Page 273 of 3502

NISSAN TEANA 2003 Service Manual DISASSEMBLY AT-265 D E F G H I J K L MA B AT b. Remove low one-way clutch with a hook made of wire. Check low one-way clutch, and replace if damaged or worn. c. Remove snap ring with flat-bladed sc

Page 274 of 3502

NISSAN TEANA 2003 Service Manual AT-266 DISASSEMBLY f. Check that low one-way clutch rotates counter-clockwise around front planetary carrier. Then try to turn it clockwise and check that it is locked. Replace low one-way clutch i

Page 275 of 3502

NISSAN TEANA 2003 Service Manual DISASSEMBLY AT-267 D E F G H I J K L MA B AT b. Remove rear sun gear from rear planetary carrier. c. Remove needle bearings from rear planetary carrier. Check rear planetary carrier and needle bear

Page 276 of 3502

NISSAN TEANA 2003 Service Manual AT-268 DISASSEMBLY 43. Remove needle bearing from overrun clutch hub. Check needle bearing and overrun clutch hub, and replace if damaged or worn. 44. Remove forward clutch assembly and overrun clu

Page 277 of 3502

NISSAN TEANA 2003 Service Manual DISASSEMBLY AT-269 D E F G H I J K L MA B AT c. Remove output shaft adjusting shim. d. Remove output shaft assembly. If output shaft assembly came off with side cover, tap side cover with a soft ha

Page 278 of 3502

NISSAN TEANA 2003 Service Manual AT-270 DISASSEMBLY 47. Disassemble reduction pinion gear according to the following procedures. a. Set manual shaft to “P” position to fix idler gear. b. Unlock idler gear lock nut with pin punc

Page 279 of 3502

NISSAN TEANA 2003 Service Manual DISASSEMBLY AT-271 D E F G H I J K L MA B AT 50. Remove parking actuator support from transaxle case. Check parking actuator support, and replace if damaged or worn. 51. Remove LH differential side

Page 280 of 3502

NISSAN TEANA 2003 Service Manual AT-272 REPAIR FOR COMPONENT PARTS REPAIR FOR COMPONENT PARTSPFP:00000 Manual ShaftBCS001OJ COMPONENTS REMOVAL 1. Remove detent spring from transaxle case. 2. Drive out retaining pin of manual plate
