Page 3337 of 3502

NISSAN TEANA 2003 Service Manual HEATED SEAT SE-81 C D E F G H J K L MA B SE Check Heated Seat Switch RH Circuit BIS0013M 1. CHECK HEATED SEAT SWITCH RH CIRCUIT (VOLTAGE) 1. Turn ignition switch OFF. 2. Disconnect heated seat switc

Page 3338 of 3502

NISSAN TEANA 2003 Service Manual SE-82 HEATED SEAT 3. CHECK HEATED SEAT SWITCH RH CIRCUIT (CONTINUITY) 1. Turn ignition switch OFF. 2. Disconnect heated seat control unit connector. 3. Check continuity between heated seat switch RH

Page 3339 of 3502

NISSAN TEANA 2003 Service Manual HEATED SEAT SE-83 C D E F G H J K L MA B SE Check Seat Heater LH Circuit BIS0013N 1. CHECK SEAT HEATER LH CIRCUIT (VOLTAGE) 1. Turn ignition switch OFF. 2. Disconnect seat heater LH connector. 3. Tu

Page 3340 of 3502

NISSAN TEANA 2003 Service Manual SE-84 HEATED SEAT 3. CHECK SEAT HEATER LH CIRCUIT (CONTINUITY) 1. Turn ignition switch OFF. 2. Disconnect heated seat control unit connector. 3. Check continuity between seat heater LH harness conne

Page 3341 of 3502

NISSAN TEANA 2003 Service Manual HEATED SEAT SE-85 C D E F G H J K L MA B SE 2. CHECK SEAT HEATER RH GROUND CIRCUIT 1. Turn ignition switch OFF. 2. Check continuity between seat heater RH harness connector B174 terminal 40 and grou

Page 3342 of 3502

NISSAN TEANA 2003 Service Manual SE-86 HEATED SEAT 2. CHECK HEATED SEAT SWITCH INDICATOR LH CIRCUIT Check voltage between heated seat switch LH harness connector and ground. OK or NG OK >> GO TO 4. NG >> Check harness connection.

Page 3343 of 3502

NISSAN TEANA 2003 Service Manual HEATED SEAT SE-87 C D E F G H J K L MA B SE Check Heated Seat Switch Indicator RH Circuit BIS0013Q 1. CHECK HEATED SEAT SWITCH INDICATOR RH POWER SUPPLY 1. Turn ignition switch ON. 2. Check voltage

Page 3344 of 3502

NISSAN TEANA 2003 Service Manual SE-88 HEATED SEAT 4. CHECK HEATED SEAT SWITCH RH GROUND CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect heated seat switch RH connector and heated seat control unit connector. 3. Check continuity
