Page 2257 of 3502
![NISSAN TEANA 2003 Service Manual OIL PAN AND OIL STRAINER
EM-149
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
To install, align protrusion of oil pan gasket with notches of
front timing chain case and rear oil seal retainer.
Install oil pan ga NISSAN TEANA 2003 Service Manual OIL PAN AND OIL STRAINER
EM-149
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
To install, align protrusion of oil pan gasket with notches of
front timing chain case and rear oil seal retainer.
Install oil pan ga](/manual-img/5/57392/w960_57392-2256.png)
OIL PAN AND OIL STRAINER
EM-149
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
To install, align protrusion of oil pan gasket with notches of
front timing chain case and rear oil seal retainer.
Install oil pan gasket with smaller arc to front timing chain
case side.
c. Install new O-rings on the bottom of cylinder block and oil pump.
d. Apply a continuous bead of liquid gasket with tube presser [SST:
WS39930000] to cylinder block mating surface of oil pan (upper)
to a limited portion as shown in the figure.
Use Genuine Liquid Gasket or equivalent.
CAUTION:
For bolt holes with marks (5 locations), apply liquid
gasket outside the holes.
Apply a bead of 4.5 to 5.5 mm (0.177 to 0.217 in) diameter
to area “A”.
Attaching should be done within 5 minutes after coating.
e. Install oil pan (upper).
CAUTION:
Install avoiding misalignment of both oil pan gasket and O-rings.
Tighten bolts in numerical order as shown in the figure.
There are two types of mounting bolt. Refer to the following
for locating bolts.
f. Install transaxle joint bolts.
2. Install oil strainer to oil pump.
3. Install oil pan (lower) as follows:
PBIC1145E
PBIC1144E
PBIC2300E
M8 × 100 mm (3.97 in) : 5, 7, 8, 11
M8 × 25 mm (0.98 in) : Except the above
PBIC1636E
Page 2258 of 3502
![NISSAN TEANA 2003 Service Manual EM-150
[VQ]
OIL PAN AND OIL STRAINER
a. Use scraper to remove old liquid gasket from mating surfaces.
Also remove old liquid gasket from mating surface of oil pan
(upper).
Remove old liquid gasket NISSAN TEANA 2003 Service Manual EM-150
[VQ]
OIL PAN AND OIL STRAINER
a. Use scraper to remove old liquid gasket from mating surfaces.
Also remove old liquid gasket from mating surface of oil pan
(upper).
Remove old liquid gasket](/manual-img/5/57392/w960_57392-2257.png)
EM-150
[VQ]
OIL PAN AND OIL STRAINER
a. Use scraper to remove old liquid gasket from mating surfaces.
Also remove old liquid gasket from mating surface of oil pan
(upper).
Remove old liquid gasket from the bolt holes and thread.
CAUTION:
Do not scratch or damage the mating surfaces when clean-
ing off old liquid gasket.
b. Apply a continuous bead of liquid gasket with tube presser [SST:
WS39930000] to oil pan (lower) as shown in the figure.
Use Genuine Liquid Gasket or equivalent.
CAUTION:
Attaching should be done within 5 minutes after coating.
c. Install oil pan (lower).
Tighten mounting bolts in numerical order as shown in the fig-
ure.
4. Install oil pan drain plug.
Refer to the figure of components of former page for installation direction of drain plug washer. Refer to
EM-145, "
Removal and Installation" .
5. Install in the reverse order of removal after this step.
NOTE:
At least 30 minutes after oil pan is installed, pour engine oil.
INSPECTION AFTER INSTALLATION
1. Check the engine oil level and adjust engine oil. Refer to LU-19, "ENGINE OIL" .
2. Start engine, and make sure there is no leak of engine oil.
SEM958F
PBIC2647E
PBIC0782E
Page 2259 of 3502
OIL PAN AND OIL STRAINER
EM-151
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
3. Stop engine and wait for 10 minutes.
4. Check the engine oil level again. Refer to LU-19, "
ENGINE OIL" .
Page 2260 of 3502
EM-152
[VQ]
IGNITION COIL
IGNITION COILPFP:22448
Removal and InstallationBBS004VV
REMOVAL
1. Remove engine cover. Refer to EM-133, "INTAKE MANIFOLD COLLECTOR" .
2. Remove intake manifold collectors (upper and lower). (At the right bank side, remove ignition coil) Refer to
EM-133, "
INTAKE MANIFOLD COLLECTOR" .
3. Move aside harness, harness bracket, and hoses located above ignition coil.
4. Disconnect harness connector from ignition coil.
5. Remove ignition coil.
CAUTION:
Do not drop or shock it.
INSTALLATION
Installation is the reverse order of removal.
1. Ignition coil 2. Spark plug 3. Rocker cover
A. Left bank
PBIC4359E
Page 2261 of 3502
SPARK PLUG (PLATINUM-TIPPED TYPE)
EM-153
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
SPARK PLUG (PLATINUM-TIPPED TYPE)PFP:22401
Removal and InstallationBBS004VW
REMOVAL
1. Remove engine cover. Refer to EM-133, "INTAKE MANIFOLD COLLECTOR" .
2. Remove ignition coil. Refer to EM-152, "
IGNITION COIL" .
3. Remove spark plug using spark plug wrench (commercial ser-
vice tool).
CAUTION:
Do not drop or shock it.
INSPECTION AFTER REMOVAL
Use standard type spark plug for normal condition.
Hot type spark plug is suitable when fouling occurs with standard type spark plug under conditions such as:
Frequent engine starts
Low ambient temperatures
Cold type spark plug is suitable when spark plug knock occurs with standard type spark plug under conditions
such as:
Extended highway driving
Frequent high engine revolution
1. Ignition coil 2. Spark plug 3. Rocker cover
A. Left bank
PBIC4359E
SEM294A
MakeNGK
Standard typePLFR5A-11
Hot typePLFR4A-11
Cold typePLFR6A-11
Gap (Nominal) : 1.1 mm (0.043 in)
Page 2262 of 3502
EM-154
[VQ]
SPARK PLUG (PLATINUM-TIPPED TYPE)
CAUTION:
Do not drop or shock spark plug.
Do not use wire brush for cleaning.
If plug tip is covered with carbon, spark plug cleaner may
be used.
Checking and adjusting plug gap is not required between
change intervals.
INSTALLATION
Installation is the reverse order of removal.Cleaner air pressure:
Less than 588 kPa (5.88 bar, 6 kg/cm
2 , 85 psi)
Cleaning time:
Less than 20 seconds
SMA773C
SMA806CA
Page 2263 of 3502
![NISSAN TEANA 2003 Service Manual FUEL INJECTOR AND FUEL TUBE
EM-155
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
FUEL INJECTOR AND FUEL TUBEPFP:16600
Removal and InstallationBBS004VX
Refer to GI-10, "Components" for symbol marks in the figure. NISSAN TEANA 2003 Service Manual FUEL INJECTOR AND FUEL TUBE
EM-155
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
FUEL INJECTOR AND FUEL TUBEPFP:16600
Removal and InstallationBBS004VX
Refer to GI-10, "Components" for symbol marks in the figure.](/manual-img/5/57392/w960_57392-2262.png)
FUEL INJECTOR AND FUEL TUBE
EM-155
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
FUEL INJECTOR AND FUEL TUBEPFP:16600
Removal and InstallationBBS004VX
Refer to GI-10, "Components" for symbol marks in the figure.
CAUTION:
Do not remove or disassemble parts unless instructed as shown in the figure.
REMOVAL
WARNING:
Put a “CAUTION FLAMMABLE” sign in the workshop.
Be sure to work in a well ventilated area and furnish workshop with a CO2 fire extinguisher.
Do not smoke while servicing fuel system. Keep open flames and sparks away from the work area.
To avoid the danger of being scalded, do not drain engine coolant when engine is hot.
1. Remove engine cover. Refer to EM-133, "
INTAKE MANIFOLD COLLECTOR" .
2. Release the fuel pressure. Refer to EC-392, "
FUEL PRESSURE RELEASE" .
3. Drain engine coolant, or when water hoses are disconnected, attach plug to prevent engine coolant leak-
age. Refer to CO-34, "
Changing Engine Coolant" and EM-133, "INTAKE MANIFOLD COLLECTOR" .
CAUTION:
Perform this step when engine is cold.
1. Fuel feed hose (with damper) 2. Quick connector cap 3. Centralized under-floor piping
4. Fuel tube 5. Spacer 6. Clip
7.O-ring (black) (VQ23DE)
O-ring (blue) (VQ35DE)8. Fuel injector 9.O-ring (green) (VQ23DE)
O-ring (brown) (VQ35DE)
10. O-ring 11. Fuel damper
A. Refer to EM-157
PBIC4686E
Page 2264 of 3502
![NISSAN TEANA 2003 Service Manual EM-156
[VQ]
FUEL INJECTOR AND FUEL TUBE
4. Remove air duct (inlet), air cleaner case (upper) with mass air flow sensor and air duct assembly. Refer to
EM-131, "
AIR CLEANER AND AIR DUCT" .
5. Remove NISSAN TEANA 2003 Service Manual EM-156
[VQ]
FUEL INJECTOR AND FUEL TUBE
4. Remove air duct (inlet), air cleaner case (upper) with mass air flow sensor and air duct assembly. Refer to
EM-131, "
AIR CLEANER AND AIR DUCT" .
5. Remove](/manual-img/5/57392/w960_57392-2263.png)
EM-156
[VQ]
FUEL INJECTOR AND FUEL TUBE
4. Remove air duct (inlet), air cleaner case (upper) with mass air flow sensor and air duct assembly. Refer to
EM-131, "
AIR CLEANER AND AIR DUCT" .
5. Remove intake manifold collectors (upper and lower). Refer to EM-133, "
INTAKE MANIFOLD COLLEC-
TOR" .
6. Remove fuel feed hose (with damper) from fuel tube.
CAUTION:
While hose disconnected, plug it to prevent fuel from
draining.
Do not separate fuel damper and fuel feed hose.
7. When separating fuel feed hose (with damper) and centralized under-floor piping connection, disconnect
quick connector as follows:
a. Remove quick connector cap from quick connector.
b. Disconnect quick connector from centralized under-floor piping as follows:
CAUTION:
Disconnect quick connector by using quick connector release (SST), not by picking out retainer
tabs.
i. With the sleeve side of quick connector release facing to quick connector, install quick connector release
onto fuel tube.
ii. Insert quick connector release into quick connector until sleeve
contacts and goes no further. Hold quick connector release on
that position.
CAUTION:
Inserting quick connector release hard will not disconnect
quick connector. Hold quick connector release where it
contacts and goes no further.
iii. Draw and pull out quick connector straight from centralized
under-floor piping.
CAUTION:
Pull quick connector holding “A” position as shown in
the figure.
Do not pull with lateral force applied. O-ring inside quick connector may be damaged.
Prepare container and cloth beforehand as fuel will leak out.
Avoid fire and sparks.
Keep parts away from heat source. Especially, be careful when welding is performed around
them.
Do not expose parts to battery electrolyte or other acids.
Do not bend or twist connection between quick connector and fuel feed hose (with damper) dur-
ing installation/removal.
To keep clean the connecting portion and to avoid dam-
age and foreign materials, cover them completely with
plastic bags or something similar.
PBIC2468E
PBIC1898E
PBIC1899E
