NISSAN TEANA 2003 Service Manual INTEGRATED COLOR DISPLAY SYSTEM AV-105 C D E F G H I J L MA B AV 15. CHECK CAMERA-CONNECTION RECOGNITION SIGNAL 1. Connect rear view camera control unit and display control unit connectors. 2. Turn

Page 634 of 3502

NISSAN TEANA 2003 Service Manual AV-106 INTEGRATED COLOR DISPLAY SYSTEM When Displaying Rear View Image, SETTING Menu Is Not DisplayedBKS00287 Symptom: Pressing the “SETTING” button when displaying rear view image, SETTING menu

Page 635 of 3502

NISSAN TEANA 2003 Service Manual INTEGRATED COLOR DISPLAY SYSTEM AV-107 C D E F G H I J L MA B AV Tint Is Strange for The RGB ImageBKS00288 Symptom: Tint of all RGB images is strange. 1. CHECK HARNESS 1. Turn ignition switch OFF. 2

Page 636 of 3502

NISSAN TEANA 2003 Service Manual AV-108 INTEGRATED COLOR DISPLAY SYSTEM 2. CHECK RGB SIGNAL 1. Connect display control unit and display connectors. 2. Turn ignition switch ON. 3. Start Confirmation mode. Refer to AV- 8 9 , " Confi

Page 637 of 3502

NISSAN TEANA 2003 Service Manual INTEGRATED COLOR DISPLAY SYSTEM AV-109 C D E F G H I J L MA B AV RGB Image Is RollingBKS00289 Symptom: RGB image is rolling. 1. CHECK HARNESS 1. Turn ignition switch OFF. 2. Disconnect display contr

Page 638 of 3502

NISSAN TEANA 2003 Service Manual AV-110 INTEGRATED COLOR DISPLAY SYSTEM Values for All Items in The TRIP Screen Do Not ChangeBKS0028A Symptom: Values for items, “Elapsed Time”, “Driving Distance” and “Average Speed” in

Page 639 of 3502

NISSAN TEANA 2003 Service Manual INTEGRATED COLOR DISPLAY SYSTEM AV-111 C D E F G H I J L MA B AV Example of Symptoms Possible No MalfunctionBKS0028D For system operation information, refer to Owners Manual. DISPLAY REAR VIEW MONI

Page 640 of 3502

NISSAN TEANA 2003 Service Manual AV-112 INTEGRATED COLOR DISPLAY SYSTEM Removal and Installation of A/C and AV SwitchBKS0028E REMOVAL Remove A/C and AV switch integral with audio unit. Refer to AV- 3 4 , "Removal and Installation
