Page 3801 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR91.29-P-1420GH
Removing and installing front power seat motor group (seat cushion)
7.3.97

MODEL
163 with CODE (221b) Electrically adjustable left and right front seats

P91.29-0333-06

1
Seat c

Page 3802 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
Torx bit set

000 589 01 10 00

Copyright DaimlerChrysler AG 14.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 2

Page 3803 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR91.10-P-1000GH
Remove/install front seat
3.3.97

MODEL
163.113 /128 /136 /154 /157 /172 /174 /175 with CODE (221b) Electrically adjustable driver and passe
nger seat

P91.10-0547-06

1
Torx sock

Page 3804 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
Number
Designation
Model 163 up to

08/99
Model 163 as of

09/99

BA91.40-P-1001-01DBelt end fitting screw
Nm
3535

Torx bit set

000 589 01 10 00

Copyright DaimlerChrysler AG 09.05.2006 CD-Ausg

Page 3805 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR91.12-P-1100GH
Remove and install cover on bottom of rear seat
22.2.00

MODELS
163.136 /154 /172 as of 1.9.99,

163.113 /128 /157 /174 /175

P91.12-2189-09

Arrows
Pushing directions for releas

AR91.12-P-1100GH
Remove and install cover on bottom of rear seat
22.2.00

MODELS
163.136 /154 /172 as of 1.9.99,

163.113 /128 /157 /174 /175

P91.12-2189-09

Arrows
Pushing directions for releasing

the locating tabs

Remove

Risk of breakage! Carefully press covers off

with a short screwdriver or suitable long

wedges.

1
Remove rear cargo space floor flaps

See Operating Instructions

2Remove rear cover (A)

Pull front outer edges of the cover

upwards in order to release the locating tabs

(1). Press outer locating tabs (2) outwards. In

the center of the cover, press locating tab (3)

to the right and locating tab (4) forwards. In

order to release the locating tabs (5), press

the cover down and remove to the rear.

3
Remove curtain at front 40 % bench

4
Remove outer cover (B) from 40 % bench

Press the cover in and pull upwards at

locating tab (6). Pull outwards at locating tabs

(7, 8). Press the cover forwards in order to

release the locating tab (9). At locating tab

(10), press down with a long wedge between

the covers. Guide the cover past the lateral

curtain.

5
Remove inner cover (C) from 40 % bench

Pull the outer rear corners of the cover up

in order to release the rear locating tabs (11).

In order to release the locating tabs (12),

press the cover forwards and remove to the

front.

6
Remove curtain at front 60 % bench

7
Remove outer cover (D) from 60 % bench

Push locating tab (13) up and turn cover

out and up at locating tab (14). Pull outwards

at locating tabs (15). Press the cover

forwards in order to release the locating tabs

(16). At locating tab (17) press down with a

long wedge between the covers. Guide the

cover past the lateral curtain.

8
Remove inner cover (E) from 60 % bench

Press locating tabs (18) in. Pull the outer

rear corners of the cover up in order to

release the rear locating tabs (19). In order to

release the locating tabs (20), press the cover

forwards, rotate counterclockwise and remove
past the springs towards the rear.

Install

Copyright DaimlerChrysler AG 14.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

Page 3806 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 9
Install inner cover (E) at 60 % bench

Insert cover past the springs from the rear

and rotate into position in a clockwise

direction. Insert locating tabs (19). Press the

front cover down an

Page 3807 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR91.18-P-1850GI
Remove and install cover on rear seat cushion
6.5.99

MODELS
163.136 /154 /172 as of 1.9.99,

163.113 /128 /157 /174 /175

P91.18-2031-09

1
Paneling of horizontal adjustment

h

Page 3808 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
15
Detach the staple wires from the opened wire

rings at rear seat cover (7)

16
Remove rear seat cover (7) from rear seat

upholstery (8)

17
Install in the reverse order

Seat belts/emergency
