Page 2361 of 3502

NISSAN TEANA 2003 Service Manual CYLINDER BLOCK EM-253 [VQ] C D E F G H I J K L MA EM Remove main bearing caps and bearings, and using scale on plastigage bag, measure the plastigage width. NOTE: The procedure when the measured v

Page 2362 of 3502

NISSAN TEANA 2003 Service Manual EM-254 [VQ] CYLINDER BLOCK Measure outer diameter “d” at position as shown in the figure. If reduction appears in a position other than “d”, regard it as “d”. When “d” exceeds the

Page 2363 of 3502

NISSAN TEANA 2003 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-255 [VQ] C D E F G H I J K L MA EM SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00100 Standard and LimitBBS004WE GENERAL SPECIFICATIONS VA LV E T I M I N G Engi

Page 2364 of 3502

NISSAN TEANA 2003 Service Manual EM-256 [VQ] SERVICE DATA AND SPECIFICATIONS (SDS) DRIVE BELT INTAKE MANIFOLD COLLECTOR, INTAKE MANIFOLD AND EXHAUST MANIFOLD Unit: mm (in) SPARK PLUG Unit: mm (in) Deflection adjustment Unit: mm (in

Page 2365 of 3502

NISSAN TEANA 2003 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-257 [VQ] C D E F G H I J K L MA EM CAMSHAFT AND CAMSHAFT BEARING Unit: mm (in) * 1 : Cam wear limit *2 : Total indicator reading Valve Lifter Unit: mm (in) V

Page 2366 of 3502

NISSAN TEANA 2003 Service Manual EM-258 [VQ] SERVICE DATA AND SPECIFICATIONS (SDS) Available Valve Lifter VQ23DE Unit: mm (in) VQ35DE Unit: mm (in) Identification (stamped) mark Thickness Intake Exhaust 666U 6.66 (0.2622) 668U 6.68

Page 2367 of 3502

NISSAN TEANA 2003 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-259 [VQ] C D E F G H I J K L MA EM Identification (stamped) mark Thickness Intake Exhaust 788U 788R 7.88 (0.3102) 790U 790R 7.90 (0.3110) 792U 792R 7.92 (0.3

Page 2368 of 3502

NISSAN TEANA 2003 Service Manual EM-260 [VQ] SERVICE DATA AND SPECIFICATIONS (SDS) CYLINDER HEAD Unit: mm (in) Valve Dimensions Unit: mm (in) Items Standard Limit Head surface distortion 0.03 (0.0012) 0.1 (0.004) Normal cylinder he
