Page 241 of 3502

NISSAN TEANA 2003 Service Manual ON-VEHICLE SERVICE AT-233 D E F G H I J K L MA B AT Revolution Sensor ReplacementBCS00157 COMPONENTS REMOVAL AND INSTALLATION Removal 1. Remove front tire LH from vehicle. 2. Remove LH splash guard.

Page 242 of 3502

NISSAN TEANA 2003 Service Manual AT-234 ON-VEHICLE SERVICE CAUTION: Do not reuse O-ring. Apply petroleum jelly to O-ring. Be careful not to mis-connect because shape of connectors are same as turbine revolution sensor (power tra

Page 243 of 3502

NISSAN TEANA 2003 Service Manual ON-VEHICLE SERVICE AT-235 D E F G H I J K L MA B AT REMOVAL AND INSTALLATION Removal 1. Remove front tire LH from vehicle. 2. Remove LH splash guard. (Front fender side) 3. Disconnect turbine revolu

Page 244 of 3502

NISSAN TEANA 2003 Service Manual AT-236 AIR BREATHER HOSE AIR BREATHER HOSEPFP:31098 Removal and Installation [Air Breather Hose (Oil Catch Tank to Air Duct)]BCS00159 COMPONENTS (OIL CATCH TANK TO AIR DUCT) For QR20DE engine models

Page 245 of 3502

NISSAN TEANA 2003 Service Manual AIR BREATHER HOSE AT-237 D E F G H I J K L MA B AT For VQ23DE engine models SCIA2589E 1. Air duct 2. Resonator 3. Air breather hose (air duct side) 4. Oil catch tank

Page 246 of 3502

NISSAN TEANA 2003 Service Manual AT-238 AIR BREATHER HOSE REMOVAL AND INSTALLATION (QR20DE ENGINE MODELS) During removal and installation of air breather hose (air duct side) be careful of the following. Secure a mark (A) when ins

Page 247 of 3502

NISSAN TEANA 2003 Service Manual AIR BREATHER HOSE AT-239 D E F G H I J K L MA B AT Assemble air breather hose (air duct side) within 30...aligning air duct ribs so as not to contact air breather hose (air duct side) opening with

Page 248 of 3502

NISSAN TEANA 2003 Service Manual AT-240 AIR BREATHER HOSE REMOVAL AND INSTALLATION Removal 1. Remove air duct. Refer to EM-131, "AIR CLEANER AND AIR DUCT" . 2. Remove air breather hose (air duct side and A/T side) from oil catch ta
