MERCEDES-BENZ ML320 1997 Complete Repair Manual 2
Remove screws (2)

Starting from the straight-ahead position,

turn steering wheel by 90 to obtain better

access to the bolts.

*BA91.60-P-1001-01A

Screwdriver bit

*126589001000

3
Lift

Page 3898 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR46.10-P-0200GH
Removing, installing contact spiral
1.3.97

MODEL
163.113 /128 /136 /154 /157 /172 /174 /175

P46.10-0460-01 P46.10-0461-01 P46.10-0399-01

Remove/install

1
Remove steering whee

Page 3899 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR46.10-P-0100GHRemoving and installing steering wheel
1.3.97

MODEL
163.113 /128 /136 /154 /157 /172 /174 /175

P46.10-0449-11
P46.10-0450-01 P46.10-0458-01 P46.10-0459-01

Modification notes

10.

AR46.10-P-0100GHRemoving and installing steering wheel
1.3.97

MODEL
163.113 /128 /136 /154 /157 /172 /174 /175

P46.10-0449-11
P46.10-0450-01 P46.10-0458-01 P46.10-0459-01

Modification notes

10.9.03

Connecting quiescent current retention unit deleted
Step 1

10.9.03
Reference to adjusting toe on front axle replaced by

reference to chassis alignment check
Step 10

Removing, installing

Danger!

Risk of explosion
caused by explosive gas.

Risk of poisoning and caustic burns

caused by swallowing battery electrolyte.
Risk of injury
caused by burns to skin and

eyes from battery acid or when handling

damaged lead-acid batteries
No fire, sparks, open flames or smoking.

Wear acid-resistant gloves, clothing and eye

protection. Pour battery electrolyte only into

suitable and appropriately marked containers.

AS54.10-Z-0001-01A

Danger!

Risk of injury
when carrying out test or repair

work on airbag or emergency tensioning

retractor units
Store airbag units with deployment side facing

up; do not expose to temperatures greater

than 100 °C. When working on these units,

disconnect the power supply.

AS91.00-Z-0001-01A

Legal provisions concerning handling and

storage of airbag and emergency tensioning

retractor units

AH91.00-P-0004-01A

o

Notes on disposing of airbag and emergency

tensioning retractor units

OS91.00-P-0001-01A

1
Disconnect ground cable from battery

Protect the ground cable to prevent

unintentional contact with the battery ground

terminal.

AR54.10-P-0003A

Notes on battery

AH54.10-P-0001-01A

2
Remove airbag unit (120) from steering wheel

(32)

AR91.60-P-0660GH

Instructions for performing repair, body work

and welding on vehicles with airbags and

ETR units

AH91.00-P-0002-01B

3
Unplug connectors (38b, 38c) for horn

4
Turn steering wheel (32) to horizontal position

(front wheels in straight-ahead position)

Copyright DaimlerChrysler AG 09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

Page 3900 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 5
Remove key and engage steering lock

6
Unscrew bolt (32c)

Hold the steering wheel (32).

Installation:
Replace bolt (32c).

*BA46.10-P-1001-02A

7
Pull off steering wheel (32)

Pass cables

Page 3901 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
GF54.30-P-3009A
Stepper motor, location/design/function
7.7.99

MODEL
129, 140 as of 1.6.96,

163, 168, 170,

202 as of 1.8.96,

208,

210 as of 1.6.96,

215, 220

P54.30-0521-06

General

Ste

GF54.30-P-3009A
Stepper motor, location/design/function
7.7.99

MODEL
129, 140 as of 1.6.96,

163, 168, 170,

202 as of 1.8.96,

208,

210 as of 1.6.96,

215, 220

P54.30-0521-06

General

Stepper motors are motors which, like most

electric motors, consist of a fixed stator and a

moveable rotor. The rotary motion is not

continuous, rather the rotor turns in steps, a

certain angle at a time, for example 90°.

Design

The illustration shows the basic design of a
stepper motor with 1 pole pair and 2 phases.

The stator is made of magnetically soft iron

and holds the windings. Opposite windings

belong together and form a phase (in this

case, a and b). The rotor consists of a

permanent magnet. In the illustration the rotor

has 1 pole pair.

Function

The rotor is turned by applying current

through phase aor b (see illustration). The

magnetism in the stator changes according to

the polarization (I) of the phases.

The rotor will turn so that its south pole (S) is at the north pole (N) of

the stator and its north pole (N) is at the south pole (S) of the stator.

The illustration shows a full rotation of the rotor. The rotor moves in

steps of 90° from positions 1 through 4 and back to its starting

position.

Unlike normal electric motors, the motor can stop in each of these

positions with a certain holding torque. This type of motor is therefore
particularly suitable for use as a servomotor for exact positioning.
The size of the steps can be reduced considerably by increasing the

number of pole pairs and phases.

Theoretically, it is even possible to make the steps infinitely small

with just a few poles and phases by using complicated electronic

phase control (sine-cosine control).

Stepper motors (with sine-cosine control) are used, for example, for

pointing instruments in the instrument cluster (A1).

Copyright DaimlerChrysler AG 04.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

Page 3902 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
BT27.35-P-0004-01A
Strainer for modulating pressure and shift

pressure control solenoid valve, new
Transmission 722.6
k

TRANSMISSION
722.6## ## as of 0538312

P27.35-0248-06

70
Strainer

Str

Page 3903 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
BT27.35-P-0005-01A
Strainer in inlet to converter lock-up control

solenoid valve, new
Transmission 722.6
k

TRANSMISSION
722.6## ## as of 0485895

P27.35-0251-09

144
Strainer/converter lock-u

Page 3904 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR88.30-P-0200-04GH
Prepare cutting tool

Commercially available tools
(see Workshop Equipment Manual)

Number

Designation
Make (e. g.)
Order number

WH58.30-Z-1010-10A
Cutting tool kit (compresse
