TIMING CHAIN
EM-189
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
a. Apply a continuous bead of liquid gasket with tube presser [SST:
WS39930000] to front timing chain case back side as shown in
the figure.
Use Genuine Liquid Gasket or equivalent.
b. Install front timing chain case as to fit its dowel pin hole together dowel pin on rear timing chain case.
c. Tighten mounting bolts to the specified torque in numerical order
as shown in the figure.
There are two types of mounting bolt. Refer to the following
for locating bolts.
d. After all bolts tightening, retighten them to the specified torque in
numerical order as shown in the figure.
CAUTION:
Be sure to wipe off any excessive liquid gasket leaking on surface mating with oil pan (upper).
e. After installing front timing chain case, check the surface height
difference between the following parts on the oil pan (upper)
mounting surface.
If not within standard, repeat the installation procedure.
15. Install right and left intake valve timing control covers as follows:
a. Install new seal rings in shaft grooves.
PBIC2648E
M8 bolts : 1, 2
: 28.4 N·m (2.9 kg-m, 21 ft-lb)
M6 bolts : Except the above
: 12.7 N·m (1.3 kg-m, 9 ft-lb)
Standard
Front timing chain case to rear timing chain case:
−0.14 to 0.14 mm (−0.006 to 0.006 in)
SEM730G
SEM943G
Page 2298 of 3502
![NISSAN TEANA 2003 Service Manual EM-190
[VQ]
TIMING CHAIN
b. Apply a continuous bead of liquid gasket with tube presser [SST:
WS39930000] to intake valve timing control covers as shown in
the figure.
Use Genuine Liquid Gasket or eq NISSAN TEANA 2003 Service Manual EM-190
[VQ]
TIMING CHAIN
b. Apply a continuous bead of liquid gasket with tube presser [SST:
WS39930000] to intake valve timing control covers as shown in
the figure.
Use Genuine Liquid Gasket or eq](/manual-img/5/57392/w960_57392-2297.png)
EM-190
[VQ]
TIMING CHAIN
b. Apply a continuous bead of liquid gasket with tube presser [SST:
WS39930000] to intake valve timing control covers as shown in
the figure.
Use Genuine Liquid Gasket or equivalent.
c. Install new collared O-ring in front timing chain case oil hole (left
and right sides).
d. Being careful not to move seal rings from the installation grooves, align dowel pins on front timing chain
case with the holes to install intake valve timing control covers.
e. Tighten mounting bolts in numerical order as shown in the fig-
ure.
16. Install crankshaft pulley as follows:
a. Install crankshaft pulley, taking care not to damage front oil seal.
When press-fitting crankshaft pulley with plastic hammer, tap on its center portion (not circumference).
b. Fix crankshaft with pulley holder [SST: KV10109300].
c. Tighten crankshaft pulley bolt.
d. Place a matching mark (A) on crank pulley (1) aligning with the
matching (B) of crank pulley mounting bolt (2). Tighten the bolts
90 degrees (one marks).
SBIA0492E
PBIC2631E
PBIC0918E
: 44.1 N·m (4.5 kg-m, 33 ft-lb)
PBIC4627J
Page 2299 of 3502
![NISSAN TEANA 2003 Service Manual TIMING CHAIN
EM-191
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
e. Rotate crankshaft pulley in normal direction (clockwise when viewed from engine front) to confirm it turns
smoothly.
17. For the following opera NISSAN TEANA 2003 Service Manual TIMING CHAIN
EM-191
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
e. Rotate crankshaft pulley in normal direction (clockwise when viewed from engine front) to confirm it turns
smoothly.
17. For the following opera](/manual-img/5/57392/w960_57392-2298.png)
TIMING CHAIN
EM-191
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
e. Rotate crankshaft pulley in normal direction (clockwise when viewed from engine front) to confirm it turns
smoothly.
17. For the following operations, perform steps in the reverse order of removal.
INSPECTION AFTER INSTALLATION
Inspection for Leaks
The following are procedures for checking fluids leak, lubricates leak and exhaust gases leak.
Before starting engine, check oil/fluid levels including engine coolant and engine oil. If less than required
quantity, fill to the specified level. Refer to MA-14, "
RECOMMENDED FLUIDS AND LUBRICANTS" .
Use procedure below to check for fuel leakage.
–Turn ignition switch “ON” (with engine stopped). With fuel pressure applied to fuel piping, check for fuel
leakage at connection points.
–Start engine. With engine speed increased, check again for fuel leakage at connection points.
Run engine to check for unusual noise and vibration.
NOTE:
If hydraulic pressure inside timing chain tensioner drops after removal/installation, slack in the guide may
generate a pounding noise during and just after engine start. However, this is normal. Noise will stop after
hydraulic pressure rises.
Warm up engine thoroughly to make sure there is no leakage of fuel, exhaust gases, or any oil/fluids
including engine oil and engine coolant.
Bleed air from lines and hoses of applicable lines, such as in cooling system.
After cooling down engine, again check oil/fluid levels including engine oil and engine coolant. Refill to the
specified level, if necessary.
Summary of the inspection items:
* Transmission/transaxle/CVT fluid. power steering fluid, brake fluid, etc.Item Before starting engine Engine running After engine stopped
Engine coolant Level Leakage Level
Engine oil Level Leakage Level
Other oils and fluid* Level Leakage Level
Fuel Leakage Leakage Leakage
Exhaust gases — Leakage —
Page 2300 of 3502
EM-192
[VQ]
CAMSHAFT
CAMSHAFTPFP:13001
Removal and InstallationBBS004W1
REMOVAL
1. Remove engine assembly from vehicle, and separate front suspension member and transaxle from
engine. Refer to EM-223, "
ENGINE ASSEMBLY" .
1.Intake valve timing control solenoid
valve2. Gasket 3. Camshaft bracket (No. 2 to 4)
4. Seal washer 5. Camshaft (EXH) 6. Camshaft (INT)
7. Camshaft bracket (No. 1) 8. Dowel pin 9. Valve lifter
10. O-ring 11. Timing chain tensioner (secondary) 12. Spring
13. Plunger 14. Cylinder head (right bank) 15. Cylinder head (left bank)
16. O-ring 17.Camshaft position sensor (PHASE)
(right bank)18.Camshaft position sensor (PHASE)
(left bank)
PBIC2477E
Page 2301 of 3502
![NISSAN TEANA 2003 Service Manual CAMSHAFT
EM-193
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
2. Install engine sub-attachment with engine stand shaft [SST: KV10117001 and KV10106500] to right side
of cylinder block, then lift engine, and mount NISSAN TEANA 2003 Service Manual CAMSHAFT
EM-193
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
2. Install engine sub-attachment with engine stand shaft [SST: KV10117001 and KV10106500] to right side
of cylinder block, then lift engine, and mount](/manual-img/5/57392/w960_57392-2300.png)
CAMSHAFT
EM-193
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
2. Install engine sub-attachment with engine stand shaft [SST: KV10117001 and KV10106500] to right side
of cylinder block, then lift engine, and mount it onto engine stand [SST: ST0501S000]. Refer to EM-228,
"CYLINDER BLOCK" .
3. Remove front timing chain case, camshaft sprocket, timing chain and rear timing chain case. Refer to EM-
173, "TIMING CHAIN" .
4. Remove camshaft position sensors (PHASE) (right and left
banks) from cylinder head back side.
CAUTION:
Handle carefully to avoid dropping and shocks.
Do not disassemble.
Do not allow metal powder to adhere to magnetic part at
sensor tip.
Do not place sensors in a location where they are
exposed to magnetism.
5. Remove intake valve timing control solenoid valves.
Discard intake valve timing control solenoid valve gaskets and
use new gaskets for installation.
6. Remove camshaft brackets.
Mark camshafts, camshaft brackets and bolts so they are placed in the same position and direction for
installation.
Equally loosen camshaft bracket bolts in several steps in the
reverse order as shown in the figure.
7. Remove camshafts.
8. Remove valve lifters.
KBIA1046E
SEM443GA
PBIC2050E
Page 2302 of 3502
![NISSAN TEANA 2003 Service Manual EM-194
[VQ]
CAMSHAFT
Identify installation positions, and store them without mixing them up.
9. Remove chain tensioners (secondary) from both cylinder heads
(right and left banks).
Remove timing c NISSAN TEANA 2003 Service Manual EM-194
[VQ]
CAMSHAFT
Identify installation positions, and store them without mixing them up.
9. Remove chain tensioners (secondary) from both cylinder heads
(right and left banks).
Remove timing c](/manual-img/5/57392/w960_57392-2301.png)
EM-194
[VQ]
CAMSHAFT
Identify installation positions, and store them without mixing them up.
9. Remove chain tensioners (secondary) from both cylinder heads
(right and left banks).
Remove timing chain tensioner (secondary) with its stopper
pin attached.
NOTE:
Stopper pin was attached when timing chain (secondary) was
removed.
INSPECTION AFTER REMOVAL
Camshaft Runout
1. Put V-block on precise flat table, and support No. 2 and 4 journal
of camshaft.
CAUTION:
Do not support journal No. 1 (on the side of camshaft
sprocket) because it has a different diameter from the other
three locations.
2. Set dial indicator vertically to No. 3 journal.
3. Turn camshaft to one direction with hands, and measure cam-
shaft runout on dial indicator. (Total indicator reading)
4. If it exceeds the limit, replace camshaft.
Camshaft Cam Height
1. Measure camshaft cam height with micrometer.
2. If wear is beyond the limit, replace camshaft.
PBIC2111E
Standard : 0.02 mm (0.0010 in)
Limit : 0.05 mm (0.0020 in)PBIC0929E
Standard cam height
Intake
VQ23DE : 44.265 - 44.455 mm (1.7427 - 1.7502 in)
VQ35DE : 44.865 - 45.055 mm (1.7663 - 1.7738 in)
Exhaust
VQ23DE : 43.405 - 43.595 mm (1.7089 - 1.7163 in)
VQ35DE : 44.865 - 45.055 mm (1.7663 - 1.7738 in)
Cam wear limit
: 0.2 mm (0.008 in)
EMQ0072D
Page 2303 of 3502
![NISSAN TEANA 2003 Service Manual CAMSHAFT
EM-195
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
Camshaft Journal Oil Clearance
CAMSHAFT JOURNAL DIAMETER
Measure outer diameter of camshaft journal with micrometer.
CAMSHAFT BRACKET INNER DIAMETER
NISSAN TEANA 2003 Service Manual CAMSHAFT
EM-195
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
Camshaft Journal Oil Clearance
CAMSHAFT JOURNAL DIAMETER
Measure outer diameter of camshaft journal with micrometer.
CAMSHAFT BRACKET INNER DIAMETER](/manual-img/5/57392/w960_57392-2302.png)
CAMSHAFT
EM-195
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
Camshaft Journal Oil Clearance
CAMSHAFT JOURNAL DIAMETER
Measure outer diameter of camshaft journal with micrometer.
CAMSHAFT BRACKET INNER DIAMETER
Tighten camshaft bracket bolt with the specified torque. Refer to EM-197, "INSTALLATION" for the tight-
ening procedure.
Measure inner diameter “A” of camshaft bracket with bore
gauge.
CAMSHAFT JOURNAL OIL CLEARANCE
(Oil clearance) = (Camshaft bracket inner diameter) – (Camshaft journal diameter)
If it exceeds the limit, replace either or both camshaft and cylinder head.
NOTE:
Camshaft bracket cannot be replaced as a single part, because it is machined together with cylinder head.
Replace whole cylinder head assembly.
Camshaft End Play
Install dial indicator in thrust direction on front end of camshaft.
Measure the end play of dial indicator when camshaft is moved
forward/backward (in direction to axis).Standard:
No. 1 : 25.935 - 25.955 mm (1.0211 - 1.0218 in)
No. 2, 3, 4 : 23.445 - 23.465 mm (0.9230 - 0.9238 in)
PBIC0040E
Standard:
No. 1 : 26.000 - 26.021 mm (1.0236 - 1.0244 in)
No. 2, 3, 4 : 23.500 - 23.521 mm (0.9252 - 0.9260 in)
PBIC1645E
Standard:
No. 1 : 0.045 - 0.086 mm (0.0018 - 0.0034 in)
No. 2, 3, 4 : 0.035 - 0.076 mm (0.0014 - 0.0030 in)
Limit : 0.15 mm (0.0059 in)
Standard : 0.115 - 0.188 mm (0.0045 - 0.0074 in)
Limit : 0.24 mm (0.0094 in)
SEM864E
Page 2304 of 3502
![NISSAN TEANA 2003 Service Manual EM-196
[VQ]
CAMSHAFT
Measure the following parts if out of the limit.
–Dimension “A” for camshaft No. 1 journal
–Dimension “B” for cylinder head No. 1 journal bearing.
Refer to the sta NISSAN TEANA 2003 Service Manual EM-196
[VQ]
CAMSHAFT
Measure the following parts if out of the limit.
–Dimension “A” for camshaft No. 1 journal
–Dimension “B” for cylinder head No. 1 journal bearing.
Refer to the sta](/manual-img/5/57392/w960_57392-2303.png)
EM-196
[VQ]
CAMSHAFT
Measure the following parts if out of the limit.
–Dimension “A” for camshaft No. 1 journal
–Dimension “B” for cylinder head No. 1 journal bearing.
Refer to the standards above, and then replace camshaft and/or
cylinder head.
Camshaft Sprocket Runout
1. Put V-block on precise flat table, and support No. 2 and 4 journal of camshaft.
CAUTION:
Do not support journal No. 1 (on the side of camshaft sprocket) because it has a different diameter
from the other three locations.
2. Measure the camshaft sprocket runout with dial indicator. (Total
indicator reading)
If it exceeds the limit, replace camshaft sprocket.
Valve Lifter
Check if surface of valve lifter has any wear or cracks.
If anything above is found, replace valve lifter. Refer to EM-202,
"Valve Clearance" .
Valve Lifter Clearance
VALVE LIFTER OUTER DIAMETER
Measure outer diameter at 1/2 height of valve lifter with
micrometer since valve lifter is in barrel shape.Standard : 27.500 - 27.548 mm (1.0827 - 1.0846 in)
Standard : 27.360 - 27.385 mm (1.0772 - 1.0781 in)
KBIA2404J
Limit : 0.15 mm (0.0059 in)
PBIC0930E
KBIA0182E
Standard
VQ23DE : 29.977 - 29.987 mm (1.1802 - 1.1806 in)
VQ35DE : 33.977 - 33.987 mm (1.3377 - 1.3381 in)
JEM798G
