Page 969 of 3502

NISSAN TEANA 2003 Service Manual RADIATOR (ALUMINUM TYPE) CO-17 [QR] C D E F G H I J K L MA CO Grip the crimped edge and bend it upwards so that radiator plate pliers B slips off. CAUTION: Do not bend excessively. In areas where

Page 970 of 3502

NISSAN TEANA 2003 Service Manual CO-18 [QR] RADIATOR (ALUMINUM TYPE) 2. Install sealing rubber while pushing it in with fingers. CAUTION: Be careful not to twist sealing rubber. 3. Caulk tank in numerical order as shown in the figu

Page 971 of 3502

NISSAN TEANA 2003 Service Manual RADIATOR (ALUMINUM TYPE) CO-19 [QR] C D E F G H I J K L MA CO 4. Make sure that the rim is completely crimped down. 5. Make sure that there is no leakage. Refer to CO-19, " INSPECTION" . INSPECTION

Page 972 of 3502

NISSAN TEANA 2003 Service Manual CO-20 [QR] COOLING FAN COOLING FANPFP:21140 Removal and InstallationBBS005A8 REMOVAL 1. Drain engine coolant from radiator. Refer to CO-10, "Changing Engine Coolant" . CAUTION: Perform this step w

Page 973 of 3502

NISSAN TEANA 2003 Service Manual COOLING FAN CO-21 [QR] C D E F G H I J K L MA CO Disassembly and Assembly BBS005A9 DISASSEMBLY 1. Remove cooling fans (RH and LH) from fan motors. 2. Remove fan motors from fan shroud. INSPECTION AF

Page 974 of 3502

NISSAN TEANA 2003 Service Manual CO-22 [QR] WATER PUMP WATE R P U M PPFP:21020 Removal and InstallationBBS005AA REMOVAL 1. Drain engine coolant from radiator drain plug at the bottom of radiator and from water drain plug on engine

Page 975 of 3502

NISSAN TEANA 2003 Service Manual WATER PUMP CO-23 [QR] C D E F G H I J K L MA CO INSPECTION AFTER REMOVAL Visually check if there is no significant dirt or rusting on water pump body and vane. Make sure that there is no looseness

Page 976 of 3502

NISSAN TEANA 2003 Service Manual CO-24 [QR] THERMOSTAT AND WATER CONTROL VALVE THERMOSTAT AND WATER CONTROL VALVEPFP:21200 Removal and InstallationBBS005AB REMOVAL 1. Drain engine coolant from radiator drain plug at the bottom of r
