NISSAN TEANA 2003 Service Manual FL-1
FUEL SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION FL
A
FL

FUEL SYSTEM
PREPARATION ........................................................... 2
Commercial Service Tools .............

Page 2418 of 3502

NISSAN TEANA 2003 Service Manual FL-2
PREPARATION

PREPARATIONPFP:00002
Commercial Service ToolsBBS005AD
Tool nameDescription
Fuel tank lock ring wrench Removing and installing fuel tank lock ring
ZZA0122D

Page 2419 of 3502

NISSAN TEANA 2003 Service Manual FUEL SYSTEM
FL-3
C
D
E
F
G
H
I
J
K
L
MA
FL

FUEL SYSTEMPFP:17503
Checking Fuel LinesBBS005AE
Inspect fuel lines, fuel filler cap and fuel tank for improper attach-
ment, leaks, cracks, damage, loose

FUEL SYSTEM
FL-3
C
D
E
F
G
H
I
J
K
L
MA
FL

FUEL SYSTEMPFP:17503
Checking Fuel LinesBBS005AE
Inspect fuel lines, fuel filler cap and fuel tank for improper attach-
ment, leaks, cracks, damage, loose connections, chafing or deterio-
ration.
If necessary, repair or replace damaged parts.
General PrecautionsBBS005AF
WARNING:
When replacing fuel line parts, be sure to observe the following.
Put a “CAUTION: FLAMMABLE” sign in the workshop.
Be sure to work in a well ventilated area and furnish workshop with a CO2 fire extinguisher.
Do not smoke while servicing fuel system. Keep open flames and sparks away from the work area.
Put drained fuel in an explosion-proof container and put the lid on securely. Keep the container in
safe area.
CAUTION:
Use gasoline required by the regulations for octane number. Refer to GI-6, "Precautions for Fuel" .
Before removing fuel line parts, perform the following procedures:
–Release fuel pressure from the fuel lines. Refer to EC-49, "FUEL PRESSURE RELEASE"
(QR20DE), or EC-392, "FUEL PRESSURE RELEASE" (VQ23DE and VQ35DE).
–Disconnect the battery cable from negative terminal.
Always replace clamps with new ones.
Do not kink or twist tubes when they are being installed.
Perform work on level place.
Do not tighten hose clamps excessively to avoid damaging hoses.
After connecting fuel tube quick connectors, make sure
quick connectors are secure.
Ensure that connector and resin tube do not contact any
adjacent parts.
After installing tubes, make sure there is no fuel leakage at
connections in the following steps.
–Apply fuel pressure to fuel lines with turning ignition switch
“ON” (with engine stopped). Then check for fuel leaks at
connections.
–Start engine and rev it up and check for fuel leaks at con-
nections.
Use only a genuine NISSAN fuel filler cap as a replacement.
If an incorrect fuel filler cap is used, the “MIL” may come
on.
For servicing “Evaporative Emission System” parts, refer to
EC-27, "
EVAPORATIVE EMISSION SYSTEM" (QR20DE), or
EC-366, "
EVAPORATIVE EMISSION SYSTEM" (VQ23DE
and VQ35DE).
SMA803A
SBIA0504E

Page 2420 of 3502

NISSAN TEANA 2003 Service Manual FL-4
FUEL LEVEL SENSOR UNIT, FUEL FILTER AND FUEL PUMP ASSEMBLY

FUEL LEVEL SENSOR UNIT, FUEL FILTER AND FUEL PUMP ASSEMBLYPFP:17042
Removal and InstallationBBS005AG
REMOVAL
WARNING:
Be sure to read

Page 2421 of 3502

NISSAN TEANA 2003 Service Manual FUEL LEVEL SENSOR UNIT, FUEL FILTER AND FUEL PUMP ASSEMBLY
FL-5
C
D
E
F
G
H
I
J
K
L
MA
FL

6. Remove inspection hole cover.
Remove cover by pushing it, then by turning clip clockwise 90
degrees and

Page 2422 of 3502

NISSAN TEANA 2003 Service Manual FL-6
FUEL LEVEL SENSOR UNIT, FUEL FILTER AND FUEL PUMP ASSEMBLY

CAUTION:
Quick connector can be disconnected when the tabs
are completely depressed. Do not twist it more than
necessary.
Do not use

Page 2423 of 3502

NISSAN TEANA 2003 Service Manual FUEL LEVEL SENSOR UNIT, FUEL FILTER AND FUEL PUMP ASSEMBLY
FL-7
C
D
E
F
G
H
I
J
K
L
MA
FL

INSTALLATION
Note the following, and install in the reverse order of removal.
Fuel Level Sensor Unit, Fuel F

Page 2424 of 3502

NISSAN TEANA 2003 Service Manual FL-8
FUEL TANK

FUEL TANKPFP:17202
Removal and InstallationBBS005AI
REMOVAL
WARNING:
Be sure to read “General Precautions” before working on the fuel system. Refer to FL-3, "
General Pre-
caution
