1997 MERCEDES-BENZ ML320 Complete Repair Manual

catalytic converter lug pattern seat adjustment battery location engine oil capacity air filter

Page 3193 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR88.40-P-3020GH
Adjust engine hood
8.4.99

MODEL
163.113 /128 /136 /154 /157 /172 /174 /175

P88.40-2067-09

1
Bolts

2
Engine hood

3
Engine hood hinge
7

Locknut

8
Nuts

4

Bolts

5
Engine

AR88.40-P-3020GH
Adjust engine hood
8.4.99

MODEL
163.113 /128 /136 /154 /157 /172 /174 /175

P88.40-2067-09

1
Bolts

2
Engine hood

3
Engine hood hinge
7

Locknut

8
Nuts

4

Bolts

5
Engine hood catch upper section

6
Stop buffer

Longitudinal, height and transverse

adjustment

Danger!

Risk of injury
to
fingers being jammed or

pinched
when Remove/install or aligning

hoods, doors, trunk lid/tailgate or sliding roof.
When moving components, ensure that no

body parts or limbs are within the operating

range of moving parts.

AS00.00-Z-0011-01A

1
Open engine hood (2)

For slight range of adjustments for

longitudinal and height adjustment

2
Loosen bolts (1) on engine hood hinge (3)

and adjust engine hood (2)

3
Tighten bolts (1)

*BA88.40-P-1001-01C

For larger range of adjustments for

longitudinal and height adjustment

4.1
Remove gas-operated strut from engine hood

(2) and put down in engine compartment

Risk of breakage. Do not remove the

retainer otherwise the preload will be lost.

AR88.40-P-3010GH

As of VIN A145273, X708319.

5
Remove cover on air intake

AR83.25-P-1405GH

6
Remove rubber cover from engine hood hinge

Installation:
Replace rubber cover.

7
Cut seam sealing along engine hood hinge so

that hinge can be moved

Installation:
Replace seam sealing. Paint

sealant after curing.

*BR00.45-Z-1004-01A

8
Loosen nuts (8) on engine hood hinge (3)

9
Adjust engine hood (2) so that front edges of

front fenders are flush with engine hood and

top edges are aligned

For larger range of adjustment in

longitudinal direction loosen engine hood

catch upper section (5) and tighten.

*BA88.40-P-1004-01C

10
Tighten nuts (8) for engine hood hinge (3)

*BA88.40-P-1002-01C

11.1
Install gas-operated strut

As of VIN A145273, X708319.

AR88.40-P-3010GH

12
Adjust stop buffer (6)

Unscrew locknut (7). Adjust height of stop

buffer so that top edges of front fenders and

engine hood are flush If required, place

spacer plates below engine hood catch upper

section.

13
Fasten stop buffer (6)

Tighten locknut (7).

Transverse adjustment

14
Loosen bolts (4) from engine hood catch

upper section (5)

Copyright DaimlerChrysler AG 09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

Page 3194 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
15
Adjust gap dimensions
Gap dimensions

*BE60.00-P-1001-01D

Feeler gage

*129589032100

16
Align engine hood catch upper section (5)

centered in longitudinal and transverse
direction to engine

Page 3195 of 4133

Page 3196 of 4133

Page 3197 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR88.40-P-3100GH
Remove/install control cable for engine hood
5.5.00

MODEL
163.113 /128 /136 /154 /157 /172 /174 /175

P88.40-2140-06

Illustrated up to VIN A145272, X708318

1
Clips

2
Rubber g

Page 3198 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR88.40-P-4050R
Remove/install Mercedes star
30.3.01

MODEL
163, 203.7, 215, 230.467 /474 /475 /476 /479

P88.40-2291-11

Shown on model 230

1
Mercedes star

2
Grommets

Remove/Install

1
Re

Page 3199 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
AR88.40-P-3060GH
Remove/install engine hood hinge
16.4.97

MODEL
163.113 /128 /136 /154 /157 /172 /174 /175

P88.40-0365-01
P88.40-0364-01

1
Screws

2
Engine hood hinge

3
Nuts

Removing and

AR88.40-P-3060GH
Remove/install engine hood hinge
16.4.97

MODEL
163.113 /128 /136 /154 /157 /172 /174 /175

P88.40-0365-01
P88.40-0364-01

1
Screws

2
Engine hood hinge

3
Nuts

Removing and installing

Danger!

Risk of injury
to
fingers being jammed or

squeezed
when removing and installing or

aligning hoods, doors, trunk lid/tailgate or

sliding roof.
When moving components, ensure that no

body parts or limbs are within the operating

range of moving parts.

AS00.00-Z-0011-01A
1.1
Remove engine hood

Only when both engine hood hinges are

removed.

AR88.40-P-3000GH
1.2
Open engine hood and raise to vertical position

Up to VIN A145272, X708318.

AR88.40-P-1000GH

As of VIN A145273, X708319.

AR88.40-P-1000GI

2
Remove cover on air intake

AR83.25-P-1405GH

3
Remove rubber cover from engine hood hinge

Installation:
Replace rubber cover.

4
Cut joint seal along engine hood hinge so that

hinge can be moved

Installation:
Replace seam sealing. Paint

sealant after curing.

*BR00.45-Z-1004-01A

5
Mark installation position of engine hood

hinge (2)

Facilitates installation.

6.1
Remove gas strut

As of VIN A145273, X708319.

AR88.40-P-3010GH

Danger of breaking!
Do not remove the

retainer otherwise the preload will be lost.

7
Remove screws (1)

Support engine hood at rear to prevent

damage.

*BA88.40-P-1001-01C

8
Unscrew nuts (3)

*BA88.40-P-1002-01C

9
Remove engine hood hinge (2)

Installation:
Align engine hood hinge at
marks made previously.

10
Install in the reverse order

11
Check alignment of engine hood
If necessary:
#

Adjust engine hood

AR88.40-P-3020GH

Engine hood

Number

Designation
Model 163

BA88.40-P-1001-01C
Screw for engine hood hinge on engine hood
Nm
10

BA88.40-P-1002-01C
Nut for engine hood hinge on body
Nm
18

Repair products
Number

Designation
Order number

BR00.45-Z-1004-01A
MB body sealant for sealing seams (suitable for painting)
001 989 63 20

Copyright DaimlerChrysler AG 09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

Page 3200 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual
SM63.20-P-0002GH
Reinforce engine hood hinge support on front left
16.1.02

MODELS
163.136 /154 /172 #A as of 145273,

163.136 /154 /172 #X as of 708319,

163.113 /128 /174 /175

P63.20-3439-12
