Page 2065 of 4133

SI54.50-P-0001A
Service Information: Compass in trip computer
22.10.00
MODELS
163.113 /154 /172 as of 1.9.00,
163.128 /157 /174 /175 with CODE (245) Trip computer
The compass is calibrated in the factory in order to compensate
for deviations caused by magnetic field intensity of the vehicle and
magnetic interference when operating the heated rear window.
Once the compass is calibrated, it never needs to be recalibrated
under normal operating conditions. If a strong deviation in magnetic
field intensity is detected, the compass automatically recalibrates
itself.
A calibration must be carried out if the compass is replaced.
Additionally, the user can fine tune the compass in order to adapt
it to the vehicle's surrounding area. By setting the respective
compass zone, the compass compensates for deviations in the
earth's magnetic field.
The calibration should take place at least 10 m from any source of
interference such as power lines, buildings and parked vehicles.
Zone setting
1
Press the MODE button on the trip computer
until the compass direction is displayed
2
Press the RESET button once
The current compass zone is displayed
3
Press the RESET button until the desired
compass zone is displayed
The maps for determining the correct
compass zone can be found in the owner's
manual. If the RESET button is not pressed
within 5 seconds, the point of the compass is
displayed again.
Compass calibration
4
Bring the compass to the compass zone
display mode
5
Press the MODE button once
Display shows
CAL-
on.
6
Press the RESET button for at least 2 seconds
The hyphen (
-
) in the display disappears.
The calibration mode is active and remains
active until the calibration process has
concluded. If the ignition is switched off and
on, calibration mode remains active, even if
CAL
no longer is displayed.
7
Drive two complete circles at a speed of
between 5 - 10 km/h
Heated rear window switched off.
8
Switch heated rear window on
9
Drive three full circles at a speed from 5 - 10
km/h.
Calibration process concluded.
Although the display can change from
CAL
to
the point of the compass before the
calibration drive has been concluded, the
calibration process is still active and must be
carried out exactly as described.
Copyright DaimlerChrysler AG 18.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 2066 of 4133

GF54.30-P-2004A
Control buttons, location/task
24.10.96
MODEL
129, 140 as of 1.6.96,
163, 170
The instrument cluster has two control buttons which are on the left
or right next to the speedometer.
The
right control button
is used to adjust the time (refer to Owner's
Manual).
-----------------------------------------------------------------------------------------
The
left control button
is used
D
to regulate the instrument illumination
D
to activate the display illumination
D
to reset the trip odometer display
D
to operate the maintenance display (model 170 only bis 05.97)
D
to operate the Active Service System ASSYST (as of 06.97)
-----------------------------------------------------------------------------------------
n
Purpose/function of terminal 58d, instrument
display illumination
Engines 112, 113, 611 (engines with oil
sensor)
GF54.30-P-3008A
n
Electronic clock
GF54.30-P-3011A
n
Active Service System (ASSYST)
GF00.20-P-0003-01A
Operating instructions, resetting
Model 210 as of 01.03.97 with engines M111,
OM 602, OM 604, OM 605 and
OM 606
As of 06/97 models 129, 140, 170, 202 except
engines 112, 113, 611
(valid for engines with oil level switch)
GF00.20-P-0003-01B
Copyright DaimlerChrysler AG 05.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 2067 of 4133

GF72.29-P-2002GH
Convenience control, function
7.4.97
MODEL
163
The convenience control allows the driver to operate the electrical
seat adjustment, the power windows, the electric vent windows, the
electric outside rearview mirror as well as the electric sliding/pop-up
roof or the electric lamella sliding roof
when the ignition is switched
off.
To achieve this, the all-activity module (AAM) (N10) switches to the
corresponding loads via the convenience relay (F1k14)
circuit 30 .
As of 12.99 the vehicle is equipped with its own convenience relay for
seat adjustment (relay 1, F2k1). In addition the status of the
convenience control via CAN is transmitted to the extended activity
module (EAM, N10/1).
Conditions for control actuation
On all-activity module (AAM) (N10) configured for
I
up
to
11.99:
The convenience actuation becomes active as soon as
D
Circuit 15 ON is recognized
When circuit 15 is switched off, the convenience actuation is
deactivated after a door is opened
Otherwise
The convenience actuation is active in the following cases:
D
Circuit 15c ON
D
A front door is open
D
The remote control key is removed, however, the doors are not
yet opened
In both cases the convenience actuation remains active for 5 min.
Switch-on condition for circuit 15c
When the remote control key is inserted into the ignition lock, circuit
15c is switched on when the key is turned out of the zero position.
Circuit 15c switches off only after the remote control key is removed
from the ignition lock
Electric seat adjustment without memory,
function
GF91.29-P-0003GH
Electric seat adjustment with memory, function
as of 12.99
GF91.29-P-0002GH
Convenience control, function
for electrical seat adjustment as of 12.99
GF91.29-P-2013GK
Power windows, function
GF72.29-P-0003GH
Power tilting/sliding roof (SR), function
GF77.20-P-0001GH
Electrically adjustable outside rearview
mirrors, function
GF88.79-P-0005GH
Electric vent windows, function
GF67.39-P-1000GH
Extended activity module,
location/purpose/design
as of 12.99
GF54.21-P-4107GK
Copyright DaimlerChrysler AG 04.08.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 2068 of 4133

AR20.00-P-1142M
Drain, pour in coolant
8.11.99
ENGINE
612.963 in MODEL 163.113
P20.20-2083-12
1
Front noise encapsulation bottom part
2
Radiator
3
Radiator drain tap
4
Siphon hose
Draining
Danger!
Risk of injury
to
fingers being jammed or
pinched
when removing, installing or aligning
hoods, doors, trunk lid/tailgate or sliding roof.
When moving components, ensure that no
body parts or limbs are within the operating
range of moving parts.
AS00.00-Z-0011-01A
Danger!
Risk of injury
to skin and eyes suffering
scalding from contact with hot coolant spray.
Risk of poisoning
from swallowing coolant.
Do not open cooling system unless coolant
temperature is below 90 °C. Open cap slowly
and release the pressure. Do not pour coolant
into beverage bottles.
Wear protective gloves, protective clothing
and eye protection.
AS20.00-Z-0001-01A
1
Open engine hood and raise to vertical position
Have assistant secure hood.
AR88.40-P-1000GI
2
Open cap of coolant expansion reservoir
Turn cap half a turn in the anti-clockwise
direction, release pressure, and then unscrew
cap.
3
Remove front noise encapsulation bottom
part (1)
4
Attach siphon hose (4) to drain connection of
radiator
5
Drain coolant at radiator (2) on right
To do this, turn drain tap (3) at radiator (2)
into position "1" (arrow).
Disposal of coolants.
Pay attention to legal provisions or local
wastewater regulations!
Refer to Environmental Protection Catalog
issued by MBVD/PWU for locations in
Germany.
6
Clean cooling and heating system
Clean cooling and heating system in case
of impurities. See
#
Remove oil from cooling and heating system.
AR20.00-P-1250B
Pour in
Notes on coolant
All engines
AH20.00-N-2080-01A
7
Turn drain tap (3) at radiator (2) into position
"0" (arrow)
Copyright DaimlerChrysler AG 12.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 2069 of 4133

Danger!
Risk of accident
caused by vehicle starting
off by itself when engine is running.
Risk of
injury
caused by contusions and burns when
working in engine during starting procedure
Secure vehicle to prevent it from moving.
Wear closed and snug-fitting work clothes.
Do not grasp hot or rotating parts.
AS00.00-Z-0005-01A
8
Pour in coolant
Warm up engine by running at moderate
revs. Top up coolant constantly at coolant
expansion reservoir. Close coolant expansion
tank once
coolant temperature is 60-70 °C.
*BF20.00-P-1001-02E
Note on coolant level
Model 124, 129, 140, 163.113, 168, 170, 202,
208, 210, 220, 463
AH20.00-P-1142-01A
9
Inspect cooling system for leaks
AR20.00-P-1010HA
Cooling system
Number
Designation
Engine
612.963
BF20.00-P-1001-02E
Cooling system
Total capacity
Liter
Y
11.0
Filling capacity of anticorrosion/
antifreeze agent down to
-37 °C
Liter
Y
5.5
Filling capacity of anticorrosion/
antifreeze up to -45 °C
Liter
Y
6.25
Specifications for Operating
Fluids
SheetBB00.40-P-0310-01A
SheetBB00.40-P-0325-00A
Copyright DaimlerChrysler AG 12.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 2
Page 2070 of 4133

AR20.00-P-1142HA
Draining and pouring in coolant
2.4.93
ENGINE
112 in MODELS 129, 163, 202, 208, 210, 211.061 /065 /261 /265 /080 /280 /082 /282, 220, 230.467
ENGINE
113 in MODELS 129, 163, 202, 208, 210, 211.070 /083 /283, 215, 220
ENGINE
113.962 in MODELS 463.206 /240 /241 /247 /248 /249 /254
ENGINE
112.945 in MODELS 463.209 /232 /233 /244 /245 /250
ENGINE
137 in MODELS 215, 220
ENGINE
113.982 in MODELS 463.241 /243 /246
P20.00-0215-06
Illustrated on model 202
1
Coolant expansion reservoir
2
Cooling system cap
3
Radiator drain plug
3a
Drain hose (inner diameter 12 mm)
4
Crankcase drain plug
4a
Drain hose (inner diameter 14 mm)
P20.00-2045-06
Shown on model 215 with M137
1
coolant expansion reservoir
2
Cooling system cap
3
Radiator drain plug
3a
Drain hose (inner diameter 12 mm)
Draining
Danger!
Risk of injury
to skin and eyes suffering
scalding from contact with hot coolant spray.
Risk of poisoning
from swallowing coolant.
Do not open cooling system unless coolant
temperature is below 90°C. Open cap slowly
and release the pressure. Do not pour coolant
into beverage bottles.
Wear protective gloves, protective clothing
and eye protection.
AS20.00-Z-0001-01A
Notes on coolant
All engines
AH20.00-N-2080-01A
Copyright DaimlerChrysler AG 12.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 2071 of 4133

1
Open cooling system cap (2) on coolant
expansion reservoir (1)
Cap with detent:
Turn cap carefully as far as the first detent,
release pressure, and then unscrew cap.
2-stage and 1-stage cap: Rotate cap half
a revolution in a counterclockwise direction,
release overpressure, then unscrew cap.
2.1Remove engine compartment paneling
Models 129, 202, 208, 210
AR61.20-P-1105AB
Models 163.172/ 174/ 175
AR61.20-P-1105GH
Models 163.113/ 128
AR94.30-P-5400GH
Model 211
AR61.20-P-1105T
Models 215, 220
AR61.20-P-1105M
Model 230
AR61.20-P-1105R
2.2Remove underride guard
Only on model 463
3.1
Remove air guide
Only on model 163 with engine 113.942
4
Drain coolant
Model 163: For draining coolant, detach
bottom coolant line at radiator or at coolant
pump.
Collect coolant Observe regulations for
disposal of coolant.
Installation:
On model 163 replace
radiator connection of hose clamps to coolant
hose, otherwise this can cause a damage to
the bolt/thread.
Hose clamp
*BA20.20-P-1004-01A
Pouring in
5
Pour in coolant
All except engine 137
*BF20.00-P-1001-02K
Engine 137
*BF20.00-P-1001-02M
Notes on coolant level
Engines 112, 113, 137, 275, 285
AH20.00-P-1142-01V
Notes on coolant level
Model 163 with engines 111, 112, 113
AH20.00-P-1142-01GH
6
Bleed cooling system
Let engine run, put heater on full heat
output.
Except stationary heater, code 228
AR20.00-P-1142-06GA
With stationary heater code 228
7
Inspect cooling system for leaks
AR20.00-P-1010HA
Radiator, coolant hoses
Number
Designation
Engines
112.942/
970,
113.942/
965/981
BA20.20-P-1004-01A
Hose clamp
Nm
3
Designation
Engines
112.910 /920
in model 202,
112.940
in model 208
Engines
112.911/921/941
in model 210
Engines
112.922/944/972
in model 220
BF20.00-P-1001-02K
Cooling system
Total capacity
Liters
Y
9.5
Y
10.0
Y
10.5
Capacity of
anticorrosion/antifreeze agent
down to -37°C
Liters
Y
4.75
Y
5.0
Y
5.0
Capacity of anticorrosion/
antifreeze agent down
to -45°C
Liters
Y
5.25
Y
5.5
Y
5.5
Specifications for Operating
Fluids
SheetBB00.40-P-0310-01ABB00.40-P-0310-01ABB00.40-P-0310-01A
SheetBB00.40-P-0325-00ABB00.40-P-0325-00ABB00.40-P-0325-00A
Copyright DaimlerChrysler AG 12.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 2
Page 2072 of 4133

Cooling system
Number
Designation
Engines
112.923/943
in model 129
Engine
112.945 in
models 463.209/
232/233/244/
245/250
Engine 112.942
in models 163,
113.940/980
in models 210,
113.943/984
in model 208,
113.944
in model 202
BF20.00-P-1001-02K
Cooling system
Total capacity
Liters
Y
11.75
Y
11.5
Y
11.0
Capacity of
anticorrosion/antifreeze agent
down to -37°C
Liters
Y
6.0
Y
5.8
Y
5.5
Capacity of anticorrosion/
antifreeze agent down
to -45°C
Liters
Y
6.5
Y
6.4
Y
6.0
Specifications for Operating
Fluids
SheetBB00.40-P-0310-01ABB00.40-P-0310-01ABB00.40-P-0310-01A
SheetBB00.40-P-0325-00ABB00.40-P-0325-00ABB00.40-P-0325-00A
Cooling system
Number
Designation
Engines
112.913/917/
949/954
in model 211
Engines
113.967/969
in model 211
Engine
113.990
BF20.00-P-1001-02K
Cooling system
Total capacity
Liters
Y
9.5
Y
10.75
Y
13.2
Capacity of
anticorrosion/antifreeze agent
down to -37°C
Liters
Y
4.75
Y
5.25
Y
6.6
Capacity of anticorrosion/
antifreeze agent down
to -45°C
Liters
Y
5.25
Y
6.0
Y
7.3
Specifications for Operating
Fluids
SheetBB00.40-P-0310-01ABB00.40-P-0310-01ABB00.40-P-0310-01A
SheetBB00.40-P-0325-00ABB00.40-P-0325-00ABB00.40-P-0325-00A
Cooling system
Number
Designation
Engines
113.941/960
in models 215,
220
Engine
113.961
in model 129
Engine 113.962
in modeld
463.206/
240/241
/247/248 249/254
BF20.00-P-1001-02K
Cooling system
Total capacity
Liters
Y
11.5
Y
12.75
Y
12
Capacity of
anticorrosion/antifreeze agent
down to -37°C
Liters
Y
5.75
Y
6.25
Y6
Capacity of anticorrosion/
antifreeze agent down
to -45°C
Liters
Y
6.25
Y
7.0
Y
6,6
Specifications for Operating
Fluids
SheetBB00.40-P-0310-01ABB00.40-P-0310-01ABB00.40-P-0310-01A
SheetBB00.40-P-0325-00ABB00.40-P-0325-00ABB00.40-P-0325-00A
Cooling system
Copyright DaimlerChrysler AG 12.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 3
