Page 3433 of 3502

NISSAN TEANA 2003 Service Manual WT-1
ROAD WHEELS & TYRES
E SUSPENSION
CONTENTS
C
D
F
G
H
I
J
K
L
M
SECTION WT
A
B
WT

ROAD WHEELS & TYRES
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ......................................

Page 3434 of 3502

NISSAN TEANA 2003 Service Manual WT-2
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartBES0004G
Use chart below to help you find the cause o

Page 3435 of 3502

NISSAN TEANA 2003 Service Manual ROAD WHEEL
WT-3
C
D
F
G
H
I
J
K
L
MA
B
WT

ROAD WHEELPFP:40300
InspectionBES0004H
ALUMINUM WHEEL
1. Check tyres for wear and improper inflation.
2. Check wheels for deformation, cracks and other dama

Page 3436 of 3502

NISSAN TEANA 2003 Service Manual WT-4
ROAD WHEEL AND TYRE ASSEMBLY

ROAD WHEEL AND TYRE ASSEMBLYPFP:40300
Balancing Wheels (Bonding Weight Type)BES0004I
REMOVAL
Using releasing agent, remove double-faced adhesive tape from the road

WT-4
ROAD WHEEL AND TYRE ASSEMBLY

ROAD WHEEL AND TYRE ASSEMBLYPFP:40300
Balancing Wheels (Bonding Weight Type)BES0004I
REMOVAL
Using releasing agent, remove double-faced adhesive tape from the road wheel.
CAUTION:
Be careful not to scratch the road wheel during removal.
After removing double-faced adhesive tape, wipe clean traces of releasing agent from the road
wheel.
WHEEL BALANCE ADJUSTMENT
If a tyre balance machine has adhesion balance weight mode settings and drive-in weight mode setting, select
and adjust a drive-in weight mode suitable for road wheels.
1. Set road wheel on wheel balancer using the center hole as a guide. Start the tyre balance machine.
2. When inner and outer unbalance values are shown on the tyre balance machine indicator, multiply outer
unbalance value by 5/3 to determine balance weight that should be used. Select the outer balance weight
with a value closest to the calculated value above and install it to the designated outer position of, or at the
designated angle in relation to the road wheel.
CAUTION:
Do not install the inner balance weight before installing the outer balance weight.
Before installing the balance weight, be sure to clean the mating surface of the road wheel.
Indicated unbalance value × 5/3 = balance weight to be
installed.
Calculation example:
23 g (0.81 oz) × 5/3 = 38.33 g (1.35 oz) = 40 g (1.41 oz) balance
weight (closer to calculated balance weight value)
Note that balance weight value must be closer to the calculated
balance weight value.
Example:
37.4 = 35 g (1.23 oz)
37.5 = 40 g (1.41 oz)
a. Install balance weight in the position shown in the figure.
b. When installing balance weight to road wheels, set it into the
grooved area on the inner wall of the road wheel as shown in the
figure so that the balance weight center is aligned with the tyre
balance machine indication position (angle).
CAUTION:
Always use genuine NISSAN adhesion balance weights.
Balance weights are unreusable; always replace with new
ones.
Do not install more than three sheets of balance weight.
SMA054D
SEIA0271E

Page 3437 of 3502

NISSAN TEANA 2003 Service Manual ROAD WHEEL AND TYRE ASSEMBLY
WT-5
C
D
F
G
H
I
J
K
L
MA
B
WT

c. If calculated balance weight value exceeds 50 g (1.76 oz), install
two balance weight pieces in line with each other as shown in
the fi

Page 3438 of 3502

NISSAN TEANA 2003 Service Manual WT-6
SERVICE DATA AND SPECIFICATIONS (SDS)

SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Road WheelBES0004K
Ty r eBES0004L
