Page 1097 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 293 Technical data Layout of poly-V-belt drive Layout of poly-V-belt drive 1Automatic belt tensioner 2Power steering pump 3Air conditioning compressor 4Crankshaft 5Coolant pump 6Generator (alternator

Page 1098 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 294 Technical dataEngine EngineModel ML 350 (163.157 1) 1The quoted data apply only to the standard vehicle. See an authorized Mercedes-Benz Light Truck Center for the corresponding data of all speci

Page 1099 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 295 Technical data Rims and tires Rims and tires Use only tires and rims which have been specifically developed for your vehicle and tested and approved by Mercedes-Benz. Other tires and rims can

Page 1100 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 296 Technical dataRims and tiresSpare wheelModel ML 350, ML 500 Rim 4Jx18 H2 ET0 Wheel offset 0 in (0 mm) Space-saver tire T155 / 90 D18 113M 1 1Must not be used with snow chains.

Page 1101 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 297 Technical data Electrical system Electrical system Model ML 350 ML 500 Generator (alternator) 14 V / 120 A 14 V / 150 A Starter motor 12 V / 1.7 kW 12 V / 1.7 kW Battery 12 V / 100 Ah 12 V / 100

Page 1102 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 298 Technical dataMain Dimensions Main DimensionsModel ML 350, ML 500 Overall vehicle length 182.6 in (4638 mm) Overall vehicle width 83.7 in (2126 mm) Overall vehicle height 71.7 in (1820 mm) Wheelb

Page 1103 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 299 Technical data Weights Weights Roof load max. 220 lbs (100 kg)

Page 1104 of 4133

MERCEDES-BENZ ML320 1997 Complete Repair Manual 300 Technical dataFuels, coolants, lubricants etc. Fuels, coolants, lubricants etc.Capacities Vehicle components and their respective lubricants must match.Therefore use only brands tested and appr
