 AR68.30-P-4100GI
Remove/install door sill molding
20.4.01
MODEL
163.113 /128 /136 /154 /157 /172 /174 /175
Door sill molding in cargo space
P68.30-2393-11
1
 Caps
2
 Door sill molding

Remove/install
1
Remove cover caps (1)
 Do not scratch door sill molding.
2
Remove screws below caps
3
Remove door sill molding (2)

Installation:
  Ensure that sealing rubber is
positioned correctly.
4.1
Disconnect connector from electronic compass
 Only as of 01.09.00 and with code (245),
trip computer.
5
Install in the reverse order
Copyright DaimlerChrysler AG  28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2131 of 4133

 AR63.20-P-2010GH
Remove/install D-pillar paneling
26.1.99
MODEL
163.113 /128 /136 /154 /157 /172 /174 /175
P63.20-3336-11
1
D-pillar paneling
2
 Bonding material

Remove
1
Remove D-pillar paneling (1)
 Separate glue bead with cutting wire.
 Additional pull handle for cutting wire
*WH58.30-Z-1017-02A
2
Remove any residual bonding material on the
D-pillar flange
 Not more than 2 mm of glue must remain.

Install
3
Clean D-pillar paneling
 In order to ensure a good adhesion.
4
Apply primer to damaged paint areas on D-
pillar flange
 Use 2K primer
 . Allow primer to air for at
least 5 minutes.
5
Prepare D-pillar flange
 If the remaining glue (cut glue bead) is
older than 24 hours, also apply
 primer
for
paint to body to obtain optimum glued joint.
*BR00.45-Z-1059-02A
 If the
 body
has been damaged or if there
is no bonding material then apply the
 primer
to the bonding first. Allow the primer to flash
off for at least 10 minutes, but not for longer
than 15 minutes.
6
Prepare D-pillar paneling (1)
 Apply primer to bonding. Allow the primer
to flash off for at least 10 minutes, but not for
longer than 15 minutes.
*BR00.45-Z-1059-02A
7
Prepare glue cartridge
AR67.10-P-1000-07P
 Betapower II (2-component electric
cartridge gun)
*WH58.30-Z-1015-20A
2-component glue kit
*BR00.45-Z-1055-02A
8
Apply glue (2) as glue bead to D-pillar
paneling (1)

The paneling must be put on within 5
minutes, otherwise the adhesion quality of the
bonding material will be impaired.
 Height of adhesive bead approx. 13 mm
Use reference points on inside of D-pillar
paneling.
 Betapower II (2-component electric
cartridge gun)
*WH58.30-Z-1015-20A
9
Align D-pillar paneling (1)
10
Install D-pillar paneling (1)
 Firmly press D-pillar paneling to D-pillar
flange.
Commercially available tools
 (see Workshop Equipment Manual)
Number
Designation
Make (e. g.)
Order number
WH58.30-Z-1017-02A
 Additional handle for cutting wire
Stahlwille
Eduard Wille GmbH &
Co.Lindenallee 27
D-42331 Wuppertal
10351/1
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2132 of 4133
 WH58.30-Z-1015-20A
Betapower II (2-component electric cartridge gun)
DOW Automotive
(Deutschland) GmbH
Am Güterbahnhof
D-35683 Dillenburg
Tel.: +49 (0)
39484/8714-0
995.182
Repair products
Number
Designation
Order number
BR00.45-Z-1059-02A
Primer BETAPRIME 5404
100ml
Item no. 940.870
Felt ring
Tech. Großhandels GbR
D-37242
Bad Sooden-Allendorf
BR00.45-Z-1055-02A
2K glue kit
168 670 00 93
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 2


        Page 2133 of 4133

 AR47.10-P-4000GH
Empty fuel tank if fuel pump is faulty
28.10.97
MODEL
163.113 with ENGINE 612.963
MODEL
 163.128 with ENGINE 628.963
MODEL
 163.136 with ENGINE 111.977
MODEL
 163.154 with ENGINE 112.942
MODEL
 163.157 with ENGINE 112.970
MODEL
 163.172 with ENGINE 113.942
MODEL
 163.174 with ENGINE 113.981
MODEL
 163.175 with ENGINE 113.965
P47.20-2076-06
1
Fondsitzkonsole
2
 Cover of left C-pillar
3
 Seat retaining cable
4
 Wiring harness
P47.10-2077-09
84
 Closing cover
90/10
 Ground line (vacuum unit)
90/11
 Fuel return line
 90/12
Fuel feed line
90/13
 Stationary heater connection
90/14
 Extraction hose

Remove, Install


Danger!
Risk of explosion
  from fuel igniting,
risk of
poisoning
  from inhaling and swallowing fuel
as well as
 risk of injury
  to eyes and skin
from contact with fuel.
Fire, sparks, open flames or smoking
forbidden.
Pour fuels only into suitable and appropriately
marked containers.
Wear protective clothing when handling fuel.
AS47.00-Z-0001-01A
Copyright DaimlerChrysler AG  28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2134 of 4133

 1.1
Unscrew bolts at rear of 2/3 seat bench and
raise rear of seat bench
 Up to VIN A145272, X708318.
1.2
Remove covers at seat frame of 60% bench
seat
 As of VIN A145273, X708319.
AR91.12-P-1100GH
 Only remove the covers which are
identified in the document with A, D and E.
2.1
Fold 60% bench seat forward into footwell
 As of VIN A145273, X708319. See
operator's manual.
3.1
Pull floor covering below rear seat mounting
bracket (1) of 60% seat forward
 Carefully pull floor covering forward under
the seat console to prevent it from tearing.
 As of VIN A145273, X708319.
4.1
Pull the floor covering forward under the front
corner of the left C-pillar cover (2)
 Carefully pull the floor covering forward
under the cover to prevent it from tearing.
 As of VIN A145273, X708319.
5
Cut into floor covering directly behind seat
retaining cable (3)
 Ensure that the wiring harness (4) is not
damaged when cutting the floor covering.
 As of VIN A145273, X708319. Broken
line marks the cut.
6
Fold floor mat back

 Do not crease floor mat!
 Fold floor mat back far enough to provide
access to cap (84) between body and fuel
pump.
7
Remove end cover (84) of body

Installation:
 Replace cap and insert with
new sealing compound.


Cap (84) is sealed in with body sealer.
Heat with hot air blower to make it easier to
remove.
8
Seal fuel return line (90/11)
 Pliers
*163589003700
9
Connect extraction hose (90/14) with adapter
hose to connection for fuel return line (90/11)

 Extraction hose
*168589009000


Adapter hose
*163589009100
10
Connect ground cable (90/10) of extraction
pump ground terminal vehicle battery
Pumping out
11
Pump fuel out into safety container using
extraction pump

*BF47.10-P-1001-01A

*WH58.30-Z-1001-16A
12
Install in the reverse order

Fuel tank
Number
Designation
Models
163.113/
136/154/
172 up to
31.08.01
Models
163.113/
136/154/
172 as of
01.09.01

Models
163.157/
175
Model
163.128
Model
163.174
BF47.10-P-1001-01A
Fuel tank capacity
Total capacity
Liter
72838393
Reserve capacity
Liter
10121212
Copyright DaimlerChrysler AG  28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 2


        Page 2135 of 4133
 163 589 00 91 00
Extraction hose
Adapter hose
Pliers
163 589 00 37 00 168 589 00 90 00
Commercially available tools
 (see Workshop Equipment Manual)
Number
Designation
Make (e.g.)
Order number
WH58.30-Z-1001-16A
Suction master M2P 20 B
Ecco GmbH
Vonkeln 17
D-42349 Wuppertal
9749 5000 50
Copyright DaimlerChrysler AG  28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 3


        Page 2136 of 4133

 AR40.10-P-1080A
Draining TIREFIT sealant out of tires
18.6.96
MODEL
163.174
MODEL
 168, 170, 171, 203, 209, 211, 230, 240
P40.10-0309-02
1
Tire sealant container
2
 Hose
3
 Tire sealant
Draining


Danger!
Risk of death
  cased by vehicle slipping or
toppling off of the lifting platform.
Align vehicle between the columns of the
hydraulic hoist and position the four support
plates below the hoist support points specified
by the vehicle manufacturer.
AS00.00-Z-0010-01A
1
Remove wheel.

e

Remove/install wheels, rotate if necessary
Model 163.174
AP40.10-P-4050GH
Model 168, 170, 203, 209, 211, 230, 240
AP40.10-P-4050Z
Type 171
AP40.10-P-4050V
2
Position road wheel upright with valve
pointing downwards for
approx. 10 minutes.

 Raise wheel approx. 200 mm to allow tire
sealant (3) to run out.
3
Unscrew valve element from the valve and
allow pressure to escape from the tire
4
Pull valve out of rim.

 Press remains of valve remaining in valve
bore of disk wheel into inside of tire.
5
Attach hose (2) to tire sealant container (1).

 Replace original hose of tire sealant
container (1) with a hose (2) approx.
400 mm long.
6
Press tire sealant container (1) together and
immerse hose (2) through the valve hole in
the disk wheel, as low as possible into the tire
repair kit (3)
7
Reduce pressure on tire sealant container (1),
the tire sealant (3) is extracted.

 This method can be used to remove
approx. 90% of the tire sealant (3).
 If the tire sealant container (1) is not
available, drill the tire tread with a twist drill (
4
10mm) and allow the tire repair kit (3) to flow
into a suitable container.

TIREFIT tire sealant
Model 163.174, 168, 170, 171, 203, 209, 211,
230, 240
AH40.10-P-0001-01A
8
Replace tire
 Remove the remaining tire repair kit (3)
from the rim using a damp cloth.
AR40.10-P-1030A
9
Place new TIREFIT tire repair kit in the vehicle
See
#
e
TIREFIT tire sealant - check expiration date.
AP40.10-P-4054R
Copyright DaimlerChrysler AG  06.07.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
