If communication is still not possible when the tool is con-
nected to another vehicle, the problem is probably in the
tool itself, so consult the Service Department listed in the
tool's instruction manual.
2.SRS WARNING LIGHT CHECK
(a)Turn the ignition switch to the ON position, and check that the SRS warning light comes on.
(b)Check that the SRS warning light goes off after approx.
6 seconds.
HINT:
When the ignition switch is ON position and the SRS
warning light remains on or flashes, the airbag sensor
assy center detects a malfunction code.
When the SRS warning light comes on even when the
ignition switch is in the LOCK position, trouble in the pow-
er source or combination meter assy is suspected. Pro-
ceed to ºSRS warning light circuit malfunction (Always
lights up, when ignition switch is LOCK position)º on page
05±1386.
When the ignition switch is turned from the LOCK to ON
position, the SRS warning light does not come on. Pro-
ceed to ºSRS warning light circuit malfunction (Does not
light up, when ignition switch is turned ON)º on page
05±1389.
Page 1234 of 5135
H40173CG
TC
H13050
Normal Code (w/o Past Trouble Code)
Normal Code (w/ Past Trouble Code) Malfunctioning Code
(Example Code 11 and 31) 0.25
ON
OFF
0.750.25
0.25
ON
OFF
0.52.54.0
1.5 0.5 Repeat
DTC31
DTC11
±
DIAGNOSTICS SUPPLEMENTAL RESTRAINT SYSTEM
05±1185
AVENSIS REPAIR MANUAL (RM1018E)
3.DTC CHECK (USING SST CHECK WIRE)
(a)Output the DTCs (Present trouble code).
(1)Turn the ignition switch to the ON position, and wait
for approx. 60 seconds.
(2)Using SST, connect the TC and CG of the DLC3.
SST09843±18040
NOTICE:
Pay attention to the terminal connecting position to avoid
a malfunction.
(b)Output the DTCs (Past trouble code).
(1)Using SST, connect the TC and CG of the DLC3.
SST09843±18040
NOTICE:
Pay attention to the terminal connecting position to avoid
a malfunction. (2)Turn the ignition switch to the ON position, and wait
for approx. 60 seconds.
(c)Read the DTCs. (1)Read the DTC by counting the blinking times. Forexample, the blinking patterns for normal code,
code 11 and code 31 are shown in the illustration.
Normal code indication (w/o past trouble
code)
The light blinks twice per second.
Normal code indication (w/ past trouble code)
When the past trouble code is stored in the
airbag sensor assy center, the blinks only
once a second.
Malfunction code indication
The first blinking indicates the first DTC. Se-
cond blinking occurs after 1.5±second of
pause.
If there are 2 or more codes, there will be a 2.5±second pause
between each code. After all codes are shown, there will be a
4.0±second pause, and they will all be repeated.
HINT:
If 2 or more malfunctions are found, the indication starts
from the smaller numbered code.
If DTCs are indicated without a connection of the termi-
nals, proceed to the ºTC terminal circuitº on page
05±1391.
(d) Clear the DTCs. (1) When the ignition switch is turned off, the DTCs are cleared.
HINT:
Depending on the DTC, the code might not be cleared by turning off the ignition switch. In this case, proceed
to the next step.
Page 1235 of 5135
H43008
IG S/W
DLC3
SRS Warning Light (*)
ON
OFF
Open
Short
0.5 sec.
1.5 sec.
T1
0.25 sec.
T2 T3 T4 T5 T6 T5 T6 T5 T6 T5 T70.5 sec.0.25 sec.
CG TC
T1: 0 ± second
T2: approx. 6 seconds
T3: 3 ± 5 seconds
T7: within 1 second
*: The past trouble code in the illustration shows DTC 21 as an example.T4: 3 ± 10 seconds
T5: 2 ± 4 seconds
T6: 1 ± 5 seconds 05±1186
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
AVENSIS REPAIR MANUAL (RM1018E)
(2) Using SST, connect the TC and CG of the DLC3, and turn the ignition switch to the ON position.
SST 09843±18040
(3) Disconnect the TC of the DLC3 within 3 to 10 seconds after the DTCs are output, and check if
the SRS warning light comes on after 3.0 seconds.
(4) Within 2.0 to 4.0 seconds after the SRS warning light comes on, connect the TC and CG of the
DLC3.
(5) The SRS warning light goes off within 2.0 to 4.0 seconds after connecting the TC and CG of the
DLC3. Then, disconnect the TC of the DLC3 within 2.0 to 4.0 seconds after the SRS warning
light goes off.
(6) The SRS warning light comes on again within 2.0 to 4.0 seconds after disconnecting the TC of
the DLC3. Then, within 2.0 to 4.0 seconds after the lighting, connect the TC and CG of the DLC3.
(7) Check if the SRS warning light goes off after 2.0 to 4.0 seconds after connecting the TC and CG
of the DLC3, and the normal code is output within 1.0 second after the SRS warning light goes
off.
If the DTCs are not cleared, repeat the above procedure until the codes are cleared.
4. DTC CHECK (USING HAND±HELD TESTER)
(a) Check the DTCs.
(1) Connect the hand±held tester to the DLC3.
(2) Turn the ignition switch to the ON position.
(3) Check the DTCs by following the prompts on the tester screen.
HINT:
Refer to the hand±held tester operation's manual for further details.
Page 1236 of 5135
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
05±1187
AVENSIS REPAIR MANUAL (RM1018E)
(b) Clear the DTCs.
(1) Connect the hand±held tester to the DLC3.
(2) Turn the ignition switch to the ON position.
(3) Clear the DTCs by following the prompts on the tester screen.
HINT:
Please refer to the hand±held tester operation's manual for further details.
5. RELEASE METHOD OF ACTIVATION PREVENTION MECHANISM
(a) The activation prevention mechanism is built in the connector for the squib circuit of the SRS.
As explained in the troubleshooting later, insert a paper with the same thickness as the male terminal
between the terminal and the short spring to release it (Refer to illustrations on next 2 pages).
CAUTION:
Never release the activation prevention mechanism on the squib connector.
NOTICE:
Do not release the activation prevention mechanism unless specially directed by the trouble-
shooting procedure.
To prevent the terminal and the short spring from damage, always use a paper with the same
thickness as the male terminals.
Page 1237 of 5135
H42671
Side Airbag
Sensor Assy RH
Airbag Front
RH Sensor
Airbag Sensor
Assy Center
Airbag Sensor
Front LH
Side Airbag
Sensor Assy LH
Airbag Sensor
Rear LH (*1)
Seat Position
Airbag Sensor
(*2)Horn Button Assy
(Squib) Instrument Panel
Passenger Airbag
Assy (Squib)Front Seat Outer
Belt Assy RH
(Squib)
Front Seat
Airbag Assy RH
(Squib)
Front Seat
Airbag Assy
LH (Squib)
Curtain Shield
Airbag Assy LH
(Squib) (*1) Airbag Sensor
Rear RH (*1)Curtain Shield
Airbag Assy RH
(Squib) (*1)
Front Seat Outer
Belt Assy LH
(Squib) Seat Position
Airbag Sensor
(*3)
Instrument Panel
Airbag Assy (Squib)
Spiral Cable
Sub±assy 7
15 8
16
513
614 3 11
412
19
210
23
24 2129
2230
1927
2028
17 25
1826
34 5
6
78
11
12 9
1025
26
27
28
29
30
*1: w/ Curtain Shield Airbag
*2: LHD
*3: RHD 05±1188
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
AVENSIS REPAIR MANUAL (RM1018E)
Page 1238 of 5135
H42608
Airbag Sensor Assy Center Connector
Short Spring
Before Release After Release
Before Release After Release
Paper
Short Spring
Short Spring Connector
16
Connector
26
20
424
Before Release After Release
Paper
Short Spring Short Spring
PaperPaper
Short Spring
Paper
Paper
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
05±1189
AVENSIS REPAIR MANUAL (RM1018E)
Page 1239 of 5135
050WX±16
[
]
[]
[]
H40122
Supplemental Restraint System Check SheetInspector 's
Name
Date Vehicle Brought InVIN
Production Date
Licence No.
Odometer Readingkm
Miles
Date Problem Occurred
Weather
TemperatureFine Cloudy Rainy Snowy Other
Approx.
Starting Idling
Driving Constant speed Acceleration Deceleration
Other Vehicle Operation
Road Condition
Details of Problem
Vehicle Inspection, Repair Histo-
ry Prior to Occurrence of Mal-
function (Including Supplemen-
tal Restraint System)
Diagnosis System Inspection
SRS Warning Light
Inspection
DTC Inspection1st Time
2nd TimeRemains ON Does Not Come on
Normal Code Malfunction Code Code. Customer 's Name
1st Time
2nd TimeSometimes Comes on
Remains ON Does Not Come onSometimes Comes on
Normal Code Malfunction Code Code.
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
05±1183
AVENSIS REPAIR MANUAL (RM1018E)
CUSTOMER PROBLEM ANALYSIS CHECK
Page 1240 of 5135
050YF±18
±
DIAGNOSTICS SUPPLEMENTAL RESTRAINT SYSTEM
05±1181
AVENSIS REPAIR MANUAL (RM1018E)
SUPPLEMENTAL RESTRAINT SYSTEM
HOW TO PROCEED WITH TROUBLESHOOTING
The hand±held tester can be used at step 3, 5, 8, 9.
1VEHICLE BROUGHT TO WORKSHOP
2CUSTOMER PROBLEM ANALYSIS (See page 05±1183)
3DTC CHECK (Present and Past DTC) (See page 05±1184)
DTC IS OUTPUT: Go to step 4
DTC IS NOT OUTPUT: Go to step 11
4THE DTCS CHART (See page 05±1190)
5CIRCUIT INSPECTION (See page 05±1198 to 05±1374)
MALFUNCTION CODE IS OUTPUT: Go to step 6
NORMAL CODE IS OUTPUT: Go to step 11
6 IDENTIFICATION OF PROBLEM
7 REPAIR
8CLEAR THE DTCS (Present and Past DTC) (See page 05±1184)
9DTC CHECK (See page 05±1184)
DTC CODE IS NOT OUTPUT: Go to step 10
DTC CODE IS OUTPUT: Go to step 4
