 AR47.20-P-1070HBRemove/install fuel full-flow filter
21.11.97
ENGINE
611.960 /961 /962, 612.961 /963, 613.960 /961
P07.57-0222-12
Shown on Engine 611.960
1
 Fuel outlet line
2
 Fuel feed line
70
 Fuel full-flow filter
P47.20-2024-12
Illustrated on Engine 613.961
1
 Fuel feed line of fuel tank
2
 Fuel feed line to predelivery pump
3
 Fuel return line from rail
4
 Fuel return line to fuel cooler (fuel tank)
70
 Fuel full-flow filter

Remove/install


Danger!
Risk of explosion
  due to combustion,
 Risk
of poisoning
  due to inhalation and
swallowing of fuel
 Injury hazard
 due to skin
and eye contact with fuel
Fire, sparks, open flames or smoking
forbidden.
Pour fuels only into suitable and appropriately
marked containers.
Wear protective clothing when handling fuel.
AS47.00-Z-0001-01A
1
Remove trim panel of charge air distribution
pipe
Engine 611
AR01.20-P-5014-02A
Engine 612
AR01.20-P-5014-02B
Engine 613
AR01.20-P-5014-02C
*BA01.20-P-1003-01A
Copyright DaimlerChrysler AG  28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2594 of 4133

 2.1
Disconnect fuel lines (1,2) at main fuel filter
(70)
Engine 611

Collect escaping fuel.
 Pay attention to use of locking arm. Refer
to:
#
Separate fuel lines from engine, reconnect
AR47.25-P-1000-01A
2.2
Disconnect fuel lines (1,2,3,4) at main fuel
filter (70)
Engine 612, 613

Collect escaping fuel.
 Pay attention to use of locking arm. Refer
to:
#
Disconnect, connect fuel lines at engine.
AR47.25-P-1000-01A
3
Remove main fuel filter (70)

If the main fuel filter has been emptied, it
must be filled with fuel after being installed
before starting, the engine starts more easily.
*BA47.20-P-1001-02A
4
Install in the reverse order

Danger!
Risk of accident
  due to automatic starting-off
when engine is running.
 Injury hazard
 due to
crimped connection and combustion when
meshing during starting procedure or when
engine is running
Secure vehicle to prevent it from moving off
by itself.
Wear closed and close-fitting work clothes.
Do not grasp hot or rotating parts.
AS00.00-Z-0005-01A
5
Run engine and inspect fuel system for leaks
 Crankcase ventilation, cylinder head cover
Number
Designation
Engine
611.960/
961/962
Engine
612.961/
962/967
Engine
612.963
Engine
613.960/
961
BA01.20-P-1003-01A
Screw attaching cover panel to charge air
distribution pipe
Nm
10101010

Fuel filter
Number
Designation
Engine
611.960/
961
Engine
611.962
Engine
612.961/
963
Engine
613.960/
961
BA47.20-P-1001-02A
Bolt of fuel filter to charge air distribution pipe
Nm
14141414
Copyright DaimlerChrysler AG  28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 2


        Page 2595 of 4133

 AF54.30-P-2064A
Fuel gauge not registering correctly after refueling vehicle
4.2.03
MODEL
163.### #A as of 221506 up to 364039,
163.### #X as of 734088 up to 777100
Operation no. of operation texts or standard texts and flat rates
Sector
Op. no.
Operation text
Time
Acc. no.
Code
P
023803
RECODE INSTRUMENT CLUSTER
003 WU/0.3 h
54 208 50
---
Damage Code
Cause
Remedy
Refuel recognition software may not
recognize incremental refueling (< 7 L).
 In case of complaint
#
 The fuel gauge operation defaults to back-
up mode, and continuously decreases last
stored sensor value based on consumption
data supplied via engine management. This
continues until either refuel recognition or
instrument cluster (A1) reset occurs (via
STAR Diagnosis or power disconnect).
Vehicles with 83 L fuel tank (as of MY2002)
are more susceptible to this condition.
This applies only to instrument clusters
(A1) with diagnostic version 3/05, 3/06,
and 3/07.
1
 Connect STAR Diagnosis.
2
Under "Control module adaptations" in
"ICM" menu, set "Fuel tank characteristic
curve" from "Normal" to "Direct sensor
value".

DO NOT replace the instrument cluster
(A1) or fuel pump assembly (M3) for this
condition.
Copyright DaimlerChrysler AG  28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2596 of 4133

 AR47.10-P-7000GI
Remove/install fuel level sensor
21.2.01
MODEL
163.113 with ENGINE 612.963
MODEL
 163.128 with ENGINE 628.963
P47.10-2128-06
1
Rear seat console
2
 Left C-pillar cover
4
 Wiring harness
5
 Seat retaining cable
P47.10-2083-09
3
 Housing
84
 Closing cover
89
 Union nut
6
 Seal
90/10
 Fuel intake line
 90/11
Fuel-return line
90/12
 Fuel feed line
90/13
 Stationary heater connection
B4
 Fuel level gage sensor

Remove, Install
 Danger!
Risk of explosion
  from fuel igniting,
risk of
poisoning
  from inhaling and swallowing fuel
as well as
 risk of injury
  to eyes and skin
from contact with fuel.
Fire, sparks, naked flame and smoking
prohibited.
Pour fuels only into suitable and appropriately
marked containers
Wear protective clothing when handling fuel
AS47.00-Z-0001-01A
1
Drain fuel
 Fuel tank must not be filled to more than
3/4. If fuel tank is full, drain at least
23 liters of fuel.
AR47.10-P-4000GH
 Pay attention to filling capacity of fuel tank.
*BF47.10-P-1001-01A
Copyright DaimlerChrysler AG  28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2597 of 4133

 2
Remove covers at seat frame of 60% bench
seat
 As of VIN A145273, X708319.
AR91.12-P-1100GH
 Only remove the covers which are
identified in the document with A, D and E.
3
Fold 60% bench seat forward into footwell
 As of VIN A145273, X708319. See
operator's manual.
4
Pull floor covering below rear seat mounting
bracket (1) of 60% seat forward
 Ensure that the floor covering is not torn
when pulled forward.
 As of VIN A145273, X708319.
5
Pull floor covering below front corner of trim
panel of C-pillar (2) forward
 Ensure that the floor covering is not torn
when pulled forward.
 As of VIN A145273, X708319.
6
Cut into floor covering directly behind seat
retaining cable (5)
 Ensure that the wiring harness (4) is not
damaged when cutting into floor covering.
 As of VIN A145273, X708319. broken line
marks cut-in.
7
Turn back floor covering to gain access to
cap (84)

Do not kink floor covering.
8
Remove cap (84)

Cap (84) is sealed in with body sealer.
Heat with hot air blower to make it easier to
remove.

Installation:
 Replace cap and install with
new sealing compound.
9
Detach fuel feed line (90/12) and fuel return
line (90/11) and, if fitted, the fuel line at
connection (90/13)

Do not kink the fuel lines.

If no stationary heater is fitted to vehicle,
do not remove connection (90/13) otherwise
housing will be damaged.
*163589003700
10
Remove nut (89)
*163589010700

*BA47.20-P-1006-01B
11
Remove housing (3)
 Fuel lever sensor and housing are a
single part and cannot be removed separately.

Installation:
  Re-install nut (89) together
with seal (89/2).
Apply a thin film of oil to seal.
12
Install in the reverse order

Fuel pump
Number
Designation
Engine 612Engine 628
BA47.20-P-1006-01B
Union nut for fuel tank sensor on fuel
tank
Nm
6565

Fuel tank
Number
Designation
Models
163.113/
136/154/
172 up to
31.08.01
Model
163.113/
136/154/
172 as of
01.09.01

Model
163.157/
175
Model
163.128
BF47.10-P-1001-01A
Fuel tank capacity
Total capacity
Liter
728383
Reserve capacity
Liter
101212
Copyright DaimlerChrysler AG  28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 2


        Page 2598 of 4133
 163 589 01 07 00
Claw-type wrench
Pliers
163 589 00 37 00
Copyright DaimlerChrysler AG  28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 3


        Page 2599 of 4133

 AR47.25-P-1000-01A
Separate fuel lines from engine, reconnect
P47.25-0212-03
1
Release arm
2
 Sealing ring
A
 Release position
B
 Assembly position
P47.25-0213-03
 The low pressure lines of the fuel system have plug connections
with a release arm (1) in place of screw connections.
The lines are sealed by means of a seal (2).
Disconnecting
 1
 Press the release arms (1) down to the stop in release position
as shown in picture A (arrow).
2
 Disconnect connector on low-pressure line.
3
 Pull back the release arms (1) again immediately to the stop
into the assembly position as shown in picture B (arrow).
 The release arms (1) must not be kept over a long period in
the release position (A) otherwise leaks can occur due to
deformation of the low-pressure line.
 Attaching
4
 Check whether the release arm (1) is in the installed position
(b).
 If the release arms (1) were kept for a long time in the
release position (A) the low-pressure line must be replaced
otherwise leaks can occur due to deformation of the low-
pressure line.
5
 Insert connector on low-pressure line.
6
 Ensure that the connector is firmly seated and free of leaks.
Copyright DaimlerChrysler AG  28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 2600 of 4133

 AR47.10-P-4000GH
Empty fuel tank if fuel pump is faulty
28.10.97
MODEL
163.113 with ENGINE 612.963
MODEL
 163.128 with ENGINE 628.963
MODEL
 163.136 with ENGINE 111.977
MODEL
 163.154 with ENGINE 112.942
MODEL
 163.157 with ENGINE 112.970
MODEL
 163.172 with ENGINE 113.942
MODEL
 163.174 with ENGINE 113.981
MODEL
 163.175 with ENGINE 113.965
P47.20-2076-06
