Page 2105 of 4133
 GF54.30-P-2002A
Display instruments, location / task / function
24.10.96
MODEL
129, 140 as of 1.6.96,
163, 168, 170,
202 as of 1.8.96,
208 up to 31.7.99,
210 as of 1.6.96 up to 30.6.99
Display
Type of data transmission
D
 Outside temperature indicator (A1p4)
D
Fuel level gauge (A1p2)
D
Engine oil pressure gauge (A1p3), only
model 129 and model 140
D
  Low windshield washer fluid level
indicator lamp (A1e13), model 163 as of
01.09.01
Direct lines
GF54.30-P-3004A
D
 Total mileage odometer (A1h4)
D
Electronic speedometer (A1p8)
D
Tachometer (A1p5)
D
Coolant temperature gauge (A1p1)
D
Active service system (ASSYST)
D
Gear indicator (A1p12), only model 168
CAN data lines
GF54.30-P-3005A
D
Electronic clock
Internal
GF54.30-P-3011A
Copyright DaimlerChrysler AG  04.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2106 of 4133

 AD54.30-P-3000-03A
Display instruments/multi-function display
function check IC
Display

instruments
The display instruments must indicate according to operating
conditions.
Phototransistor (models 202, 208, 210)
Point a beam of light at the phototransistor with a pocket lamp, the
display illumination of the LCD displays (outside temperature, trip
odometer, total mileage recorder and electronic clock) must get
brighter.
Instrument cluster with multi-function display
If there are malfunctions (e.g. brake linings worn, coolant level too
low, exterior lamp failure etc.) or system faults (anti-lock brake
system faulty, supplemental restraint system faulty) the warning
display with warning information is inserted in place of outside
temperature, odometer, total mileage recorder and electronic clock.
The warning information is displayed in yellow or red depending on
the fault and a warning tone also sounds.
Copyright DaimlerChrysler AG  05.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2107 of 4133

 GF54.30-P-3028GH
Displaying coolant level, function
28.6.99
MODEL
163 as of 1.3.99
Function prerequisite
Engine: ON
Function
If the coolant level drops below the minimum mark the low ECL
indicator lamp (A1p11) is illuminated.
To record the coolant level the instrument cluster (A1) is connected
direct to the
 coolant level indicator electronic switch (S41)
  via two
cables. The
 coolant level indicator electronic switch (S41)
consists of two electrodes.
D
 If the
level is correct
  both electrodes are immersed in the
coolant. The coolant serves as a dielectric between the
electrodes.
D
 If the coolant level is below the minimum mark the electrodes of
the sensor are no longer immersed in the coolant. There is only
air between the electrodes as a dielectric. Evaluation
The instrument cluster (A1) sends test pulses to the sensor for
a period of one millisecond. These pulses are deformed
differently depending on the dielectric (air or coolant).
The instrument cluster (A1) evaluates the pulse shape and, if
the coolant level is below the minimum (electrodes are
completely in air), actuates the low ECL indicator lamp (A1p11)
after a delay of
 approx. 60 seconds
 .
The delay serves to prevent the indicator lamp flickering due to
the coolant moving from side to side on corners or off-road.
Diagnosis
Diagnosis is carried out, as described in the Diagnosis Manual, via
the simulation of the
 coolant level indicator electronic switch (S41)
by a resistance.
Coolant level switch,
location/task/design/function
GF54.30-P-4103GH
Copyright DaimlerChrysler AG  04.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2108 of 4133

 GF00.20-P-2010B
Displaying service, function
25.3.99
MODEL
129 as of 1.8.99
MODEL
 163 as of 1.1.00
MODEL
 168 as of 1.9.99
MODEL
 170 as of 1.12.99
MODEL
 202 as of 1.8.99
Display of service to be performed
In addition to the various service displays, the service work to be
performed (A or B) also appears.
The service symbol (wrench) appears once or twice in the display for
this purpose.
The service symbol appears
 D
 once
 for service
  A
D
 twice
 for service  B
.
A service A is always followed by a service B.
Following a service B, the next service must be calculated
taking into account the kilometer readings. If the distance of the
current service interval is less than 22 000 km, the next service
is service A, otherwise service B.
This calculation is now performed
 automatically
 in the
instrument cluster (A1).
The path of the service displayed A or B can be processed in
the service sheet without the need for a calculation.
There is no external difference in the instrument clusters with
and without the service display.
If service A (one service symbol) is displayed, it is then
necessary to ensure by means of the
 production date
or the
control unit identifier
 , that the vehicle in question is in fact a
vehicle
 with service display
 . If this is not the case, the service
must be determined as specified in the service sheet.
The table below shows from which control unit identifier the
instrument cluster features the service display:
The control unit identifier can be read with the HHT under menu point
"Control unit version".
 Model
Control unit identifier
129
2/04
163
3/04
168
3/20
170
2/23
202
0/20
Displaying remaining service function
GF00.20-P-2007A
Copyright DaimlerChrysler AG  05.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1


        Page 2109 of 4133
 AR82.20-P-0110GH
Removing and installing front dome lamp
13.3.97
MODEL
163
P82.20-0400-11
1
Overhead control panel
2
 Bulb
3
 Socket
4
 Dome lamp switch
5
 Screws
6
 Reflector housing

Removal, installation
1
Remove overhead control panel (1)
AR82.20-P-1100GH
2
Remove bulb (2)
3
Release socket (3) for bulb (2) by pressing in
 The bulb socket is clipped to the overhead
control panel.
4
Pull dome lamp switch (4) off of reflector
housing (6)
5
Unscrew screws (5) from reflector housing (6)
on left and right on overhead control panel (1)
6
Pry reflector housing (6) out of overhead
control panel (1)

Avoid damaging reflector housing
7
Reinstall in opposite order
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2110 of 4133

 AR72.10-P-2100GH
Remove/install door catch
11.2.97
MODEL
163.113 /128 /136 /154 /157 /172 /174 /175
P72.10-0483-01
1
Bolt
2
 Mount for seal
3
 Seal
4
 Bracket
5
 Door retaining strap
6
 Nut
P72.10-0484-01

Removing, installing
1
Remove door lining
Front door
AR72.10-P-1000GH
Rear door
AR72.12-P-1010GH
2
Pull foil off of inner door panel in front area
 Installation:
   Replace damaged foil.
3
Unscrew screw (1) on door retraining strap

Avoid damaging paint.
Installation:
 Apply glue to screw.
 *BR00.45-Z-1013-02A

*BA72.10-P-1001-01D

*BA72.12-P-1003-01C
4.1
Pull seal (3) off of door retaining strap (5)
Up to 08/99.
5
Close crank window
6
Unscrew nuts (6) from door retaining strap

 Hold door retaining strap to prevent it
from falling into the door

*BA72.10-P-1002-01D
7
Remove door retaining strap through
installation opening in inner door panel
  Pull rubber out of retaining clip at bottom
of window guide rail and move along door
catch.
Installation:
  Install window guide rail
correctly.
8
Install in the reverse order

Front door
Number
Designation
MODEL
Series 163
BA72.10-P-1001-01DBolt, door catch at A-pillar
Nm
24
BA72.10-P-1002-01D
Nut for door restraining strap on
inside of door
Nm
10

Rear door
Number
Designation
MODEL
Series 163
BA72.12-P-1003-01C
Screw for door catch on B-pillar
Nm
24
Auxiliary repair materials
Number
Designation
Order number
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2111 of 4133
 BR00.45-Z-1013-02A
Loctite 243 sealant
003 989 31 71
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 2


        Page 2112 of 4133

 AR72.10-P-2400GH
Removing and installing outer door handle on front door
12.2.97
MODEL
163
P72.10-0488-06
1
Handle
2
 Lock cylinder guide
3
 Rotating rod
4
 Base
5
 Base
6
 Screw
7
 Retaining strap
8
 Bearing bracket
9
 Screw
10
 Screw opening
Operation no. of operation texts or of standard texts and flat rates
 Division
Operation
 no.
Operation text
P
727240
REPLACING OUTER DOOR HANDLE ON LEFT FRONT DOOR
P
727241
REPLACING OUTER DOOR HANDLE ON LEFT FRONT DOOR, WITHOUT BEARING BRACKET
P
727242
REPLACING OUTER DOOR HANDLE ON LEFT FRONT DOOR, WITH BEARING BRACKET
P
727243
REPLACING OUTER DOOR HANDLE ON LEFT FRONT DOOR  (INCLUDING TRANSFERING LOCKING CYLINDER)
P
727265
REPLACING OUTER DOOR HANDLE ON RIGHT FRONT DOOR
P
727266
REPLACING OUTER DOOR HANDLE ON RIGHT FRONT DOOR, WITHOUT BEARING BRACKET
P
727267
REPLACING OUTER DOOR HANDLE ON RIGHT FRONT DOOR, WITH BEARING BRACKET
P
727268
REPLACING OUTER DOOR HANDLE ON RIGHT FRONT DOOR  (INCLUDING TRANSFERING LOCKING CYLINDER)

Removal, installation
1
Loosen screw (6)
 Accessible through opening (10) on inner
side of door, loosen screw (6) max. 5 turns

*BA72.10-P-1003-01D
2
Pull off cylinder guide (2) outward to remove

Installation:
  Insert rotary rod (3) into door
lock actuating mechanism
3
Pull handle (1) toward rear together with base
(4) out of bearing bracket (8)
4
Remove base (5)

Installation:
  Insert base  (5) into bearing
bracket (8)
5.1
Remove bearing bracket (8)
 Only if bearing bracket is defective. The
bearing bracket (8) can only be removed
through the installation opening in the inner
door panel. For this purpose
#
Remove door liner on front door
AR72.10-P-1000GH
6
Install in opposite order
7
Adjust clearance between handle (1) and
actuating lever on door lock with eccentric
adjustment screw
Eccentric adjustment screw:
Accessible through opening on end of door.
Use Phillips screwdriver
8
Check for proper function
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1
