7. CHECK NATS ANTENNA AMP. GROUND LINE CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between NATS antenna amp. connector M22 terminal 3 (B) and ground.
OK or NG
OK >> NATS antenna amp. is malfunctioning.
NG >>
Repair or replace the harness between NATS
antenna amp. and ground.
Diagnostic Procedure 6BIS000YS
“SECURITY INDICATOR LAMP DOES NOT LIGHT UP”
1. CHECK FUSE
Check 10A fuse [No.19, located in the fuse block (J/B)]
OK or NG
OK >> GO TO 2.
NG >> Replace fuse.
2. CHECK SECURITY INDICATOR LAMP
1. Install 10A fuse.
2. Start engine and then turn ignition switch OFF.
3. Check the security indicator lamp lights up.
OK or NG
OK >> INSPECTION END
NG >> GO TO 3.
3. CHECK SECURITY INDICATOR LAMP POWER SUPPLY CIRCUIT
1. Disconnect security indicator lamp connector.
2. Check voltage between security indicator lamp connector M19
terminal 1 (Y/R) and ground.
OK or NG
OK >> GO TO 4.
NG >> Check harness for open or short between fuse and
security indicator lamp. 3 (B) – Ground : Continuity should exist.
PIIA6148E
Security indicator lamp should light up.
1 (Y/R) – Ground : Battery voltage
PIIA6149E
Page 818 of 3502
BL-160
NATS(NISSAN ANTI-THEFT SYSTEM)
4. CHECK BCM FUNCTION
1. Connect security indicator lamp connector.
2. Disconnect BCM connector.
3. Check voltage between BCM connector M3 terminal 23 (L/B)
and ground.
OK or NG
OK >> BCM is malfunctioning.
Replace BCM.
Perform initialization with CONSULT-II.
For initialization, refer to “CONSULT-II Operation
Manual NATS”.
NG >> Check the following.
Harness for open or short between security indicator lamp and BCM.
Indicator lamp condition
Removal and Installation NATS Antenna Amp.BIS000YT
REMOVAL
CAUTION:
Before servicing SRS, turn ignition switch OFF, disconnect both battery cables and wait at least 3 min-
utes.
1. Remove the steering column cover. Refer to IP-10, "
Component Parts Location" .
2. Disconnect the NATS antenna amp. connector, remove the
screw and NATS antenna amp.
INSTALLATION
Install in the reverse order of removal.23 (L/B) – Ground : Battery voltage
PIIA6150E
PIIA6064E
Page 819 of 3502

BR-1
BRAKE SYSTEM
F BRAKES
CONTENTS
C
D
E
G
H
I
J
K
L
M
SECTION BR
A
B
BR
BRAKE SYSTEM
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Precautions for Brake System .................................. 3
PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
Commercial Service Tools ........................................ 4
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 5
NVH Troubleshooting Chart ..................................... 5
BRAKE PEDAL .......................................................... 6
Inspection and Adjustment ....................................... 6
ADJUSTMENT ...................................................... 6
Removal and Installation .......................................... 7
COMPONENTS .................................................... 7
REMOVAL ............................................................. 7
INSPECTION AFTER REMOVAL ......................... 8
INSTALLATION ..................................................... 8
BRAKE FLUID ............................................................ 9
Checking Brake Fluid Level ..................................... 9
Drain and Refill ......................................................... 9
Bleeding Brake System .......................................... 10
BRAKE TUBE AND HOSE ........................................11
Hydraulic Circuit ...................................................... 11
Removal and Installation of Front Brake Tube and
Hose ....................................................................... 12
REMOVAL ........................................................... 12
INSTALLATION ................................................... 12
Removal and Installation of Rear Brake Tube and
Hose ....................................................................... 12
REMOVAL ........................................................... 12
INSTALLATION ................................................... 12
Inspection After Installation .................................... 13
BRAKE MASTER CYLINDER .................................. 14
On-Board Inspection .............................................. 14
LEAK INSPECTION ............................................ 14
Removal and Installation ........................................ 14
REMOVAL ........................................................... 14INSTALLATION ................................................... 14
Disassembly and Assembly .................................... 15
COMPONENTS ................................................... 15
MODELS WITHOUT VDC ................................... 16
MODELS WITH VDC .......................................... 18
BRAKE BOOSTER ................................................... 21
On-Board Inspection and Service ........................... 21
OPERATION CHECK .......................................... 21
AIR TIGHT CHECK ............................................. 21
Removal and Installation ........................................ 22
COMPONENTS ................................................... 22
REMOVAL ........................................................... 22
INSPECTION AFTER REMOVAL ....................... 23
INSTALLATION ................................................... 23
VACUUM LINES ....................................................... 24
Components ........................................................... 24
Removal and Installation ........................................ 24
Inspection ............................................................... 25
VISUAL INSPECTION ......................................... 25
CHECK VALVE INSPECTION ............................. 25
FRONT DISC BRAKE ............................................... 26
On-Board Inspection ............................................... 26
PAD WEAR INSPECTION ................................... 26
Components ........................................................... 26
Removal and Installation of Brake Pad .................. 27
REMOVAL ........................................................... 27
INSTALLATION ................................................... 27
Removal and Installation of Brake Caliper Assembly
... 28
REMOVAL ........................................................... 28
INSTALLATION ................................................... 29
Disassembly and Assembly of Brake Caliper
Assembly ................................................................ 29
DISASSEMBLY ................................................... 29
INSPECTION AFTER DISASSEMBLY ................ 30
ASSEMBLY ......................................................... 30
DISC ROTOR INSPECTION ............................... 32
BRAKE BURNISHING PROCEDURE ................. 32
REAR DISC BRAKE ................................................. 33
On-Board Inspection ............................................... 33
Page 820 of 3502

BR-2 PAD WEAR INSPECTION ................................... 33
Components ........................................................... 33
Removal and Installation of Brake Pad ................... 34
REMOVAL ........................................................... 34
INSTALLATION .................................................... 34
Removal and Installation of Brake Caliper Assembly
... 35
REMOVAL ........................................................... 35
INSTALLATION .................................................... 35
Disassembly and Assembly of Brake Caliper Assembly ................................................................ 36
DISASSEMBLY .................................................... 36
INSPECTION AFTER DISASSEMBLY ................ 37
ASSEMBLY .......................................................... 37
DISC ROTOR INSPECTION ............................... 39
BRAKE BURNISHING PROCEDURE ................. 39
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 40
General Specifications ............................................ 40
Brake Pedal ............................................................ 40
Brake Booster ......................................................... 40
Check Valve ............................................................ 40
Front Disc Brake ..................................................... 40
Rear Disc Brake ...................................................... 41
Page 821 of 3502

PRECAUTIONS
BR-3
C
D
E
G
H
I
J
K
L
MA
B
BR
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
BFS000BB
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SRS and SB section of
this Service Manual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Brake SystemBFS000BC
Clean dust on front brake and rear brake with a vacuum dust collector. Do not blow with compressed air.
Recommended fluid is brake fluid “DOT 3 or DOT 4”. Refer to MA-14, "Fluids and Lubricants" .
Do not reuse drained brake fluid.
Be careful not to splash brake fluid on painted areas; it may cause paint damage. If brake fluid is splashed
on painted surfaces of body, immediately wipe it off and them wash it away with water immediately.
To clean or wash all parts of master cylinder, disc brake caliper, use clean brake fluid.
Do not use mineral oils such as gasoline or kerosene. They will ruin rubber parts of the hydraulic system.
Use a flare nut torque wrench when installing brake tube.
When installing brake tube, be sure to check torque.
Before working, turn ignition switch OFF and disconnect electri-
cal connector of ABS actuator and electric unit (control unit) or
battery cables.
Burnish the brake contact surfaces after refinishing or replacing
rotors, after replacing pads, or if a soft pedal occurs at very low
mileage. Refer to BR-32, "
BRAKE BURNISHING PROCE-
DURE" (Front disc brake), BR-39, "BRAKE BURNISHING
PROCEDURE" (Rear disc brake).
WARNING:
Clean brake pads and shoes with a waste cloth, then wipe with a dust collector.
SBR820BA
Page 822 of 3502
BR-4
PREPARATION
PREPARATIONPFP:00002
Special Service ToolsBFS000BD
Commercial Service ToolsBFS000BE
Tool number
Tool nameDescription
GG94310000
Flare nut torque wrench
a:10 mm (0.39 in) / 12 mm (0.47 in)Installing each brake tube
NT406
Tool nameDescription
Pin punch
Tip diameter: 4 mm (0.16 in) dia.Removing and installing reservoir tank
pin
ZZA0515D
Page 823 of 3502
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING
BR-5
C
D
E
G
H
I
J
K
L
MA
B
BR
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartBFS000BF
Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
×: ApplicableReference page
BR-26
, BR-33
BR-26
, BR-33
BR-26
, BR-33—
—
BR-32, BR-39—
—
—
BR-32, BR-39
NVH in FAX, RAX and FSU, RSU section
NVH in WT section
NVH in WT section
NVH in FAX section
NVH in PS section
Possible cause and
suspected parts
Pads - damaged
Pads - uneven wear
Shims damaged
Rotor imbalance
Rotor damage
Rotor runout
Rotor deformation
Rotor deflection
Rotor rust
Rotor thickness variation
AXLE AND SUSPENSION
TYRES
ROAD WHEEL
DRIVE SHAFT
STEERING
Symptom BrakeNoise××× ×××
××
Shake× ×××
××
Shimmy, Judder×××××××××× ×
Page 824 of 3502

BR-6
BRAKE PEDAL
BRAKE PEDALPFP:46501
Inspection and AdjustmentBFS000BG
Play and clearance inspection between brake pedal and floor panel with pedal depressed.
Check brake pedal height from dash lower panel (1).
Adjust height referring to the following specifications.
ADJUSTMENT
1. Loosen stop lamp switch, brake switch and/or ASCD cancel
switch by turning it counterclockwise by 45°.
2. Loosen lock nut “A” on input rod, then rotate input rod to set,
brake pedal to the specified height, and tighten lock nut “A”.
Refer to BR-22, "
COMPONENTS" .
CAUTION:
Make sure the threaded end of input rod stays inside clevis.
3. With pedal pulled and held by hand, press stop lamp switch,
brake switch and/or ASCD cancel switch until its threaded end
contacts bracket.
4. With threaded end of stop lamp switch, brake switch and/or
ASCD cancel switch contacting bracket, rotate switch clockwise
by 45° to secure.
CAUTION:
Make sure that the clearance “C” between bracket and
end of stop lamp switch, brake switch and/or ASCD can-
cel switch is within the standard.
When locking stop lamp switch and ASCD cancel switch,
pull brake pedal to avoid moving toward the direction
where switches are being pressed.
5. Check the pedal play.
CAUTION:
Make sure that stop lamps goes off when pedal is released.
6. Start engine to check brake pedal depressed height.
H1Brake pedal free height (from dash lower panel
(1) top surface)195.8 - 205.8 mm
(7.71 - 8.10 in)
H
2
Depressed brake pedal height
[under a force of 490 N (50 kg, 110 lb) with
engine running]More than 115 mm
(4.53 in)
CClearance between the threaded end of stop
lamp switch, brake switch and/or ASCD cancel
switch (2) and bracket (3)0.74 - 1.96 mm
(0.0291 - 0.0772 in)
A Pedal play3-11 mm
(0.12 - 0.43 in)
SFIA2743J
PFIA0824E
