Page 3737 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual AR54.65-P-0002GH Remove/install Parktronic system (PTS) sensors in rear bumper 19.4.01 MODEL 163.113 /128 /154 /157 /174 /175 with CODE (220a) Parktronic System (PTS) P54.65-2412-06 1 Plug conne

Page 3738 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual AR67.10-P-1000-07P Prepare glue cartridge Commercially available tools (see Workshop Equipment Manual) Number Designation Make (e. g.) Order number WH58.30-Z-1015-20A Betapower II (2-component

Page 3739 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual BT27.50-P-0010-01A Piston B2 changed Transmission 722.6 phased in k TRANSMISSION 722.6## ## as of 0552036 as of 1.8.97 P27.60-2009-02 14d Sealing ring 27 Pistons To improve the piston guide

Page 3740 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual AR03.10-P-7311-01V Measure end clearance of piston rings Modification notes 12.6.02 Value in line 1001 for Engine 113.967 modified from 0.012...0.060 to 0.033...0.07 and from 0010...0.030 to 0

Page 3741 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual AR03.10-P-7311-02V Measure gap clearance of piston rings Test values for piston rings Number Designation Engine 112.910/ 911/912 Engine 112.920/ 921/922/923/940/ 941/942/943/944/ 945/946/947/94

Page 3742 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual AR03.10-P-7311BV Remove/install piston rings 2.7.97 ENGINE 113 in MODEL 129, 163, 202, 203, 208, 209, 210, 211, 215, 220, 230 ENGINE 112 /945, 113.962 /982 P03.10-2022-06 1 Compression ring (

Page 3743 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual BE03.10-P-1003-05B Dimension Plain compression ring mm 89.9 X 1.5 X 3.1 Taper-faced hook scraper ring mm 89.9 X 1.75 X 3.5 Test values for piston rings Number Designation Engine 113.944/ 980

Page 3744 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual AR03.10-P-7021AV Removing/installing pistons 2.7.97 ENGINE 112 ENGINE 112.945 in MODEL 463.209 /232 /233 /244 /245 /250 ENGINE 113.962 in MODEL 463.206 /240 /241 /247 /248 /249 /254 ENGINE
