Page 2121 of 4133

 AR88.70-P-9020GH
Removing and installing mirror glass
12.2.97
MODEL
163.113 /136 /154 /172 /174 up to 31.8.01
P88.70-0253-01
1
Mirror glass
2
 Support spring
3
 Connector
Arrows
 Mirror glass mount
M21/1r1
 Mirror heater
M21/2r1
 Mirror heater (not illustrated)
P88.70-0254-01
Operation no. of operation texts or standard texts and flat rates
Range
Op. no.
Operation text
P
883321
REPLACING GLASS FOR LEFT OUTSIDE REARVIEW MIRROR
P
883330
REPLACING GLASS FOR RIGHT OUTSIDE REARVIEW MIRROR
P
883340
REPLACING GLASS FOR BOTH OUTSIDE REARVIEW MIRRORS

Remove/install
1
Tilt mirror glass (1) at top outward
 Actuate electrical mirror adjustment switch
2
Press mirror glass (1) off of drive

*110589035900
3
Disconnect connector (3) from mirror heater
(M21/1r1 and M21/2r1)
4
Remove mirror glass (1)

 Installation:
 Install mirror glass (1) from
bottom to top, thereby observe support spring
(2) and mirror glass mounts (arrows).
5
Install in the reverse order
Assembly wedge
110 589 03 59 00
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2122 of 4133

 AR88.70-P-9000GH
Remove/install complete outside rearview mirror
12.2.97
MODEL
163.113 /128 /136 /154 /157 /172 /174 /175
P88.70-0252-06
Illustrated up to VIN A289564, X754619
1
 Paneling
2
 Screw
3
 Nuts
M21/1
 Left electrically adjustable and
heated outside mirror
M21/1x1
 Left electrically adjustable and
heated outside mirror connector

Removing and installing
1
Press off paneling (1) with assembly wedge
 As of VIN A289565, X754620: If present,
disconnect connector from loudspeaker.
 Assembly wedge
*110589035900
2
Unscrew screw (2)
3
Unscrew nut (3)
 Secure outside rearview mirror against
falling down

Installation:
  Up to VIN A289564,
X754619 fasten mounting lug for connector
for left electrically adjustable and heated
outside rearview mirror (M21/1x1) or for
connector for right electrically adjustable and
heated outside rearview mirror on bottom stud
bolt.
4
Separate connector for left electrically
adjustable and heated outside rearview mirror
(M21/1x1) or connector for right electrically
adjustable and heated outside rearview mirror.
5
Remove left electrically adjustable and heated
outside rearview mirror (M21/1) or right
electrically adjustable and heated outside
rearview mirror
6
Install in the reverse order
Assembly wedge
110 589 03 59 00
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2123 of 4133

 SM72.10-P-0004A
Modify front door
6.5.03
MODEL
163.113 /128 /136 /154 /157 /172 /174 /175
P72.10-2740-06
1
Side airbag
2
 Mounting holes
3
 Location hole
4
 Locating tab
Operation no. of the operation texts or standard texts and flat rates
 Range
Op. no.
Operation text
Flat rate
Acc. no.
Code
P
721680
Additional work to 1st door Location:.... replace transfer with
components: Drill hole for side airbag
003 WU/0.3 h
------
1
Place side airbag (1) into position on door
 Use mounting holes (2) to align properly.
2
Mark center of locating tab (4)
3
Remove side airbag
4
Drill
4
=10.5 mm hole (3) in door sheet metal
at center location
 Ensure window glass will not be damaged
by drilling.
5
Smooth rough edges of hole
6
Clean, prime, and paint hole
7
Remove metal chips from bottom of door
Parts ordering notes
Part no.
Designation
Quantity
000 986 06 50
Priming stick
1
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2124 of 4133

 AR72.12-P-1010GH
Remove/install rear door liner
18.2.97
MODEL
163.113 /128 /136 /154 /157 /172 /174 /175
P72.12-2061-09
1
Door handle cover
2
 Bolt
3
 Door liner
 7
Assembly wedge
8
 Entrance lamp
9
 Bolt
4
Bowden cable
5
 Inner lock
6
 Clips

Remove/install
1
Open crank window
2
Remove cover for door handle (1)
3
Unscrew screw (2)
4.1
Unclip SRS panel and unscrew screw (9)
 As of vehicle identification number
A145273, X708319.
5
Press door liner (3) off of bottom, front and
rear inner door panel with assembly wedge (7)
 Position assembly wedge directly next to
clips
 Assembly wedge
*110589035900
6
Lift door liner (3) up and out
7
Unhook control cable (4) on inner door
actuating mechanism
8
Unclip inner lock (5) on door liner (3)
9.1
Remove entrance lamp (8)
 As of vehicle identification number
A145273, X708319.
10
Lay down door liner
11
Check foil and sheet metal clip nuts on inner
door panel
  Replace damaged foil. Replace all clips.
12
Install in the reverse order
Assembly wedge
110 589 03 59 00
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2125 of 4133
 AR68.30-P-4100GI
Remove/install door sill molding
20.4.01
MODEL
163.113 /128 /136 /154 /157 /172 /174 /175
Door sill molding in cargo space
P68.30-2393-11
1
 Caps
2
 Door sill molding

Remove/install
1
Remove cover caps (1)
 Do not scratch door sill molding.
2
Remove screws below caps
3
Remove door sill molding (2)

Installation:
  Ensure that sealing rubber is
positioned correctly.
4.1
Disconnect connector from electronic compass
 Only as of 01.09.00 and with code (245),
trip computer.
5
Install in the reverse order
Copyright DaimlerChrysler AG  17.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2126 of 4133
 AR68.30-P-4100GI
Remove/install door sill molding
20.4.01
MODEL
163.113 /128 /136 /154 /157 /172 /174 /175
Door sill molding in cargo space
P68.30-2393-11
1
 Caps
2
 Door sill molding

Remove/install
1
Remove cover caps (1)
 Do not scratch door sill molding.
2
Remove screws below caps
3
Remove door sill molding (2)

Installation:
  Ensure that sealing rubber is
positioned correctly.
4.1
Disconnect connector from electronic compass
 Only as of 01.09.00 and with code (245),
trip computer.
5
Install in the reverse order
Copyright DaimlerChrysler AG  17.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2127 of 4133

 AR 72.1 0 -P -2 400G HRem ovin g a n d in sta llin g  o ute r d oo r h an dle  o n f r o nt d oor12 .2 .9 7
M ODEL 1 63
P 72.1 0 -0 488 -0 6
1 Handle
2 Lo ck c ylin de r g u id e
3 Rota tin g r o d
4 Base
5 Base
6 Scre w
7 Reta in in g s tr a p
8 Bearin g b ra ck e t
9 Scre w
1 0 Scre w  o p enin g
O pera tio n  n o. o f o pera tio n t e xts  o r o f s ta n dard  t e x ts  a n d  f la t r a te s
D iv is io n
O pe ra tio n
n o.O pe ra tio n te xt
P7 27 240R EPLA C IN G  O UTE R  D O O R H AN D LE  O N L E FT  F R O NT D O O R
P727 241R EPLA C IN G  O UTE R  D O O R H AN D LE  O N L E FT  F R O NT D O O R, W IT H O UT B EA R IN G  B R AC KE T
P727 242R EPLA C IN G  O UTE R  D O O R H AN D LE  O N L E FT  F R O NT D O O R, W IT H  B E AR IN G  B R AC KET
P727 243R EPLA C IN G  O UTE R  D O O R H AN D LE  O N L E FT  F R O NT D O O R  ( IN CLU DIN G  T R AN SFE R IN G  L O CKIN G  C YLIN D ER )
P727 265R EPLA C IN G  O UTE R  D O O R H AN D LE  O N R IG HT F R O NT D O OR
P727 266R EPLA C IN G  O UTE R  D O O R H AN D LE  O N R IG HT F R O NT D O OR,  W IT H O UT B E AR IN G  B R AC KET
P727 267R EPLA C IN G  O UTE R  D O O R H AN D LE  O N R IG HT F R O NT D O OR,  W IT H  B EA R IN G  B R AC KE T
P727 268R EPLA C IN G  O UTE R  D O O R H AN D LE  O N R IG HT F R O NT D O OR   ( IN CLU DIN G  T R AN SFE R IN G  L O CKIN G  C YLIN DER )

R em ova l,  i n sta lla tio n
1Loo se n  s cre w  ( 6 )
 A cce ssib le  t h ro ug h o p en in g  ( 1 0) o n  in ne r
s id e o f d oo r, lo o se n  s c re w  ( 6 ) m ax.  5  tu rn s

*B A72.1 0-P -1 003-0 1D
2P ull  o ff  c yli n d er g u id e ( 2 ) o utw ard  t o  r e m ove
 I n sta lla tio n: I n se rt  r o ta ry  r o d  ( 3 ) in to  d o or
l o ck a ctu atin g  m ech an is m
3P ull  h a nd le  ( 1 ) to w ard  r e a r t o g eth e r w it h  b ase
( 4 ) o ut o f  b e arin g  b ra cke t ( 8 )
4R em ove  b a se  ( 5 )
 I n sta lla tio n: I n se rt  b a se    ( 5 ) in to  b e a rin g
b ra cke t  ( 8 )
5 .1R em ove  b e arin g  b ra cke t  ( 8 )
 O nly  if   b e arin g b ra cke t  is  d efe ctiv e . T he
b ea rin g  b ra ck e t ( 8 ) c a n o nly  b e  r e m ove d
t h ro u gh th e in sta lla tio n  o pe nin g in  t h e in n er
d oo r p an el.  F or th is  p urp ose
#
R em ove  d oor lin er o n  f r o nt d oo r
A R 72 .1 0 -P -1 0 00 G H
6In sta ll   in  o pp o sit e  o rd e r
7A dju st  c le ara nce  b etw ee n  h an d le  ( 1 ) a n d
a ctu atin g  le ve r o n d oor lo ck  w it h  e cce n tr ic
a dju stm en t  s cre w
E cce ntr ic  a dju stm en t  s cre w :
Acce ss ib le  th ro u gh o p enin g  o n e n d  o f  d o or.
U se  P hillip s s c re w driv e r
8C heck  f o r p ro p er f u n ctio n
 F ro nt d o or
C op yrig ht  D aim le rC hry sle r A G   0 3.0 9 .2 005  C D-A usg a be G /1 0 /0 4  . T his  W IS  p rin t- o ut  w ill  n ot b e r e co rd ed  b y M odif ic a tio n s e rv ic e s. Page  1


        Page 2128 of 4133
 Num berD esig natio nM odel  1 6 3
B A72 .1 0 -P -1 00 3-0 1 DS cre w  fo r d o or h a nd leN m3
C opyrig h t  D aim le rC hry sle r A G   0 3.0 9.2 005  C D-A usg ab e G /1 0/0 4 .  T his  W IS  p rin t- o ut  w ill  n ot b e r e co rd ed  b y M odif ic a tio n s e rv ic e s. Page  2
