Page 3177 of 4133

to burn or are part of a smoldering fire.
The scrapping of gas-filled hydraulic parts can also be handed over to a scrap dealer who carries out the
required safety measures. If accepted, the scrap dealer must sign an official declaration (see sample), in which
he/she is bound to scrap gas-filled hydraulic parts in accordance with the respective valid accident prevention
regulations.
This type of agreement however does require that it is absolutely impossible to retrieve shock absorbers from
the scrap which can then be subsequently repaired. Any such devices therefore need to be damaged to
permanently disable them for any reuse. To this end it is sufficient to bang the shock absorber pipe on a hard
edge, to make a dent in it with a light hammer blow or to crush it slightly in a vise.
 On no account should the piston rod be bent, this may cause an accident!
If agreements to render gas-filled hydraulic parts harmless, cannot be made with a scrap dealer, then the
specified safety measures must be performed by the owner. For accident prevention reasons, safety glasses and
gloves must be worn as protection against any escaping gas and oil as well as drill shavings. The balance holes
are to be drilled with as little operating speed as possible. Any escaping oil is to be collected.
Fig. 647: Sheet Metal And Metal Scrap Declaration Form

2004 Mercedes-Benz ML350
1998-2005 GENINFO Overall vehicle - 163 Chassis
me
Saturday, October 02, 2010 3:47:57 PMPage 532 © 2006 Mitchell Repair Information Company, LLC.


        Page 3178 of 4133
 AR68.10-P-1400GI
Remove/install glove compartment
22.4.99
MODEL
163.136 /154 /172 #A as of 145273,
163.136 /154 /172 #X as of 708319,
163.113 /128 /157 /174 /175
P68.10-2330-06
1
 Glove compartment lid
2
 Screws
3
 Glove compartment
4
 Instrument panel
5
 Spreading rivets
E13/1
 Glove compartment lamp

Remove/Install
1
Open glove compartment lid (1)
2
Unclip glove compartment lamp (E13/1) and
disconnect connector
3
Unscrew bolt (2)
 Torx bit set
*000589011000
4
Remove upper spreading rivets (5) from glove
compartment (3)
 Press pressure pin approx. 4 mm upward
and remove spreading rivet downward.
5
Pull glove compartment (3) out of instrument
panel (4)
6
Install in the reverse order
 Align upper edge of glove compartment lid
(1) in relation to instrument panel (4).
Torx bit set
000 589 01 10 00
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 3179 of 4133
 AR68.10-P-1300GH
Adjust glove compartment lid
4.2.97
MODEL
163.136 /154 /172 #A up to 145272
P68.10-0517-06
1
Glove compartment lid
2
 Instrument panel
3
 Screws
4
 Striker eye
5
 Hinge screw
6
 Hinge
Arrows
 Air gap and adjustment possibilities
on hinge
Adjusting

During entire operation pay attention to
uniform transition, gap and adjustment
possibilities on hinge (arrows) between glove
compartment lid (1) and instrument panel (2).
1
Loosen screws (3) on striker eye (4)

Installation:
  Adjust transition at top of
striker eye (4).Glove compartment lid (1)
should make slight contact to stop buffers.
2
Remove glove compartment
AR68.10-P-1400GH
3
Adjust gap
 For this purpose loosen hinge screw (5)
from hinge (6).
4
Install glove compartment
AR68.10-P-1400GH
5
Check for easy motion and proper function
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 3180 of 4133
 AR68.10-P-1300GH
Adjust glove compartment lid
4.2.97
MODEL
163.136 /154 /172 #A up to 145272
P68.10-0517-06
1
Glove compartment lid
2
 Instrument panel
3
 Screws
4
 Striker eye
5
 Hinge screw
6
 Hinge
Arrows
 Air gap and adjustment possibilities
on hinge
Adjusting

During entire operation pay attention to
uniform transition, gap and adjustment
possibilities on hinge (arrows) between glove
compartment lid (1) and instrument panel (2).
1
Loosen screws (3) on striker eye (4)

Installation:
  Adjust transition at top of
striker eye (4).Glove compartment lid (1)
should make slight contact to stop buffers.
2
Remove glove compartment
AR68.10-P-1400GH
3
Adjust gap
 For this purpose loosen hinge screw (5)
from hinge (6).
4
Install glove compartment
AR68.10-P-1400GH
5
Check for easy motion and proper function
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 3181 of 4133
 AR68.10-P-1400GH
Remove/install glove compartment
4.2.97
MODEL
163.136 /154 /172 #A up to 145272
P68.10-0515-05
1
Striker eye
2-7
 Screws
8-9
 Stop buffer
10
 Glove compartment
E13/1
 Glove compartment lamp

Remove/Install
1
Open glove compartment lid
2
Unclip glove compartment lamp (E13/1) and
disconnect connector
3
Remove striker eye (1)

Installation:
  Check adjustment.Refer to:
#
Adjust glove compartment lid.
AR68.10-P-1300GH
4
Unscrew screws (2-7)
5
Pry glove compartment (10) out of arrest at
bottom and pull out
6
Install in the reverse order
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 3182 of 4133

 AR68.10-P-1220GH
Disassembling and assembling glove compartment lid
4.2.97
MODEL
163.136 /154 /172 up to 31.8.99
P68.10-0518-06
1
Stop lever
2
 Inner section
3
 Screw for catch
4
 Glove compartment catch
5
 Screw for inner section
6
 Insert
7
 Glove compartment lid
8
 Hinge
9
 Spring for catch
10
 Pin for catch

Disassembly, assembly
1
Remove glove compartment lid
AR68.10-P-1200GH
2
Unclip stop lever (1) from inner section (2)
3
Remove hinges (8) on inner section (2)
 Remove hinge pins
4
Unscrew screws (3) from lock (4)
5
Unscrew screws (5) from glove compartment
inner section (2)
 5 each.
6
Remove inner section (2)
7
Remove insert (6) from inner section (2)
8
Unhook glove compartment catch (4) and
spring (9)
9
Remove glove compartment catch (4) from
glove compartment lid (7)
 Drive out pin (10).
Installation:
 Observe installation position for
spring (9).
10
Install in opposite order
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 3183 of 4133
 GF54.30-P-2017A
HHT interface, location/task
7.7.99
MODEL
129, 140 as of 1.6.96,
163, 168, 170,
202 as of 1.8.96,
208 up to 31.7.99,
210 as of 1.6.96 up to 30.6.99
The instrument cluster has diagnostic capabilities. In other words,
diagnosis is possible using a hand held test (HHT). The instrument
cluster therefore has a line (K-line) which is connected to the data
link connector (X11/4).
 The instrument cluster, including the Active Service System
(ASSYST), is tested with the HHT. The following functions can be
selected:
D
 Control module version
D
 Error memory
D
 Actual valves
D
 Controls
D
 Manual transmission adaptation:
 - variant coding
- settings
Copyright DaimlerChrysler AG  05.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 3184 of 4133

 AD00.00-P-2000-03C
Connect hand-held tester (HHT), read out
diagnostic trouble code memory
Model 163 up to 31.08.01
Model 168
Workshop equipment/MB testers
 (see Workshop Equipment Manual)
WE58.40-Z-1001-06A
Hand-held tester (HHT), order number 6511 0001 99
WE58.40-Z-1002-06A
Test cable (multiplexer)
WE58.40-Z-1009-06A
Adapter cable (HHT) for test connector (X11/4, 16-pin), order number 6511 0090 99
P42.35-0234-06
1
Connect hand-held tester (087) to
diagnosis test connector (X11/4) in
interior using test cable (multiplexer)
(094) and adapter cable (107) .
2
 Switch on ignition.
3
 According to instructions in display :
a)
 Read out/erase fault memory
b)
 Read out actual values
c)
 Perform actuations
d)
 Program control modules
4
 Disconnect HHT.
087
 Hand-held tester (HHT)
094
 Test cable (multiplexer)
107
 Adapter cable (HHT) for datalink
connector (X11/4, 16-pin)
X11/4
 Diagnostic data link connector
 Note system-specific deviations listed in respective diagnosis
description in chapter entitled "Diagnosis Previous Knowledge".
 Stored faults possibly caused by cables being disconnected during
testing or by simulation must be erased from the fault memory once
the work is completed.
Copyright DaimlerChrysler AG  05.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1
