Page 2025 of 4133

AR68.20-P-2000GH
Remove/install center console
4.2.97
MODEL
163.113 /128 /136 /154 /157 /172 /174 /175
P68.20-0447-01 P68.20-0449-01 P68.20-0452-01
1
Housing
2
Screws
S21/15s1
Left rear power window switch
S21/15s2
Right rear power window switch
3
Screws
4
Screws
Remove, Install
1
Remove armrest cover from center console
AR68.20-P-2370GH
2
Remove cover on gearshift lever
Up to 31.08.01
AR68.20-P-2310GH
As of 01.09.01
AR68.20-P-2310GI
3
Unscrew screws (2) from front of housing (1)
4.1
Disconnect electrical connector on right and
left rear power window switches (S21/15s1
and S21/15s2)
Up to 31.08.01:
Remove wiring harness
from mount.
4.2
Disconnect connector from floor in center
console
Up to 31.08.01: Remove wiring harness
from mount.
5
Unscrew screws (4) from rear of housing (1)
6
Remove housing (1)
Set selector lever to position N
Installation:
As of 01.09.01, ensure that
air duct is installed tightly.
7
Install in the reverse order
Copyright DaimlerChrysler AG 09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 2026 of 4133
BT27.60-P-0001-01A
Center shift modified
Transmission 722.6 phased in
k
TRANSMISSION
722.6
P27.60-0372-12
97
Intermediate lever
112
Selector lever
116
Shift shaft
120
Shift detent
127
Pin
128
Shift gate
128a
Rubber stop
136
Locking lever
137
Sleeve with shift detent carrier
138
Pin
138a
Roller
138b
Circlip
The center shift has been modified to improve operating convenience
and dampen noise.
The intermediate lever (97) is rigidly connected to the shift shaft (116).
A sleeve (137) with locking lever (136) is arranged on the shift shaft in
such a way that it can move.
A roller (138a) attached to the shift detent carrier and two rubber stops
(128b) on the shift gate (128) dampen noise during the transverse
movement of the selector lever.
Copyright DaimlerChrysler AG 28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 2027 of 4133
AR40.10-P-1040-01A
Mounting centering sleeve
Commercially available tools
(see Workshop Equipment Manual)
Number
Designation
Make (e.g.)
Order number
WH58.30-Z-1003-18A
Centering sleeve DUO-FLEX 2
When ordering, state flange shaft diameter and model of balancing
machine
HAWEKA
D-30928 Burgwedel
16 100 8006
WH58.30-Z-1004-18A
Conversion kit
Hofmann
D-64319 Pfungstadt
6416 451
P40.10-0212-01
1
Because of the segment centering of the rims, the wheel balancing machines approved by
Mercedes-Benz must be used with a centering sleeve (arrow).
2
The centering sleeve ensures that the rim is mounted much more securely on the balancing
machine and eliminates balancing errors.
HAWEKA centering sleeve
P40.10-0213-01
Hofmann centering sleeve
Copyright DaimlerChrysler AG 06.07.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 2028 of 4133
GF80.20-P-0005-01GH
Central locking (CL), location of components
P80.20-0522-06
Location of components
1
Antenna
F1
Fuse and relay module
F1k15
CL rear door unlocking relay
F1k20
CL all door locking relay
F1k23
CL front right front door and rear
door unlocking relay
F1k24
CL front left front door and tank
flap unlocking relay
M14/5
Right front door CL actuating
motor
M14/6
Left front door CL actuating motor
M14/7
Tailgate CL actuating motor
M14/8
Left rear door CL actuating motor
M14/9
Right rear door CL actuating motor
M14/10
Filler flap CL actuating motor
N10
All-activity module (AAM)
Copyright DaimlerChrysler AG 17.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 2029 of 4133

AD80.20-P-6001-43GH
CL test of electrical system motor actuation
relay
t
A
Scope of test
Measuring instrument/
Test connection
Operation/Requirement
Specified value
D
Possible cause/Remedy
1.0
Central locking locks
everything
HHT actuation
A
All doors closed and
unlocked.
All doors and
fuel tank flap
are locked
D
Individual doors are not
locked:
t
1.1
D
No door is locked:
t
1.2
1.1
Central locking unlocks
everything
HHT actuation
A
All doors closed and locked.
All doors and
fuel tank flap
are unlocked
D
Left front door and fuel
tank flap are not unlocked:
t
1.3
D
Right front door and rear
doors are not unlocked:
t
1.4
D
Tailgate is not unlocked:
t
1.5
D
No door is unlocked:
Cables, N10
1.2
Central locking relay,
lock all doors (F1k20)
Function
Replace relay (F1k20) by
relay (F1k15),
Repeat test
t
1.0
All doors and
fuel tank flap
are locked
If test 1.0 in order:
D
Relay (F1k20)
otherwise:
D
Cables
1.3
Central locking relay,
unlock left door and fuel
tank flap (F1k24)
Function
Replace relay (F1k24) by
relay (F1k15), close and
lock left front door
A
Actuation of unlocking
left front door.
Left front door
is unlocked
Value in order:
D
Relay (F1k24)
Value not in order:
D
Cables
1.4
Central locking relay,
unlock right door and
rear doors (F1k23)
Function
Replace relay (F1k23) by
(F1k15), repeat test
t
1.1
All doors and
fuel tank flap
are unlocked
If the same fault pattern
emerges when test 1.1 is
repeated:
D
Cables
D
All-Activity Module (AAM)
(N10)
Tailgate is not unlocked:
D
Relay (F1k23)
1.5
Central locking relay,
unlock tailgate (F1k15)
Function
Replace relay (F1k15) by
(F1k23), close and lock
tailgate
A
Actuation of unlocking
tailgate
Tailgate is
unlocked
Value in order:
D
Relay (F1k15)
Value not in order:
D
Cables
Copyright DaimlerChrysler AG 17.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 2030 of 4133

AR09.41-P-6817MM
Removing and installing charge air cooler
10.11.99
ENGINE
612.963 in MODEL 163.113
P09.41-2024-09
1
Headlamp units
2
Cover strips
3
Front end crossmember
4
Socket at temperature sensor
9
Bolts
11
Socket
110/2
Charge air cooler
B17
Intake air temperature sensor
5
Right hose clamp
6
Left hose clamp
7
Charge air hose to charge air cooler
8
Charge air hose from charge air cooler
Operation no. of operation texts or standard texts and flat rates
Sector
Op. no.
Operation text
P
096810
REMOVING AND INSTALLING CHARGE AIR COOLER
P
096820
REPLACING CHARGE AIR COOLER
P
096827
REPLACING CHARGE AIR COOLER (COOLER REMOVED)
Removing, installing
Danger!
Risk of injury
from fingers becoming
jammed or bruised
when removing and
installing and aligning hood, trunk lid, doors,
lids and sliding roof
When moving components ensure that no
body parts or limbs are in the area of motion.
AS00.00-Z-0011-01A
1
Open engine hood and position upright
Have an assistant secure hood
AR88.40-P-1000GI
2
Remove headlamp units (1)
AR82.10-P-4730GH
3
Remove front end crossmember (3)
Place over engine with release cable
attached.
AR62.30-P-2300GH
4
Unplug socket (4) at intake air temperature
sensor (B17)
Do not release or lock temperature sensor
(B17) in place with socket plugged in
otherwise the locking arms will be over-
tensioned. Refer to:
#
Removing and installing intake air
temperature sensor.
AR07.52-P-1465A
5
Detach hose clamps (5, 6) of the charge air
hoses (7, 8) at the charge air cooler (110/2)
6
Unscrew bolts (9) at charge air cooler
7
Remove charge air cooler (110/2)
Detach from charge air hoses.
Traces of oil, slight quantities of oil in the
charge air hose come from the crankcase
ventilation and are permissible.
8
Install in the reverse order
Copyright DaimlerChrysler AG 12.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 2031 of 4133
9
Check headlamp adjustment and if necessary
correct.
e
Check and correct headlamp adjustment
MODEL 124, 129, 140, 163, 202
MODEL 170, 208, 210 except CODE (491)
USA version
AP82.10-P-8260A
10
Read fault memory, erase
Stored faults which can result from cables
being disconnected or from simulation during
removal and installation or test work, have to
be processed and erased in the fault
memories after completing the work. Refer to:
#
STAR DIAGNOSIS
Copyright DaimlerChrysler AG 12.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 2
Page 2032 of 4133

AR09.41-P-6817MM
Removing and installing charge air cooler
10.11.99
ENGINE
612.963 in MODEL 163.113
P09.41-2024-09
1
Headlamp units
2
Cover strips
3
Front end crossmember
4
Socket at temperature sensor
9
Bolts
11
Socket
110/2
Charge air cooler
B17
Intake air temperature sensor
5
Right hose clamp
6
Left hose clamp
7
Charge air hose to charge air cooler
8
Charge air hose from charge air cooler
Operation no. of operation texts or standard texts and flat rates
Sector
Op. no.
Operation text
P
096810
REMOVING AND INSTALLING CHARGE AIR COOLER
P
096820
REPLACING CHARGE AIR COOLER
P
096827
REPLACING CHARGE AIR COOLER (COOLER REMOVED)
Removing, installing
Danger!
Risk of injury
from fingers becoming
jammed or bruised
when removing and
installing and aligning hood, trunk lid, doors,
lids and sliding roof
When moving components ensure that no
body parts or limbs are in the area of motion.
AS00.00-Z-0011-01A
1
Open engine hood and position upright
Have an assistant secure hood
AR88.40-P-1000GI
2
Remove headlamp units (1)
AR82.10-P-4730GH
3
Remove front end crossmember (3)
Place over engine with release cable
attached.
AR62.30-P-2300GH
4
Unplug socket (4) at intake air temperature
sensor (B17)
Do not release or lock temperature sensor
(B17) in place with socket plugged in
otherwise the locking arms will be over-
tensioned. Refer to:
#
Removing and installing intake air
temperature sensor.
AR07.52-P-1465A
5
Detach hose clamps (5, 6) of the charge air
hoses (7, 8) at the charge air cooler (110/2)
6
Unscrew bolts (9) at charge air cooler
7
Remove charge air cooler (110/2)
Detach from charge air hoses.
Traces of oil, slight quantities of oil in the
charge air hose come from the crankcase
ventilation and are permissible.
8
Install in the reverse order
Copyright DaimlerChrysler AG 12.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
