TROUBLE DIAGNOSIS FOR SYMPTOMS
CVT-163
D
E
F
G
H
I
J
K
L
MA
B
CVT
TCM terminal data are reference values, measured between each terminal and ground.
TerminalWire
colorItem Condition Data (Approx.)
5 L CAN-H — —
6 P CAN-L — —
8GBack-up lamp
relaySelector lever in “R” position. 0 V
Selector lever in other positions. Battery voltage
13 G/W ROM assembly — —
14 L/R ROM assembly — —
15 BR/R ROM assembly — —
31 O K-LINE — —
42 W/R Sensor ground Always 0 V
46 L/O Sensor power— 5.0 V
—0 V
Page 1170 of 3502

CVT-164
TROUBLE DIAGNOSIS FOR SYMPTOMS
CVT Indicator Lamp Does Not Come OnBCS001MB
SYMPTOM:
CVT indicator lamp does not come on for about 2 seconds when turning ignition switch to ON.
DIAGNOSTIC PROCEDURE
1. CHECK CAN COMMUNICATION LINE
Perform the self-diagnosis check. Refer to CVT-47, "
SELF-DIAGNOSTIC RESULT MODE" .
Is any malfunction of the
“U1000 CAN COMM CIRCUIT” indicated in the results?
YES >> Check CAN communication line. Refer to CVT-53, "DTC U1000 CAN COMMUNICATION LINE" .
NO >> GO TO 2.
2. CHECK TCM POWER SOURCE
1. Turn ignition switch ON.
2. Check voltage between TCM connector terminals and ground.
Refer to CVT-135, "
Wiring Diagram — CVT — POWER" .
OK or NG
OK >> GO TO 4.
NG >> GO TO 3.
3. DETECT MALFUNCTIONING ITEM
Check the following.
Harness for short or open between ignition switch and TCM connector terminal 10, 19
Refer to CVT-135, "
Wiring Diagram — CVT — POWER" .
10A fuse (No.83, located in the IPDM E/R). Refer to CVT-135, "Wiring Diagram — CVT — POWER" .
Ignition switch. Refer to PG-3, "POWER SUPPLY ROUTING CIRCUIT" .
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4. CHECK TCM GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check continuity between TCM connector terminals and ground.
Refer to CVT-135, "
Wiring Diagram — CVT — POWER" .
OK or NG
OK >> GO TO 5.
NG >> Repair open circuit or short to ground or short to power
in harness or connectors.
Name Connec-
tor Terminal Voltage (Approx.)
Power supply F10610 Battery voltage
19 Battery voltage
SCIA4737E
Name Connec-
tor Terminal Continuity
Ground F10725
Ye s
48
SCIA2671E
Page 1171 of 3502

TROUBLE DIAGNOSIS FOR SYMPTOMS
CVT-165
D
E
F
G
H
I
J
K
L
MA
B
CVT
5. DETECT MALFUNCTIONING ITEM
Check the following.
Harness and fuse for short or open between ignition switch and CVT indicator lamp
Refer to PG-3, "
POWER SUPPLY ROUTING CIRCUIT" .
OK or NG
OK >> GO TO 6.
NG >> Repair or replace damaged parts.
6. CHECK SYMPTOM
Check again. Refer to CVT-37, "
Check Before Engine Is Started" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 7.
7. CHECK COMBINATION METERS
Check combination meters. Refer to DI-4, "
COMBINATION METERS" .
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
Engine Cannot Be Started in “P” or “N” PositionBCS001MC
SYMPTOM:
Engine cannot be started with selector lever in “P” or “N” position.
Engine can be started with selector lever in “D”, “M” or “R” position.
DIAGNOSTIC PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis check. Refer to CVT-47, "
SELF-DIAGNOSTIC RESULT MODE" .
Do the self-diagnostic results indicate PNP switch circuit or start signal circuit?
YES >> Check PNP switch circuit or start signal circuit. Refer to CVT-62, "DTC P0705 PARK/NEUTRAL
POSITION SWITCH" or CVT-56, "DTC P0615 START SIGNAL CIRCUIT" .
NO >> GO TO 2.
2. CHECK CVT POSITION
Check CVT position. Refer to CVT-179, "
Checking of CVT Position"
OK or NG
OK >> GO TO 3.
NG >> Adjust CVT position. Refer to CVT-178, "
Adjustment of CVT Position" .
3. CHECK STARTING SYSTEM
Check starting system. Refer to SC-14, "
STARTING SYSTEM" .
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
Page 1172 of 3502

CVT-166
TROUBLE DIAGNOSIS FOR SYMPTOMS
In “P” Position, Vehicle Moves Forward or Backward When PushedBCS001MD
SYMPTOM:
Vehicle moves when it is pushed forward or backward with selector lever in “P” position.
DIAGNOSTIC PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis check. Refer to CVT-47, "
SELF-DIAGNOSTIC RESULT MODE" .
Do the self-diagnostic results indicate PNP switch circuit?
YES >> Check PNP switch circuit. Refer to CVT-62, "DTC P0705 PARK/NEUTRAL POSITION SWITCH" .
NO >> GO TO 2.
2. CHECK CVT POSITION
Check CVT position. Refer to CVT-179, "
Checking of CVT Position"
OK or NG
OK >> GO TO 3.
NG >> Adjust CVT position. Refer to CVT-178, "
Adjustment of CVT Position" .
3. CHECK SYMPTOM
Check again. Refer to CVT-37, "
Check at Idle" .
OK or NG
OK >>INSPECTION END
NG >> Replace the transaxle assembly. Refer to CVT-193, "
Removal and Installation" .
In “N” Position, Vehicle MovesBCS001ME
SYMPTOM:
Vehicle moves forward or backward when selecting “N” position.
DIAGNOSTIC PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis check. Refer to CVT-47, "
SELF-DIAGNOSTIC RESULT MODE" .
Do the self-diagnostic results indicate PNP switch circuit?
YES >> Check PNP switch circuit. Refer to CVT-62, "DTC P0705 PARK/NEUTRAL POSITION SWITCH" .
NO >> GO TO 2.
2. CHECK CVT POSITION
Check CVT position. Refer to CVT-179, "
Checking of CVT Position"
OK or NG
OK >> GO TO 3.
NG >> Adjust CVT position. Refer to CVT-178, "
Adjustment of CVT Position" .
3. CHECK CVT FLUID LEVEL
Check CVT fluid level. Refer to CVT-13, "
Checking CVT Fluid" .
OK or NG
OK >> GO TO 4.
NG >> Refill CVT fluid.
4. CHECK SYMPTOM
Check again. Refer to CVT-37, "
Check at Idle" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 5.
Page 1173 of 3502

TROUBLE DIAGNOSIS FOR SYMPTOMS
CVT-167
D
E
F
G
H
I
J
K
L
MA
B
CVT
5. CHECK TCM
1. Check TCM input/output signal. Refer to CVT-40, "
TCM Input/Output Signal Reference Values" .
2. If NG, re-check TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the transaxle assembly. Refer to CVT-193, "Removal and Installation" .
NG >> Repair or replace damaged parts.
Large Shock “N” → “R” PositionBCS001MF
SYMPTOM:
There is large shock when shifting from “N” to “R” position.
DIAGNOSTIC PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis check. Refer to CVT-47, "
SELF-DIAGNOSTIC RESULT MODE" .
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system. Refer to CVT-47, "Display Items List" .
NO >> GO TO 2.
2. CHECK ENGINE IDLE SPEED
Check engine idle speed. Refer to EC-387, "
Idle Speed and Ignition Timing Check" .
OK or NG
OK >> GO TO 3.
NG >> Repair.
3. CHECK CVT FLUID LEVEL
Check CVT fluid level. Refer to CVT-13, "
Checking CVT Fluid" .
OK or NG
OK >> GO TO 4.
NG >> Refill CVT fluid.
4. CHECK LINE PRESSURE
Check line pressure at idle. Refer to CVT-33, "
LINE PRESSURE TEST" .
OK or NG
OK >> GO TO 5.
NG >> Check the malfunctioning item. Refer to CVT-34, "
Judgement of Line Pressure Test" .
5. CHECK SYMPTOM
Check again. Refer to CVT-37, "
Check at Idle" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 6.
6. CHECK TCM
1. Check TCM input/output signals. Refer to CVT-40, "
TCM Input/Output Signal Reference Values" .
2. If NG, re-check TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the transaxle assembly. Refer to CVT-193, "Removal and Installation" .
NG >> Repair or replace damaged parts.
Page 1174 of 3502

CVT-168
TROUBLE DIAGNOSIS FOR SYMPTOMS
Vehicle Does Not Creep Backward in “R” PositionBCS001MG
SYMPTOM:
Vehicle does not creep backward when selecting “R” position.
DIAGNOSTIC PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis check. Refer to CVT-47, "
SELF-DIAGNOSTIC RESULT MODE" .
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system. Refer to CVT-47, "Display Items List" .
NO >> GO TO 2.
2. CHECK CVT POSITION
Check CVT position. Refer to CVT-179, "
Checking of CVT Position"
OK or NG
OK >> GO TO 3.
NG >> Adjust CVT podition. Refer to CVT-178, "
Adjustment of CVT Position" .
3. CHECK CVT FLUID LEVEL
Check CVT fluid level. Refer to CVT-13, "
Checking CVT Fluid" .
OK or NG
OK >> GO TO 4.
NG >> Refill CVT fluid.
4. CHECK LINE PRESSURE
Check line pressure at idle. Refer to CVT-33, "
LINE PRESSURE TEST" .
OK or NG
OK >> GO TO 5.
NG >> Check the malfunctioning item. Refer to CVT-34, "
Judgement of Line Pressure Test" .
5. CHECK SYMPTOM
Check again. Refer to CVT-37, "
Check at Idle" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 6.
6. CHECK TCM
1. Check TCM input/output signals. Refer to CVT-40, "
TCM Input/Output Signal Reference Values" .
2. If NG, re-check TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the transaxle assembly. Refer to CVT-193, "Removal and Installation" .
NG >> Repair or replace damaged parts.
Page 1175 of 3502

TROUBLE DIAGNOSIS FOR SYMPTOMS
CVT-169
D
E
F
G
H
I
J
K
L
MA
B
CVT
Vehicle Does Not Creep Forward in “D” PositionBCS001MH
SYMPTOM:
Vehicle does not creep forward when selecting “D” position.
DIAGNOSTIC PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis check. Refer to CVT-47, "
SELF-DIAGNOSTIC RESULT MODE" .
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system. Refer to CVT-47, "Display Items List" .
NO >> GO TO 2.
2. CHECK CVT POSITION
Check CVT position. Refer to CVT-179, "
Checking of CVT Position"
OK or NG
OK >> GO TO 3.
NG >> Adjust CVT position. Refer to CVT-178, "
Adjustment of CVT Position" .
3. CHECK CVT FLUID LEVEL
Check CVT fluid level. Refer to CVT-13, "
Checking CVT Fluid" .
OK or NG
OK >> GO TO 4.
NG >> Refill CVT fluid.
4. CHECK LINE PRESSURE
Check line pressure at idle. Refer to CVT-33, "
LINE PRESSURE TEST" .
OK or NG
OK >> GO TO 5.
NG >> Check the malfunctioning item. Refer to CVT-34, "
Judgement of Line Pressure Test" .
5. CHECK SYMPTOM
Check again. Refer to CVT-37, "
Check at Idle" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 6.
6. CHECK TCM
1. Check TCM input/output signals. Refer to CVT-40, "
TCM Input/Output Signal Reference Values" .
2. If NG, re-check TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the transaxle assembly. Refer to CVT-193, "Removal and Installation" .
NG >> Repair or replace damaged parts.
Page 1176 of 3502

CVT-170
TROUBLE DIAGNOSIS FOR SYMPTOMS
CVT Does Not ShiftBCS001MI
SYMPTOM:
CVT does not shift at the specified speed on “Cruise Test”.
DIAGNOSTIC PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis check. Refer to CVT-47, "
SELF-DIAGNOSTIC RESULT MODE" .
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system. Refer to CVT-47, "Display Items List" .
NO >> GO TO 2.
2. CHECK CVT POSITION
Check CVT position. Refer to CVT-179, "
Checking of CVT Position"
OK or NG
OK >> GO TO 3.
NG >> Adjust CVT position. Refer to CVT-178, "
Adjustment of CVT Position" .
3. CHECK CVT FLUID LEVEL
Check CVT fluid level. Refer to CVT-13, "
Checking CVT Fluid" .
OK or NG
OK >> GO TO 4.
NG >> Refill CVT fluid.
4. CHECK LINE PRESSURE
Check line pressure at idle. Refer to CVT-33, "
LINE PRESSURE TEST" .
OK or NG
OK >> GO TO 5.
NG >> Check the malfunctioning item. Refer to CVT-34, "
Judgement of Line Pressure Test" .
5. CHECK SYMPTOM
Check again. Refer to CVT-38, "
Cruise Test" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 6.
6. CHECK TCM
1. Check TCM input/output signals. Refer to CVT-40, "
TCM Input/Output Signal Reference Values" .
2. If NG, re-check TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the transaxle assembly. Refer to CVT-193, "Removal and Installation" .
NG >> Repair or replace damaged parts.
