Slacken cylinder head bolts (21) in stages,
unscrew
Loosen cylinder head bolts according to
loosening schematic only after engine has
cooled down to prevent cylinder head from
distorting.
AR01.30-P-5800-09B
Installation:
Observe tightening pattern
and tightening instructions of cylinder head
bolts.
Oil thread and head contact surface of
cylinder head bolts.
AR01.30-P-5800-07B
Screwdriver insert
*000589031000
Screwdriver insert
*000589041000
*BA01.30-P-1001-01D
30
Remove cylinder head
Installation:
On Engine 112/113 observe
porous points in the left and right cylinder
head. If porous points are present, sealant
must be applied to the cylinder head gasket.
Notes on application of sealant to cylinder
head gasket.
Engine 112, 113
AH01.30-P-1000-04VA
The sealant must be applied within
10 minutes.
Loctite 5900 sealant.
*BR00.45-Z-1015-01A
31
Inspect version of cylinder head gasket
Assignment of cylinder head gasket
Information for assigning the cylinder head
gaskets
Engine 112, 113
AH01.30-P-1000-06V
32
Check cylinder head bolts (21)
AR01.30-P-5800-03B
*BE01.30-P-1001-04B
33
Clean sealing surfaces, inspect for cracks,
shrink holes and flatness, clean threaded
holes.
Pay attention to dowel sleeves (26) for
locating the cylinder head.
Sealing surfaces of crankcase and
cylinder head are provided with an 0.8 mm
thick silicone layer during series production.
At the time of repair installation, silicone
sealant is applied to the sealing area only in
case of any shrink holes.
The sealant must be applied within
10 minutes.
Loctite 5900 sealant.
*BR00.45-Z-1015-01A
34
Install in the reverse order
Danger!
Risk of accident
caused by vehicle starting
off by itself when engine is running.
Risk of
injury
caused by contusions and burns when
working in engine during starting procedure
Secure vehicle to prevent it from moving.
Wear closed and snug-fitting work clothes.
Do not grasp hot or rotating parts.
AS00.00-Z-0005-01A
35
Run engine and inspect for leaks
36
Inspect cooling system for leaks
Warm up engine to operating temperature
and then inspect cooling system or leaks.
AR20.00-P-1010HA
37
Read out and erase fault memory
Stored faults which can result from cables
being disconnected or from simulation during
removal and installation or test work, have to
be processed and erased in the fault
memories after completing the work:
#
Diagnosis Manual Volume 2 Index 0:
Connecting and using test equipment.
Cylinder head/cylinder head bolts
Number
Designation
Engine
112.910/911/912/
913/914/915/
916/917/920/
921/922/923/
940/941/942/
943/944/945/
946/947/949/
951/953/954/
955/960/961/
970/972/973/975
Engine
113.940/941/
942/943/944/
945/946/948/
960/961/962/
963/965/966/
967/968/969/
980/981/982/
984/986/987/
988/990/991/
992/993
BE01.30-P-1001-04B
Cylinder head bolt
Thread diameter
M
1111
Length (L) when new
mm
141.5141.5
Length (L)
mm
T
144.5
T
144.5
Copyright DaimlerChrysler AG 20.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 5
Page 2098 of 4133

Fig., see
AR01.30-P-5800-03BAR01.30-P-5800-03B
Cylinder head
Number
Designation
Engine
112.910/911/912/
913/914/915/
916/917/920/
921/922/923/
940/941/942/
943/944/945/
946/947/949/
951/953/954/
955/960/961/
970/972/973/975
Engine
113.940/941/
942/943/944/
948/960/961/
962/963/965/
966/967/968/
969/980/981/
982/984/986/
992
BA01.30-P-1001-01D
Bolt of cylinder head to
crankcase
1st stageNm
1010
2nd stage
Nm
3030
3rd stage
(°
9090
4th stage
(°
9090
Crankcase, timing case cover, end cover
Number
Designation
Engine
112
except
112.951
Engine
113.940/941/
942/943/944/
945/946/948/
960/961/962/
963/965/966/
967/968/969/
980/981/982/
984/986/992
BA01.40-P-1002-01C
Bolt, cylinder head to timing case cover
Nm
2020
Camshaft
Number
Designation
Engine
112
except 112.951
Engine
113.940/941/
942/943/944/
948/961/962/
963/965/966/
967/968/969/
980/981/982/
984/986/992
BA05.20-P-1001-01B
Bolt of camshaft sprocket
M12 x 45
1st stageNm
5050
2nd stage
(°
9090
Fuel rail
Number
Designation
Engine
112 except
112.945/951/
960/961
BA07.52-P-1001-01A
Fuel feed line to fuel rail
Nm
38
Copyright DaimlerChrysler AG 20.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 6
Page 2099 of 4133
Fuel rail
Number
Designation
Engine
113.940/941/
942/943/944/
945/946/948/
960/961/962/
963/965/966/
967/968/969/
980/981/982/
984/986/988/
BA07.52-P-1001-01A
Fuel feed line to fuel distributor
Nm
38
Exhaust manifold
Number
Designation
Engine
112
except
112.951
Engine
113.940/941/
942/943/944/
945/946/948/
960/961/962/
963/965/966/
967/968/969/
980/981/982/
984/986/992/
993
BA14.10-P-1002-01B
Flange connection of exhaust manifold or front
exhaust pipes
Nm
2020
112 589 00 32 00 112 589 01 32 00
001 589 76 09 00 000 589 01 10 00
Locating plate
Torx bit set
External Torx set
Locating plate
112 589 01 03 00
Screwdriver insert
Insertion tool
Open-end wrench
Screwdriver insert
112 589 00 01 00000 589 03 10 00000 589 04 10 00
Copyright DaimlerChrysler AG 20.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 7
Page 2100 of 4133
001 589 72 21 00
Torque wrench
Pressure hose
119 589 04 63 00
Commercially available tools
(see Workshop Equipment Manual)
Number
Designation
Make (e. g.)
Order number
WH58.30-Z-1001-06A
6 mm socket hexagon on flexible shaft for hose clamps with worm drive
Hazet
Güldenwerther
Bahnhofstraße 25-28
D-42857 Remscheid
426-6
WH58.30-Z-1002-06A
7 mm hexagon socket wrench to flexible shaft for hose clips with worm
drive
Hazet
Güldenwerther
Bahnhofstraße 25-28
D-42857 Remscheid
426-7
Auxiliary repair materials
Number
Designation
Order number
BR00.45-Z-1015-01A
Loctite sealant 5970A 003 989 98 20 10
Copyright DaimlerChrysler AG 20.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 8
Page 2101 of 4133

AR01.20-P-5014-02B
Remove/install cylinder head cover trim
Crankcase ventilation, cylinder head cover
Number
Designation
Engine
612.961/
962/967
Engine
612.963
Engine
612.965/
966
Engine
612.990
BA01.20-P-1002-01A
Screw of trim panel of cylinder head cover
to cylinder head cover
NM
101010
8
BA01.20-P-1003-01A
Screw attaching cover panel to charge air
distribution pipe
NM
101010
-
P01.20-2018-11
1
Unscrew bolts (3, 4).
Installation:
Pay attention to tightening torques
.
2
Pull out trim panel (2) of charge air distribution pipe to the side.
Installation:
Insert shackles of trim panel (2) into the rubber
mounts (5), so that the trim panel (2) is not damaged.
3
Take off trim panel (1) of cylinder head cover.
Installation:
Ensure the trim panel is correctly installed; ensure
no lines are trapped.
4
Install in reverse sequence.
Illustrated on Engine 612.961
Copyright DaimlerChrysler AG 20.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 2102 of 4133
BT27.60-P-0003-01A
Deletion of lever for shift lock cable ignition
lock at transmission
k
TRANSMISSION
722.700 ## as of 0129631 as of 24.1.01,
722.701 ## as of 0132072 as of 8.2.01
P27.60-0421-01
1
Shift lock lever ignition lock
2
Shift lock lever brake pedal
Because of the deletion of the shift lock cable ignition lock the lever for the shift lock cable ign
ition
lock (1) at the transmission is likewise deleted.
Copyright DaimlerChrysler AG 28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 2103 of 4133
BT27.60-P-0001-02A
Deletion shift lock cable ignition lock to
transmission
k
TRANSMISSION
722.7 in MODEL WDB168.### ## as of 548031 as of 10.1.01
P27.60-2187-06
1
New ignition lock cable
2
Shift lock cable
For cost-saving reasons the shift lock cable of
the ignition lock to transmission is
discontinued. A cable from the ignition lock to
the brake pedal is used in its place.
Consequently, it is only possible to
withdraw the ignition key when the brake
pedal is depressed
.
The new ignition lock cable (1) does no
longer require to be adjusted.
Copyright DaimlerChrysler AG 28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 2104 of 4133

OF91.60-P-1000-01A
Disconnecting airbag, certificate
After the front passenger airbag or emergency tensioning retractor
has been deactivated it must be ensured that the declaration is
signed by the customer.
Reconnection should be stamped and signed on the declaration by
the Mercedes-Benz service station performing the work.
a mb
Declaration
after disconnecting front passenger airbag on request by customer
I have explicitly requested the operation of the passenger airbag and
the passenger emergency tensioning retractor with belt force limiter
to be deactivated.
I have been informed that due to this measure the additional passive
safety guaranteed by the front passenger airbag as well as the front
passenger emergency tensioning retractor with belt force limiter is no
longer available and thereby increases the injury hazard for the
passenger.
Particularly body regions such as head, neck and chest can be
affected by reduced restraint. Direct contact with passenger
compartment components can occur more probably.
I hereby forego all claims against DaimlerChrysler AG that arise from
the deactivation of the passenger airbag and the passenger
emergency tensioning retractor with belt force limiter, whatever the
legal reason for the claim.
Moreover, I acknowledge that I am obligated to indicate to
passengers, any subsequent owner of the vehicle or any person
using the vehicle that this protective function has been deactivated
as well as the associated hazards.
A sticker has been attached to the passenger airbag which may be
removed only when the passenger airbag is reactivated by a
Mercedes-Benz service station.
Disconnection is to be noted in the registration papers.
......................................................................
Date/signature of customer
.....................................................................
Date/stamp/signature/Mercedes-Benz service station
Customer address:
...........................................................................
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chassis ident no.:....................................................................
Reactivation of the passenger airbag should be accomplished only by
a Mercedes-Benz service station.
Reactivation:....................................................................
Date/stamp/signature/Mercedes-Benz service station
s
Copyright DaimlerChrysler AG 14.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
