Page 1073 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 269 Practical hints Replacing bulbs High beam bulbs 1High beam headlamp cover with lock- ing tab Switch off the lights.  Open the hood ( page 217).  Twist cover1 counterclockwise and remove.2Ele

Page 1074 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 270 Practical hintsReplacing bulbs Align headlamp cover and click into place. Fog lamp bulbs 1Fog lamp  Switch off the lights.  Use a suitable object (e.g. screwdriver) to press on the release le

Page 1075 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 271 Practical hints Replacing bulbs 7Tabs Squeeze tabs7 together and remove bulb holder.  Gently push bulb into socket, turn counterclockwise and remove.  Insert new bulb in socket, push in and

Page 1076 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 272 Practical hintsReplacing bulbs Insert reflector from the left so that it engages on the right.  Position tabs of cover in slots and rein- stall cover until properly seated. Adjusting headlamp a

Page 1077 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 273 Practical hints Replacing wiper blades Replacing wiper blades Removing Fold the wiper arm forward.  Turn wiper blade at a right angle to wip- er arm. 1Wiper blade 2Safety tab  Press safety tab

Page 1078 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 274 Practical hintsFlat tire Flat tireMounting the spare wheel Preparing the vehicle  Park the vehicle as far as possible from moving traffic on a hard surface.  Turn on the hazard warning flasher

Page 1079 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 275 Practical hints Flat tire  On wheel to be changed, loosen but do not yet remove the wheel bolts (ap- proximately one full turn with wrench). The jack take-up brackets are located di- rectly beh

Page 1080 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 276 Practical hintsFlat tireRemoving the wheel Unscrew and remove all wheel bolts.  Remove the remaining bolts.  Grip the wheel from the sides and re- move it. Mounting the new wheel  Clean contac
