Page 2153 of 3502

NISSAN TEANA 2003 Service Manual CAMSHAFT EM-45 [QR] C D E F G H I J K L MA EM CAMSHAFT JOURNAL OIL CLEARANCE (Oil clearance) = (Camshaft bracket inner diameter) – (Camshaft journal diameter) If out of the standard, replace eit

Page 2154 of 3502

NISSAN TEANA 2003 Service Manual EM-46 [QR] CAMSHAFT Valve Lifter Check if surface of valve lifter has any wear or cracks. If anything above is found, replace valve lifter. Refer to EM-50, "Valve Clearance" . Valve Lifter Cleara

Page 2155 of 3502

NISSAN TEANA 2003 Service Manual CAMSHAFT EM-47 [QR] C D E F G H I J K L MA EM INSTALLATION 1. Install valve lifters. Install them in the original positions. 2. Install camshafts. Distinction between intake and exhaust camshafts

Page 2156 of 3502

NISSAN TEANA 2003 Service Manual EM-48 [QR] CAMSHAFT ii. Apply liquid gasket to camshaft bracket (No. 1) contact surface on the front cover backside. Use Genuine Liquid Gasket or equivalent. Apply liquid gasket to the outside of b

Page 2157 of 3502

NISSAN TEANA 2003 Service Manual CAMSHAFT EM-49 [QR] C D E F G H I J K L MA EM CAUTION: After installation, pull the stopper pin off completely, and make sure that chain tensioner plunger is released. 8. Install chain guide. 9. Ins

Page 2158 of 3502

NISSAN TEANA 2003 Service Manual EM-50 [QR] CAMSHAFT 4. Crank the engine, and then make sure that engine oil comes out from intake valve timing control cover oil hole. End crank after checking. WARNING: Be careful not to touch rota

Page 2159 of 3502

NISSAN TEANA 2003 Service Manual CAMSHAFT EM-51 [QR] C D E F G H I J K L MA EM b. Use a feeler gauge, measure the clearance between valve lifter and camshaft. Valve clearance: Unit: mm (in) *:Approximately 80°C (176°F) By refer

Page 2160 of 3502

NISSAN TEANA 2003 Service Manual EM-52 [QR] CAMSHAFT 1. Remove camshaft. Refer to EM-41, "REMOVAL" . 2. Remove valve lifters at the locations that are out of the standard. 3. Measure the center thickness of the removed valve lifte
