NISSAN TEANA 2003 Service Manual COIL SPRING AND STRUT
FSU-13
C
D
F
G
H
I
J
K
L
MA
B
FSU

Install spring upper seat with cutout facing outside vehicle as
shown in the figure.
5. Install strut mounting insulator bracket and mounting

Page 2442 of 3502

NISSAN TEANA 2003 Service Manual FSU-14
TRANSVERSE LINK

TRANSVERSE LINKPFP:54500
Removal and InstallationBES0003Q
REMOVAL
1. Remove tires from vehicle.
2. Remove fixing nut and bolt of transverse link ball joint, and then separate

Page 2443 of 3502

NISSAN TEANA 2003 Service Manual TRANSVERSE LINK
FSU-15
C
D
F
G
H
I
J
K
L
MA
B
FSU

Axial End Play Inspection
Move tip of ball joint in the axial direction to check for looseness.
Replace transverse link if value is outside the st

Page 2444 of 3502

NISSAN TEANA 2003 Service Manual FSU-16
STABILIZER BAR

STABILIZER BARPFP:54611
Removal and InstallationBES0003R
REMOVAL
1. Remove tires from vehicle.
2. Remove steering gear assembly from vehicle. Refer to PS-17, "
POWER STEERING G

Page 2445 of 3502

NISSAN TEANA 2003 Service Manual FRONT SUSPENSION MEMBER
FSU-17
C
D
F
G
H
I
J
K
L
MA
B
FSU

FRONT SUSPENSION MEMBERPFP:54401
Removal and InstallationBES0003S
REMOVAL
1. Remove cowl top panel and hood. Install engine slinger, and the

FRONT SUSPENSION MEMBER
FSU-17
C
D
F
G
H
I
J
K
L
MA
B
FSU

FRONT SUSPENSION MEMBERPFP:54401
Removal and InstallationBES0003S
REMOVAL
1. Remove cowl top panel and hood. Install engine slinger, and then hoist engine. (Models with VQ35DE)
Refer to EI-21, "
COWL TOP" , BL-13, "HOOD" .
2. Remove tires from the vehicle.
3. Remove undercover and splash guard.
4. Remove mounting nut on the lower side of stabilizer connecting
rod. Remove stabilizer connecting rod from stabilizer bar. Refer
to FSU-16, "
STABILIZER BAR" .
5. Remove fixing nut and bolt of transverse link ball joint, and then
remove transverse link from steering knuckle. Refer to FSU-14,
"TRANSVERSE LINK" .
6. Remove front exhaust tube. Refer to EX-2, "
EXHAUST SYS-
TEM" .
7. Remove heat insulator. (Except for QR20DE models)
8. Remove steering hydraulic piping bracket from front suspension
member and rear engine mounting insulator. Refer to PS-39,
"HYDRAULIC LINE" .
9. Set a jack under transaxle assembly.
10. Remove mounting bolts of front engine mounting bracket and front engine mounting insulator. Refer to
EM-223, "
ENGINE ASSEMBLY" .
11. Remove mounting bolts of rear engine mounting bracket and rear engine mounting insulator. Refer to EM-
223, "ENGINE ASSEMBLY" .
12. Remove steering gear mounting bolts, and then hang steering gear on vehicle. Refer to PS-17, "
POWER
STEERING GEAR AND LINKAGE" .
13. Set a jack under front suspension member.
14. Remove mounting nuts on the front side and rebound stopper of front suspension member.
15. Remove mounting nut and bolts of member stay, and then remove member stay. Refer to FSU-7, "
Com-
ponents" .
16. Gradually lower a jack to remove front suspension member, stabilizer bar and transverse link from vehicle
as a unit.
17. Remove front and rear engine mounting insulators from front suspension member. Refer to EM-223,
"ENGINE ASSEMBLY" .
18. Remove transverse link from front suspension member. Refer to FSU-14, "
TRANSVERSE LINK" .
19. Remove stabilizer bar from front suspension member.
INSPECTION AFTER REMOVAL
Check front suspension member for deformation, cracks, or other damage. Replace if there are.
INSTALLATION
Installation is the reverse order of the removal. For tightening torque, refer to FSU-7, "Components" .
NOTE:
Do not reuse non-reusable parts.
Perform final tightening of each of parts, under unladen conditions, which were removed when removing
front suspension member and transverse link. Check the wheel alignment. Refer to FSU-5, "
Wheel Align-
ment Inspection" .
Adjust neutral position of steering angle sensor after checking the wheel alignment for models with VDC.
Refer to BRC-40, "
Adjustment of Steering Angle Sensor Neutral Position" .
SEIA0375E

Page 2446 of 3502

NISSAN TEANA 2003 Service Manual FSU-18
SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Wheel Alignment (Unladen*)BES0003T
*: Fuel, engine coolant and engine oil full. Spare tire, jack, hand t

Page 2447 of 3502

NISSAN TEANA 2003 Service Manual GI-1
GENERAL INFORMATION
A GENERAL INFORMATION
CONTENTS
C
D
E
F
G
H
I
J
K
L
MB
GI
SECTION GI

GENERAL INFORMATION
PRECAUTIONS .......................................................... 3
Description

GI-1
GENERAL INFORMATION
A GENERAL INFORMATION
CONTENTS
C
D
E
F
G
H
I
J
K
L
MB
GI
SECTION GI

GENERAL INFORMATION
PRECAUTIONS .......................................................... 3
Description ............................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions for NATS (NISSAN ANTI-THEFT SYS-
TEM) ........................................................................ 3
Precautions Necessary for Steering Wheel Rotation
After Battery Disconnect .......................................... 4
OPERATION PROCEDURE ................................. 4
General Precautions ................................................ 4
Precautions for Three Way Catalyst ......................... 6
Precautions for Fuel ................................................. 6
QR20DE/VQ23DE ENGINE (REGULAR GASO-
LINE, UNLEADED PREMIUM GASOLINE REC-
OMMENDED) ........................................................ 6
VQ35DE ENGINE (PREMIUM GASOLINE) ......... 6
Precautions for Multiport Fuel Injection System or
Engine Control System ............................................ 6
Precautions for Hoses .............................................. 7
HOSE REMOVAL AND INSTALLATION ............... 7
HOSE CLAMPING ................................................ 7
Precautions for Engine Oils ...................................... 8
HEALTH PROTECTION PRECAUTIONS ............. 8
Precautions for Air Conditioning ............................... 8
HOW TO USE THIS MANUAL ................................... 9
Description ............................................................... 9
Terms ....................................................................... 9
Units ......................................................................... 9
Contents ................................................................... 9
Components ........................................................... 10
SYMBOLS ........................................................... 10
How to Follow Trouble Diagnoses ........................... 11
DESCRIPTION ..................................................... 11
HOW TO FOLLOW TEST GROUPS IN TROU-
BLE DIAGNOSES ................................................ 11
HARNESS WIRE COLOR AND CONNECTOR
NUMBER INDICATION ....................................... 12
KEY TO SYMBOLS SIGNIFYING MEASURE-
MENTS OR PROCEDURES ............................... 13How to Read Wiring Diagrams ............................... 15
HEALTH PROTECTION PRECAUTIONS ............. 8
SYMBOLS ........................................................... 10
DESCRIPTION .................................................... 17
Abbreviations .......................................................... 23
SERVICE INFORMATION FOR ELECTRICAL INCI-
DENT ......................................................................... 24
How to Perform Efficient Diagnosis for an Electrical
Incident ................................................................... 24
WORK FLOW ...................................................... 24
INCIDENT SIMULATION TESTS ........................ 24
CIRCUIT INSPECTION ....................................... 27
Control Units and Electrical Parts ........................... 31
PRECAUTIONS .................................................. 31
CONSULT-II CHECKING SYSTEM .......................... 33
Description .............................................................. 33
Function and System Application ........................... 33
Nickel Metal Hydride Battery Replacement ............ 33
Checking Equipment .............................................. 34
CONSULT-II Start Procedure .................................. 34
CONSULT-II Data Link Connector (DLC) Circuit .... 35
INSPECTION PROCEDURE .............................. 35
CIRCUIT DIAGRAM ............................................... 36
LIFTING POINT ......................................................... 37
Commercial Service Tools ...................................... 37
Garage Jack and Safety Stand and 2-Pole Lift ....... 37
Board-On Lift .......................................................... 38
TOW TRUCK TOWING ............................................. 39
Tow Truck Towing ................................................... 39
TOWING AN AUTOMATIC TRANSAXLE
MODEL WITH THE FRONT WHEELS ON THE
GROUND ............................................................ 39
Vehicle Recovery (Freeing a Stuck Vehicle) ........... 39
TIGHTENING TORQUE OF STANDARD BOLTS .... 40
Tightening Torque Table ......................................... 40
IDENTIFICATION INFORMATION ............................ 41
Model Variation ....................................................... 41
IDENTIFICATION NUMBER ................................ 41
IDENTIFICATION PLATE .................................... 42
ENGINE SERIAL NUMBER ................................ 42

Page 2448 of 3502

NISSAN TEANA 2003 Service Manual GI-2 AUTOMATIC TRANSAXLE NUMBER ................. 43
Dimensions ............................................................. 44
Wheels & Tires ......................................................

Load next 8 pages
