Page 297 of 3502

NISSAN TEANA 2003 Service Manual REPAIR FOR COMPONENT PARTS AT-289 D E F G H I J K L MA B AT Control Valve Upper BodyBCS001OM COMPONENTS SCIA2960J

Page 298 of 3502

NISSAN TEANA 2003 Service Manual AT-290 REPAIR FOR COMPONENT PARTS DISASSEMBLY 1. Remove valves at retainer plates. CAUTION: Do not use a magnetic pick-up tool. a. Use a screwdriver to remove retainer plates. b. Remove retainer pla

Page 299 of 3502

NISSAN TEANA 2003 Service Manual REPAIR FOR COMPONENT PARTS AT-291 D E F G H I J K L MA B AT c. Place mating surface of valve body face down, and remove internal parts. CAUTION: If a valve is hard to remove, place valve body face

Page 300 of 3502

NISSAN TEANA 2003 Service Manual AT-292 REPAIR FOR COMPONENT PARTS –Wrap a small screwdriver with vinyl tape and use it to insert valves into their proper positions. 1-2 Accumulator Valve Install 1-2 accumulator valve (1). Align

Page 301 of 3502

NISSAN TEANA 2003 Service Manual REPAIR FOR COMPONENT PARTS AT-293 D E F G H I J K L MA B AT Control Valve Lower BodyBCS001ON COMPONENTS SCIA2959J

Page 302 of 3502

NISSAN TEANA 2003 Service Manual AT-294 REPAIR FOR COMPONENT PARTS DISASSEMBLY Remove valves at retainer plate. For removal procedures, refer to AT- 2 9 0 , " DISASSEMBLY" . INSPECTION Valve Springs Check each valve spring for da

Page 303 of 3502

NISSAN TEANA 2003 Service Manual REPAIR FOR COMPONENT PARTS AT-295 D E F G H I J K L MA B AT Install control valves. For installation procedures, refer to AT- 2 9 1 , " ASSEMBLY" . Retainer Plate (Control Valve Lower Body) Instal

Page 304 of 3502

NISSAN TEANA 2003 Service Manual AT-296 REPAIR FOR COMPONENT PARTS Reverse ClutchBCS001OO COMPONENTS DISASSEMBLY 1. Check operation of reverse clutch a. Install seal ring onto drum support of oil pump cover and install reverse clut
