Page 2561 of 3502

NISSAN TEANA 2003 Service Manual REAR WINDOW DEFOGGER GW-67 C D E F G H J K L MA B GW 4. CHECK REAR WINDOW DEFOGGER RELAY GROUND CIRCUIT 1. Turn ignition switch OFF. 2. Install rear window defogger relay. 3. Turn ignition switch ON

Page 2562 of 3502

NISSAN TEANA 2003 Service Manual GW-68 REAR WINDOW DEFOGGER 2. CHECK GROUND CIRCUIT 1. Turn ignition switch OFF. 2. Check continuity between rear window defogger connector B252 terminal 2 and ground. OK or NG OK >> Check filament.

Page 2563 of 3502

NISSAN TEANA 2003 Service Manual REAR WINDOW DEFOGGER GW-69 C D E F G H J K L MA B GW 2. CHECH REAR WINDOW DOFOGGER RELAY POWER SUPPLY CIRCUIT 1. Turn ignition switch OFF. 2. Remove rear window defogger relay. 3. Turn ignition swit

Page 2564 of 3502

NISSAN TEANA 2003 Service Manual GW-70 REAR WINDOW DEFOGGER Check Driver Side Door Mirror Defogger Circuit BIS0010C 1. CHECK DOOR MIRROR DEFOGGER POWER SUPPLY CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect door mirror (driver

Page 2565 of 3502

NISSAN TEANA 2003 Service Manual REAR WINDOW DEFOGGER GW-71 C D E F G H J K L MA B GW Check Passenger Side Door Mirror Defogger Circuit BIS0010D 1. CHECK DOOR MIRROR DEFOGGER POWER SUPPLY CIRCUIT 1. Turn ignition switch OFF. 2. Dis

Page 2566 of 3502

NISSAN TEANA 2003 Service Manual GW-72 REAR WINDOW DEFOGGER Check Filament BIS0010E 1. When measuring voltage, wrap tin foil around the top of the neg- ative probe. Then press the foil against the wire with your finger. 2. Attach p

Page 2567 of 3502

NISSAN TEANA 2003 Service Manual REAR WINDOW DEFOGGER GW-73 C D E F G H J K L MA B GW REPAIRING PROCEDURE 1. Wipe broken heat wire and its surrounding area with a cloth dampened in alcohol to clean. 2. Apply a small amount of condu

Page 2568 of 3502

NISSAN TEANA 2003 Service Manual GW-74 DOOR MIRROR DOOR MIRRORPFP:96301 Precautions to Handle Retractable Power Door MirrorsBIS0010G Do not manually operate retractable power door mirrors. If mirror is operated manually, be sure
