NISSAN TEANA 2003 Service Manual SHIFT CONTROL SYSTEM
CVT-179
D
E
F
G
H
I
J
K
L
MA
B
CVT

Checking of CVT PositionBCS001MO
1. Place selector lever in “P” position, and turn ignition switch ON. (Do not start engine.)
2. Make sure

Page 1186 of 3502

NISSAN TEANA 2003 Service Manual CVT-180
CVT SHIFT LOCK SYSTEM

CVT SHIFT LOCK SYSTEMPFP:00000
DescriptionBCS001MP
The electrical key interlock mechanism also operates as a shift lock:
With the ignition switch turned to ON, the sel

Page 1187 of 3502

NISSAN TEANA 2003 Service Manual CVT SHIFT LOCK SYSTEM
CVT-181
D
E
F
G
H
I
J
K
L
MA
B
CVT

Wiring Diagram — CVT — SHIFTBCS001MR
TCWM0548E

Page 1188 of 3502

NISSAN TEANA 2003 Service Manual CVT-182
CVT SHIFT LOCK SYSTEM

TCWM0549E

Page 1189 of 3502

NISSAN TEANA 2003 Service Manual CVT SHIFT LOCK SYSTEM
CVT-183
D
E
F
G
H
I
J
K
L
MA
B
CVT

Shift Lock Control Unit Reference ValuesBCS001MT
SHIFT LOCK HARNESS CONNECTOR TERMINALS LAYOUT
SHIFT LOCK CONTROL UNIT INSPECTION TABLE
Shift

CVT SHIFT LOCK SYSTEM
CVT-183
D
E
F
G
H
I
J
K
L
MA
B
CVT

Shift Lock Control Unit Reference ValuesBCS001MT
SHIFT LOCK HARNESS CONNECTOR TERMINALS LAYOUT
SHIFT LOCK CONTROL UNIT INSPECTION TABLE
Shift lock control unit terminal data are reference values, measured between each terminal and ground.
NOTE:
Take care that the pointer of circuit tester swings only momentarily because the output time is so short. If the inspection is done with an
oscilloscope, it should be observed that the power source voltage lasts for 3.5 to 10 ms.
SCIA2004E
Terminal
(Wire color)Item Condition Judgement standard
1
(Y/R)Power source Always Battery voltage
2
(L)Detention switch (for
key)When selector lever is not in “P” position with key
inserted or ignition knob switch pushed.Battery voltage
When selector lever is in “P” position with key
inserted.Approx. 0 V
3
(R)Detention switch (for
shift)When selector lever is not in “P” position. Battery voltage
When selector lever is in “P” position. Approx. 0 V
4
(R/G)Stop lamp switchWhen brake pedal is depressed Battery voltage
When brake pedal is released Approx. 0 V
5
(V/W)Vehicle speed signal
(8pulse signal)Speed meter is operatedRefer to DI-13, "
Terminals and Refer-
ence Value for Unified Meter and A/C
Amp." .
6
(G)Ignition signalIgnition switch: except ON Approx. 0 V
Ignition switch: ON Battery voltage
7
(R/W)Shift lock solenoid
When selector lever is in “P” position, brake
pedal is depressed, and ignition switch is ON.
When selector lever is not in “P” position, igni-
tion switch is ON, and vehicle speed is 10 km/h
(6 MPH) or less.
Within 3 minutes, after ignition switch turning to
other position from ON position, while selector
lever is not in “P” position and vehicle speed is
10 km/h (6 MPH) or less.Approx. 0 V
Except the above Battery voltage
8
(B)Ground — Approx. 0 V
9
(G/B)Key lock solenoidWhen selector lever is not “P” position.Battery voltage for approx. 0.1 sec.
(Note)
When selector lever is in “P” position. Approx. 0 V
10
(G/W)Key unlock solenoidWhen selector lever is in “P” position with ignition
switch in except ON position.Battery voltage for approx. 0.1 sec.
(Note)
Except the above. Approx. 0 V

Page 1190 of 3502

NISSAN TEANA 2003 Service Manual CVT-184
CVT SHIFT LOCK SYSTEM

Component InspectionBCS001MU
SHIFT LOCK SOLENOID
Check operation by applying battery voltage to the CVT device har-
ness connector.
CAUTION:
Be sure to apply the voltag

Page 1191 of 3502

NISSAN TEANA 2003 Service Manual CVT SHIFT LOCK SYSTEM
CVT-185
D
E
F
G
H
I
J
K
L
MA
B
CVT

Key Unlock
Check operation by applying battery voltage to ignition knob switch,
key switch and key lock solenoid harness connector terminal.

Page 1192 of 3502

NISSAN TEANA 2003 Service Manual CVT-186
AIR BREATHER HOSE

AIR BREATHER HOSEPFP:31098
Removal and InstallationBCS001MV
COMPONENTS
REMOVAL
Refer to the figure for air breather hose removal procedure.
INSTALLATION
Note the following,
