1997 MERCEDES-BENZ ML320 Complete Repair Manual

alternator belt display tire size key fob change wheel fuel pressure

Page 3817 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR91.40-P-0630GH
Remove/install seat belt with emergency tensioning retractor
26.3.97

MODEL
163.113 /128 /136 /154 /157 /172 /174 /175

P91.40-0374-09

1
Cap

2
Bolt

3
Outer paneling
7

Automa

AR91.40-P-0630GH
Remove/install seat belt with emergency tensioning retractor
26.3.97

MODEL
163.113 /128 /136 /154 /157 /172 /174 /175

P91.40-0374-09

1
Cap

2
Bolt

3
Outer paneling
7

Automatic belt retractor

R12/2
Passenger ETR [GUS] ignition

squib

4

Belt end fitting

5
Screw

6
Screw

Remove/Install

Danger!

Risk of injury
when carrying out test or repair

work on airbag or emergency tensioning

retractor units
Store airbag unit with expulsion area on top,

do not subject to temperatures above 100 °C.

Interrupt power supply when working on such

units.

AS91.00-Z-0001-01A

Danger!

The spring in the inertia reel can pose an

injury hazard
when the tension is released

and it uncoils.
Never disassemble inertia reels

AS91.00-Z-0002-01A

Important instructions for performing repair,

body work and welding on vehicles with

airbags or belt tensioner units
Models 129 as of 1.7.93, 163, 168, 170, 202

as of 1.7.93, 208, 210, 414, 638, 690.6, 901,

902, 903, 904, 905

Model 461 with engine 602.983

Model 463 up to 30.11.00

MODELS WD141, WD241, WD341, WD641,

WD741, XD141, XD241, XD341, XD441,

XD541, XD641, XD741, YD141, YD241,

YD341, YD441, YD541, YD641, YD741

AH91.00-P-0002-01B

Evaluation of airbags and emergency

tensioning retractors on accident vehicles
Model 129 as of 1.7.93, 163, 168, 170, 202 as

of 1.7.93, 203, 208, 209, 210,

211.004/006/016/061/065/070, 215, 220, 230,

240, 414, 463, 638, 901, 902, 903, 904,905

Models WD141, WD241, WD341, WD641,

WD741, XD141, XD241, XD341, XD441,

XD541, XD641, XD741, YD141, YD241,

YD341, YD441, YD541, YD641, YD741

AH91.00-P-0006-01B

Legal regulations concerning the handling

and storage of airbag and emergency

tensioning retractors
Models 124, 129, 140, 163, 168, 170, 202,

203, 208, 209, 210,

211.004/006/016/061/065/070, 215, 220, 230,

240, 314, 316, 318, 414, 461, 463, 638, 668,

670, 690.6, 901, 902, 903, 904, 905, 950,

952, 953, 954, 970, 972, 974, 975, 976

Models WD141, WD241, WD341, WD641,

WD741, XD141, XD241, XD341, XD441,

XD541, XD641, XD741, YD141, YD241,

YD341, YD441, YD541, YD641, YD741

AH91.00-P-0004-01A

o

Notes on disposal of airbags and emergency

tensioning retractors
All models

OS91.00-P-0001-01A

Render emergency tensioning retractors

unusable

AR91.40-P-0611A

1
Move front seat forwards to the full extent, tilt

front seat backrest forwards

See owner's manual.

Copyright DaimlerChrysler AG 14.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

Page 3818 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 2
Withdraw ignition key

3
Unclip cap (1) from outer paneling (3)

4
Unscrew bolt (2) from belt end fitting (4)

*BA91.40-P-1001-01D

Torx bit set

*000589011000

5
Pull belt end fitting (4) out of

Page 3819 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR91.40-P-0681GI
Remove/install rear seat belts
16.4.99

MODEL
163.136 /154 /172 as of 1.9.99,

163.113 /128 /157 /174 /175

1
Bolt

2
Seat belt guide bracket

3
Bolt

4
Automatic belt retract

AR91.40-P-0681GI
Remove/install rear seat belts
16.4.99

MODEL
163.136 /154 /172 as of 1.9.99,

163.113 /128 /157 /174 /175

1
Bolt

2
Seat belt guide bracket

3
Bolt

4
Automatic belt retractor

5
Belt height adjuster

R12/7
Right rear ETR ignition squib

P91.40-2114-03

Remove/Install

Danger!

Risk of injury
when carrying out test or repair

work on airbag or emergency tensioning

retractor units
Store airbags with exit surface pointing

upward, do not expose to temperatures above

100 °C. Interrupt power supply when working

on such units.

AS91.00-Z-0001-01A

Danger!

The spring in the inertia reel can pose an

injury hazard
when the tension is released

and it uncoils.
Never disassemble inertia reels

AS91.00-Z-0002-01A

Important instructions for performing repair,

body work and welding on vehicles with

airbags or belt tensioner units
Models 129 as of 1.7.93, 163, 168, 170, 202

as of 1.7.93, 208, 210, 414, 638, 690.6, 901,

902, 903, 904, 905

Model 461 with engine 602.983

Model 463 up to 30.11.00

MODELS WD141, WD241, WD341, WD641,

WD741, XD141, XD241, XD341, XD441,

XD541, XD641, XD741, YD141, YD241,

YD341, YD441, YD541, YD641, YD741

AH91.00-P-0002-01B

Evaluation of airbags and emergency

tensioning retractors on accident vehicles
Model 129 as of 1.7.93, 163, 168, 170, 202 as

of 1.7.93, 203, 208, 209, 210,

211.004/006/016/061/065/070, 215, 220, 230,

240, 414, 463, 638, 901, 902, 903, 904, 905

Models WD141, WD241, WD341, WD641,

WD741, XD141, XD241, XD341, XD441,

XD541, XD641, XD741, YD141, YD241,

YD341, YD441, YD541, YD641, YD741

AH91.00-P-0006-01B

Legal regulations concerning the handling

and storage of airbag and emergency

tensioning retractors
Models 124, 129, 140, 163, 168, 170, 202,

203, 208, 209, 210,

211.004/006/016/061/065/070, 215, 220, 230,

240, 314, 316, 318, 414, 461, 463, 638, 668,

670, 690.6, 901, 902, 903, 904, 905, 950,

952, 953, 954, 970, 972, 974, 975, 976

Models WD141, WD241, WD341, WD641,

WD741, XD141, XD241, XD341, XD441,

XD541, XD641, XD741, YD141, YD241,

YD341, YD441, YD541, YD641, YD741

AH91.00-P-0004-01A

o

Notes on disposal of airbags and emergency

tensioning retractors
All models

OS91.00-P-0001-01A

Render emergency tensioning retractors

unusable

AR91.40-P-0611A

1
Withdraw ignition key

2
Remove paneling on C-pillar

AR68.30-P-4490GH

Copyright DaimlerChrysler AG 14.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

Page 3820 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 3
Unscrew bolt (1) from seat belt guide bracket

(2)
If necessary, remove belt height adjuster
(5).

*BA91.40-P-1002-01D

4
Disconnect connector from right rear ETR

[GUS] ignition squib (R12/7

Page 3821 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR91.40-P-1516GJ
Remove/install rear seat belt buckle
12.1.00

MODEL
163.136 /154 /172 as of 1.9.99,

163.113 /128 /157 /174 /175

60% outer rear seat

P91.40-2174-06

2
Side covers

3
Back of r

Page 3822 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR91.40-P-1516GI
Remove/install rear seat belt buckle
12.1.00

MODEL
163.136 /154 /172 as of 1.9.99,

163.113 /128 /157 /174 /175

Center seat 60% rear seat

P91.40-2127-01

8
Bolt

9
Rear seat

Page 3823 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR91.40-P-1516GH
Remove/install rear seat belt buckle
12.1.00

MODEL
163.136 /154 /172 as of 1.9.99,

163.113 /128 /157 /175 except CODE (293) Left and right rear side bag

40% rear seat

P91.40-2

Page 3824 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR91.40-P-1516GK
Remove/install rear seat belt buckle
26.9.02

MODEL
163.136 /154 /172 as of 1.9.99,

163.113 /128 /157 /175 with CODE (293) Left and right rear side airbag

40% rear seat

MODEL
