Page 3129 of 3502

NISSAN TEANA 2003 Service Manual STEERING COLUMN
PS-15
C
D
E
F
H
I
J
K
L
MA
B
PS

Disassembly and AssemblyBGS0003V
COMPONENTS
DISASSEMBLY
1. Remove spring from jacket tube assembly and column mounting bracket.
2. Remove the TORX bol

Page 3130 of 3502

NISSAN TEANA 2003 Service Manual PS-16
STEERING COLUMN

INSPECTION AFTER ASSEMBLY
Check tilt mechanism operating range.
Operating range L : 31.5 mm (1.240 in)
SGIA1616E

Page 3131 of 3502

NISSAN TEANA 2003 Service Manual POWER STEERING GEAR AND LINKAGE
PS-17
C
D
E
F
H
I
J
K
L
MA
B
PS

POWER STEERING GEAR AND LINKAGEPFP:49001
Removal and InstallationBGS0003W
COMPONENTS
CAUTION:
Spiral cable may be cut if steering whee

Page 3132 of 3502

NISSAN TEANA 2003 Service Manual PS-18
POWER STEERING GEAR AND LINKAGE

7. Remove high-pressure tube and low-pressure hose of hydraulic
piping, and then drain power steering fluid. Refer to PS-39,
"HYDRAULIC LINE" .
8. Remove fixing

Page 3133 of 3502

NISSAN TEANA 2003 Service Manual POWER STEERING GEAR AND LINKAGE
PS-19
C
D
E
F
H
I
J
K
L
MA
B
PS

8. Remove high-pressure tube and low-pressure hose of hydraulic
piping, and then drain power steering fluid. Refer to PS-39,
"HYDRAULI

POWER STEERING GEAR AND LINKAGE
PS-19
C
D
E
F
H
I
J
K
L
MA
B
PS

8. Remove high-pressure tube and low-pressure hose of hydraulic
piping, and then drain power steering fluid. Refer to PS-39,
"HYDRAULIC LINE" .
9. Remove fixing bolt (lower side) of lower shaft.
10. Remove stabilizer connecting rod lower nut, and then separate
stabilizer connecting rod from stabilizer bar. Refer to FSU-7,
"Components" .
11. Remove mounting nut and bolt of transverse link ball joint, and
then remove transverse link from steering knuckle. Refer to
FSU-7, "
Components" .
12. Remove front exhaust tube. Refer to EX-2, "
EXHAUST SYS-
TEM" .
13. Remove steering hydraulic piping bracket from front suspension member and rear engine mounting insu-
lator. Refer to PS-39, "
HYDRAULIC LINE" .
14. Set jack under transaxle assembly.
15. Remove front engine mounting bracket and front engine mounting insulator mounting bolts. Refer to EM-
77, "ENGINE ASSEMBLY" .
16. Remove rear engine mounting bracket and rear engine mounting insulator mounting bolts. Refer to EM-
77, "ENGINE ASSEMBLY" .
17. Remove rear engine mounting insulator and front suspension member fixing nuts and bolts. Refer to EM-
77, "ENGINE ASSEMBLY" .
18. Set jack under front suspension member.
19. Loosen mounting nuts (front side) of front suspension member. Refer to FSU-7, "
Components" .
20. Remove mounting bolts (body side) of member stay, and then loosen nuts (front suspension member side
mounting point) of member stay. Refer to FSU-7, "
Components" .
21. Gradually lower jack to remove steering gear assembly mounting nut and bolts and remove rack mounting
bracket, rack mounting insulator and sleeve from vehicle, and then remove steering gear assembly from
vehicle.
INSTALLATION
Installation is the reverse order of removal. For tightening torque, refer to PS-17, "COMPONENTS" .
When installing lower shaft to steering gear assembly, follow the procedure listed below.
–Set rack of steering gear in the neutral position.
NOTE:
To get the neutral position of rack, turn pinion assembly and measure the distance of inner socket, and
then measure the intermediate position of the distance.
–Align rear cover cap projection (A) with the marking position (B)
of gear housing assembly.
–Install slit part of lower shaft (C) aligning with the projection (A)
of rear cover cap (1). Make sure that the slit part of lower shaft
(C) is aligned with both the projection (A) of rear cover cap (1)
and the marking position (B) of gear housing assembly.
–After installation, bleed air from the steering hydraulic system.
Refer to PS-39, "
HYDRAULIC LINE" .
–Perform final tightening of nuts and bolts on each part under
unladen conditions with tyres on level ground when removing
steering gear assembly. Check wheel alignment. Refer to FSU-
5, "Wheel Alignment Inspection" .
–Adjust neutral position of steering angle sensor after checking the wheel alignment for the models with
VDC. Refer to BRC-40, "
Adjustment of Steering Angle Sensor Neutral Position" .
INSPECTION AFTER INSTALLATION
Make sure that steering wheel operates smoothly by turning several times from full left stop to full right stop.
SGIA0987E
SGIA1140E

Page 3134 of 3502

NISSAN TEANA 2003 Service Manual PS-20
POWER STEERING GEAR AND LINKAGE

Disassembly and AssemblyBGS0003X
COMPONENTS
CAUTION:
Disassemble and assemble steering gear assembly by securing the mounting area in a vise using
copper plate

Page 3135 of 3502

NISSAN TEANA 2003 Service Manual POWER STEERING GEAR AND LINKAGE
PS-21
C
D
E
F
H
I
J
K
L
MA
B
PS

DISASSEMBLY
1. Remove cylinder tubes from gear housing assembly.
2. Remove rear cover cap from pinion assembly.
3. Using a rear cover

Page 3136 of 3502

NISSAN TEANA 2003 Service Manual PS-22
POWER STEERING GEAR AND LINKAGE

10. Remove end cover assembly with a 45 mm (1.77 in) open head
(suitable tool).
CAUTION:
Do not damage rack assembly surface when removing.
Rack assembly must b
