Page 329 of 3502

NISSAN TEANA 2003 Service Manual REPAIR FOR COMPONENT PARTS AT-321 D E F G H I J K L MA B AT INSPECTION Rear Internal Gear, Forward Clutch Hub and Overrun Clutch Hub Check rubbing surfaces for wear or damage. Replace if necessary.

Page 330 of 3502

NISSAN TEANA 2003 Service Manual AT-322 REPAIR FOR COMPONENT PARTS 3. Install thrust washer on rear internal gear. CAUTION: Align pawls of thrust washer with holes of rear internal gear. 4. Install bearing race on rear internal gea

Page 331 of 3502

NISSAN TEANA 2003 Service Manual REPAIR FOR COMPONENT PARTS AT-323 D E F G H I J K L MA B AT Output Shaft, Idler Gear, Reduction Pinion Gear and Bearing RetainerBCS001OT COMPONENTS DISASSEMBLY 1. Remove seal rings from output shaft

Page 332 of 3502

NISSAN TEANA 2003 Service Manual AT-324 REPAIR FOR COMPONENT PARTS 2. Remove output shaft bearing from output shaft with flat-bladed screwdrivers. CAUTION: Always replace bearing with a new one when removed. Do not damage output

Page 333 of 3502

NISSAN TEANA 2003 Service Manual REPAIR FOR COMPONENT PARTS AT-325 D E F G H I J K L MA B AT 7. Press out reduction pinion gear bearing inner race from reduc- tion pinion gear. 8. Remove reduction pinion gear bearing outer race fro

Page 334 of 3502

NISSAN TEANA 2003 Service Manual AT-326 REPAIR FOR COMPONENT PARTS ASSEMBLY 1. Press reduction pinion gear bearing inner race on reduction pin- ion gear. CAUTION: Apply ATF to reduction pinion gear bearing inner race. 2. Install re

Page 335 of 3502

NISSAN TEANA 2003 Service Manual REPAIR FOR COMPONENT PARTS AT-327 D E F G H I J K L MA B AT 5. Press output shaft bearing on output shaft. CAUTION: Do not reuse output shaft bearing. Apply ATF to output shaft bearing. 6. Press r

Page 336 of 3502

NISSAN TEANA 2003 Service Manual AT-328 REPAIR FOR COMPONENT PARTS CAUTION: Roll paper around seal rings to prevent seal rings from spreading. SAT179F
