Page 3505 of 4133
 AR68.10-P-1500GH
Removing and installing cover below instrument panel (left)
4.2.97
MODELS
163.113 /128 /136 /154 /157 /172 /174 /175
P68.10-0522-06
1
Plugs
2
 Bolt
3
 Clips
4
 Cover
X11/4
 Datalink connector

Remove/install
1
Remove plug (1)
 2 each.
2
Unscrew screw (2)
 2 each.

Installation:
 Observe clips (3).
3
Unlock and remove data link connector (X11/4)
4
Take off cover (4)
5
Install in the reverse order
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 3506 of 4133
 AR68.10-P-1520GH
Remove/install cover below instrument panel (right)
4.2.97
MODEL
163.136 /154 /172 #A up to 145272,
163.136 /154 /172 #X up to 708318
P68.10-0527-06
1
 Cover
2
 Plug-in clips
3
 Catch
X58/1
 Interior socket

Remove/Install
1
Unhook catch (3) on blower motor
 Risk of breakage!
2
Unclip cover (1)
 Cover is fastened with 2 clips (2).
3
Disconnect electrical connector from interior
socket (X58/1)
4
Install in the reverse order
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 3507 of 4133
 AR68.10-P-1520GI
Remove/install cover below instrument panel (right)
2.6.99
MODEL
163.136 /154 /172 #A as of 145273,
163.136 /154 /172 #X as of 708319,
163.113 /128 /157 /174 /175
P68.10-2249-06
1
 Torx bolts
2
 Cover
3
 Locking lever
X58/1
 I
nterior socket

Remove/Install
1
Unscrew Torx screws (1) form cover (2)
2
Fold locking lever (3) downward
3
Pull cover (2) downward and lay down
4
Disconnect electrical connector from interior
socket (X58/1)
5
Install in the reverse order
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 3508 of 4133
 AR83.40-P-6500GH
Remove/install switch unit/automatic air conditioning control module
7.3.01
MODEL
163.113 /154 /174 #A as of 289565,
163.113 #X as of 754620,
163.128 /157 /175
P83.40-2329-06
1
 Instrument panel center section
2
 Bolts
N22
 AAC pushbutton control module

Remove/install
1
Remove center section of instrument panel
AR68.10-P-1030GH
2
Remove switch unit of AAC control and
operating module (N22) from center part of
instrument panel (1)
3
Unscrew screws (2) from AAC control and
operating module (N22)
4
Disconnect AAC control and operating
module (N22) from center section of
instrument panel
 Loosen retaining clamps at the top and
bottom.
5
Install in the reverse order
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 3509 of 4133
 AR83.20-P-1835GH
Remove, install switch unit for heater/ventilation
30.4.97
MODELS
163.113/136/154/172/174 up to 31.8.01 with CODE (580) air conditioning or Tempmatic for USA
P83.20-0262-06
1
Center part of instrument panel
2
 Defroster cable
3
 Footwell ventilation cable
4
 Pushbutton control module
X72/3
 Connector

Remove/install
1
Remove radio
AR82.60-P-7502EA
2
Remove center part of instrument panel (1)
AR68.10-P-1030GH
3
Unscrew bolts at heater/AC controls (4) and
remove controls
4
Detach cable (2, 3)
 Unclip cables at heater/AC controls.
5
Disconnect connector (X72/3) at heater/AC
controls (4)
6
Install in the reverse order
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 3510 of 4133

 AR68.10-P-1111GH
Remove/install instrument panel carrier
17.3.97
MODEL
163.113 /128 /136 /154 /157 /172 /174 /175
P68.10-0612-09
1
Caps on A-pillar
2
 Bolts
3
 Instrument panel
4
 Bolt
5
 Bolts
6
 Heater housing
7
 Front passenger airbag unit
8
 Nuts, self-locking
 17
Cover below instrument panel on right
18
 Connector on MB immobilizer switch
19
 Connector at steering/ignition lock
20
 Steering column adjustment switch
connector
10
Steering column
11
 Bolts
12
 Nuts
13
 Instrument panel
14
 Bottom section of instrument panel
15
 Wiring harness
16
 Cover below instrument panel on left

Remove/install
1
Remove instrument panel (13) and the lower
part of instrument panel (14)
AR68.10-P-1000GH
2
Remove passenger airbag (7)
AR91.60-P-0680GH
3
Remove cover below instrument panel on
right (17)
Up to chassis number A145272, X708318.
AR68.10-P-1520GH
As of chassis number A145273, X708319.
AR68.10-P-1520GI
4
Unscrew screws (5) from instrument panel
carrier (3) on heater housing (6)
5
Remove cover below instrument panel on left
(16)
AR68.10-P-1500GH
6
Remove insulating mat between steering
column (10) and carrier for instrument panel (3)
7
Unscrew screws (11) for steering column (10)
from instrument panel carrier (3)

*BA46.10-P-1006-03C
8
Remove nuts (12) for steering column (10)
from instrument panel carrier (3)

*BA46.10-P-1007-03C
9
Unscrew screws (4) for instrument panel
carrier (3) from middle tunnel
10
Disconnect connector from steering column
height adjustment switch (20)
11
Disconnect connector from MB immobilizer
switching unit (18)
12
Disconnect connector from steering/ignition
switch (19)
13
Disconnect wiring harness (15) from
instrument panel carrier
 Installation:
 Ensure that wiring harness
is routed correctly on instrument panel carrier.
14
Remove wiper system
AR82.30-P-6400GH
15
Unscrew nuts for instrument panel carrier (3)
on firewall

Installation:
  Install new self-locking nuts.
16
Remove caps on A-pillar (1)
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1


        Page 3511 of 4133
 17
Unscrew screws (2) for instrument panel
carrier (3) from A-pillar
18
Remove instrument panel carrier (3) and take
out of passenger compartment to side
through passenger door

Be careful not to damage center console
when removing and installing.
19
Install in the reverse order

Jacket tube
Number
Designation
MODEL
 Series 163
BA46.10-P-1006-03C
Screw for jacket tube on upper instrument
panel carrier
Nm
20
BA46.10-P-1007-03C
Jacket tube collar nut on instrument panel
carrier at bottom
Nm
18
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 2


        Page 3512 of 4133
 AR54.65-P-0003GH
Removing and installing Parktronic system (PTS) warning display in instrument
panel
23.4.01
MODEL
 163.113 /128 /154 /157 /174 /175 with CODE (220a) Parktronic System (PTS)
P54.65-2414-11
1
Connector
A44/4
 PTS warning display, center of instrument panel

Remove/install
1
Remove PTS warning display (center of
dashboard)A44/4) above the instrument panel.

 Ensure that the instrument panel is not
damaged.
 Long wedge
*115589035900
2
Disconnect connector (1).
3
Install in the reverse order
Long wedge
115 589 03 59 00
Copyright DaimlerChrysler AG  09.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
 d by Modification services.
Page 1
