SUNLOAD SENSORPFP:27721
Removal and InstallationBJS000H9
REMOVAL
1. Remove sunload sensor garnish.
2. Disconnect sunload sensor connector, and then remove sunload
sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA3279E
Page 490 of 3502

ATC-112
INTAKE SENSOR
INTAKE SENSORPFP:27723
Removal and InstallationBJS000HA
REMOVAL
1. Remove low-pressure pipe 2 and high-pressure pipe 2. Refer to ATC-140, "Removal and Installation of
Low-pressure Pipe 2 and High-pressure Pipe 2" .
CAUTION:
Cap or wrap the joint of the pipe with suitable material such as vinyl tape to avoid the entry of air.
2. Slide evaporator to passenger side, and then remove intake
sensor.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Replace O-rings of A/C piping with new ones, and then apply compressor oil to it when installing
it.
Mark the mounting position of intake sensor bracket prior to removal so that the reinstalled sen-
sor can be located in the same position.
Female-side piping connection is thin and easy to deform. Slowly insert the male-side piping
straight in axial direction.
Insert piping securely until a click is heard.
After piping connection is completed, pull male-side piping by hand to make sure that connection
does not come loose.
When recharging refrigerant, check for leaks.
RJIA3281E
Page 491 of 3502
BLOWER UNIT
ATC-113
C
D
E
F
G
H
I
K
L
MA
B
AT C
BLOWER UNITPFP:27200
Removal and InstallationBJS000HB
REMOVAL
1. Remove instrument passenger lower panel. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove mounting nuts, and then remove ECM with bracket
attached.
3. Disconnect fan control amp. connector and blower fan motor
connector.
4. Remove harness clip from blower unit.
5. Remove blower unit mounting bolts and screw, and then discon-
nect intake door motor connector.
CAUTION:
Move blower unit rightward, and remove locating pin (1
part) and joint. Then remove blower unit downward.
6. Remove blower unit.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Make sure locating pin (1 part) and joint are securely inserted.
RJIA3292E
RJIA3293E
Page 492 of 3502
ATC-114
BLOWER UNIT
Disassembly and AssemblyBJS000HC
CAUTION:
If retaining tabs are damaged while disassembling blower unit,
use 7 screws (27111-2Y000) to assemble blower unit.
1. Intake adapter 2. Plate clip 3. Nut
4. Blower fan 5. Washer 6. Fan control amp.
7. Screw 8. Motor cover 9. Cooling hose
10. Intake lower case 11. Intake door 1 12. Intake door lever 1
13. Intake door link 14. Intake door lever 2 15. Intake door motor
16. Air conditioner filter 17. Filter cover 18. Intake door 2
19. Intake box 20. Intake upper case 21. Blower motor
RJIA3294E
RJIA3295E
Page 493 of 3502
BLOWER MOTOR
ATC-115
C
D
E
F
G
H
I
K
L
MA
B
AT C
BLOWER MOTORPFP:27226
Removal and InstallationBJS000HD
REMOVAL
1. Remove instrument passenger lower panel. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Disconnect blower motor connector.
3. Remove mounting screws, and then remove blower motor and
motor cover.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA3296E
Page 494 of 3502
ATC-116
FAN CONTROL AMPLIFIER
FAN CONTROL AMPLIFIERPFP:27761
Removal and InstallationBJS000HE
REMOVAL
1. Remove instrument passenger lower panel. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove harness clip.
3. Disconnect fan control amp. connector.
4. Remove mounting screws, and then remove fan control amp.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA3297E
Page 495 of 3502
INTAKE DOOR MOTOR
ATC-117
C
D
E
F
G
H
I
K
L
MA
B
AT C
INTAKE DOOR MOTORPFP:27730
Removal and InstallationBJS000HF
REMOVAL
1. Remove blower unit. Refer to AT C - 11 3 , "BLOWER UNIT" .
2. Remove mounting screws, and then remove intake door motor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA3298E
Page 496 of 3502
ATC-118
AIR CONDITIONER FILTER
AIR CONDITIONER FILTERPFP:27277
Removal and InstallationBJS000HG
FUNCTION
Air inside passenger compartment is kept clean at either recircula-
tion or fresh mode by installing air conditioner filter into blower unit.
REPLACEMENT TIMING
Replace air conditioner filter.
Refer to MA-9, "
CHASSIS AND BODY MAINTENANCE" .
When replacing filter, affix a caution label inside the glove box.
REPLACEMENT PROCEDURES
1. Remove instrument passenger lower panel. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Remove filter cover, and then remove air conditioner filter.
3. Take out air conditioner filter from blower unit.
4. Replace with new one and reinstall on blower unit.
5. Reinstall instrument passenger lower panel.
SJIA0573E
