Page 657 of 3502

NISSAN TEANA 2003 Service Manual BCM (BODY CONTROL MODULE)
BCS-15
C
D
E
F
G
H
I
J
L
MA
B
BCS

Check BCM Power Supply and Ground CircuitBKS001UJ
1. CHECK FUSES AND FUSIBLE LINK
Check for blown fuses and fusible link.
Refer to PG-3,

Page 658 of 3502

NISSAN TEANA 2003 Service Manual BCS-16
BCM (BODY CONTROL MODULE)

Removal and Installation of BCMBKS001UN
REMOVAL
1. Remove the Instrument driver lower panel. Refer to IP-11,
"Removal and Installation" .
2. Remove screws.
3. Discon

Page 659 of 3502

NISSAN TEANA 2003 Service Manual BL-1
BODY, LOCK & SECURITY SYSTEM
I BODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION BL
A
B
BL

BODY, LOCK & SECURITY SYSTEM
INDEX FOR DTC ........................................................ 4
DTC No

BL-1
BODY, LOCK & SECURITY SYSTEM
I BODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION BL
A
B
BL

BODY, LOCK & SECURITY SYSTEM
INDEX FOR DTC ........................................................ 4
DTC No. Index ......................................................... 4
INTELLIGENT KEY / NATS I-KEY ........................ 4
NATS V5.0 ............................................................ 4
PRECAUTIONS .......................................................... 5
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 5
Precautions Necessary for Steering Wheel Rotation
After Battery Disconnect .......................................... 5
OPERATION PROCEDURE ................................. 5
Precautions for Work ................................................ 5
PREPARATION ........................................................... 6
Commercial Service Tools ........................................ 6
SQUEAK AND RATTLE TROUBLE DIAGNOSES ..... 7
Work Flow ................................................................ 7
CUSTOMER INTERVIEW ..................................... 7
DUPLICATE THE NOISE AND TEST DRIVE ....... 8
CHECK RELATED SERVICE BULLETINS ........... 8
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ...................................................... 8
REPAIR THE CAUSE ........................................... 8
CONFIRM THE REPAIR ....................................... 9
Generic Squeak and Rattle Troubleshooting ........... 9
INSTRUMENT PANEL .......................................... 9
CENTER CONSOLE ............................................. 9
DOORS ................................................................. 9
TRUNK ................................................................ 10
SUNROOF/HEADLINING ................................... 10
SEATS ................................................................. 10
UNDERHOOD ..................................................... 10
Diagnostic Worksheet ............................................. 11
HOOD ....................................................................... 13
Fitting Adjustment .................................................. 13
LONGITUDINAL AND LATERAL CLEARANCE
ADJUSTMENT .................................................... 13
FRONT END HEIGHT ADJUSTMENT ............... 13
SURFACE HEIGHT ADJUSTMENT ................... 14
Removal and Installation ........................................ 14
REMOVAL ........................................................... 15INSTALLATION ................................................... 15
Removal and Installation of Hood Lock Control ..... 16
REMOVAL ........................................................... 16
INSTALLATION ................................................... 16
Hood Lock Control Inspection ................................ 17
RADIATOR CORE SUPPORT .................................. 18
Removal and Installation ........................................ 18
REMOVAL ........................................................... 18
INSTALLATION ................................................... 19
FRONT FENDER ...................................................... 20
Removal and Installation ........................................ 20
REMOVAL ........................................................... 20
INSTALLATION ................................................... 20
POWER DOOR LOCK SYSTEM .............................. 21
Component Parts and Harness Connector Location ... 21
System Description ................................................. 22
LOCK OPERATION ............................................. 22
UNLOCK OPERATION ........................................ 22
KEY REMINDER DOOR SYSTEM ...................... 23
VEHICLE SPEED SENSING AUTO DOOR
LOCK FUNCTION ............................................... 23
OVERRIDE MECHANISM ................................... 23
CAN Communication System Description .............. 23
CAN Communication Unit ....................................... 23
Schematic ............................................................... 24
Wiring Diagram -D/LOCK- ...................................... 25
FIG. 1 ................................................................... 25
FIG. 2 ................................................................... 26
FIG. 3 ................................................................... 27
FIG. 4 ................................................................... 28
Terminals and Reference Value for BCM ............... 29
Work Flow ............................................................... 29
CONSULT-II Function (BCM) ................................. 30
CONSULT-II START PROCEDURE .................... 30
CONSULT-II APPLICATION ITEMS .................... 30
Trouble Diagnosis Chart by Symptom .................... 31
BCM Power Supply and Ground Circuit ................. 32
Check Door Switch ................................................. 33
Check Key Switch ................................................... 35
Check Door Lock and Unlock Switch ..................... 37

Page 660 of 3502

NISSAN TEANA 2003 Service Manual BL-2 Check Door Lock Actuator Output Signal ............... 39
Check Door Lock Actuator Circuit .......................... 40
(DRIVER SIDE AND REAR LH) .......................... 40
(PASSENGER SIDE

BL-2 Check Door Lock Actuator Output Signal ............... 39
Check Door Lock Actuator Circuit .......................... 40
(DRIVER SIDE AND REAR LH) .......................... 40
(PASSENGER SIDE AND REAR RH) ................. 41
Check Door Unlock Sensor .................................... 42
FUEL FILLER LID OPENER ..................................... 44
Component Part and Harness Connector Location ... 44
Wiring Diagram –F/LID– ......................................... 45
REMOTE KEYLESS ENTRY SYSTEM ..................... 46
Component Parts and Harness Connector Location ... 46
System Description ................................................. 46
INPUTS ............................................................... 46
OPERATED PROCEDURE ................................. 47
CAN Communication System Description .............. 48
CAN Communication Unit ....................................... 48
Schematic ............................................................... 49
Wiring Diagram — KEYLES— ................................ 50
FIG. 1 ................................................................... 50
FIG. 2 ................................................................... 51
FIG. 3 ................................................................... 52
Terminals and Reference Value for BCM ................ 53
Terminals and Reference Value for IPDM E/R ........ 54
CONSULT-II Function (BCM) .................................. 54
CONSULT-II START PROCEDURE .................... 54
CONSULT-II APPLICATION ITEMS .................... 54
Work Flow ............................................................... 56
Trouble Diagnosis Symptom Chart ......................... 56
Check Key Fob Battery and Function ..................... 57
Check ACC Switch ................................................. 58
Check Door Switch ................................................. 59
CHECK DOOR SWITCH (EXCEPT TRUNK
ROOM LAMP SWITCH) ...................................... 59
CHECK TRUNK ROOM LAMP SWITCH ............ 61
Check Key Switch ................................................... 63
Check Hazard Function .......................................... 64
Check Map Lamp and Ignition Keyhole Illumination
Function .................................................................. 64
ID Code Entry Procedure ....................................... 64
KEY FOB ID SET UP WITH CONSULT-II ........... 64
KEY FOB ID SET UP WITHOUT CONSULT-II .... 66
Key Fob Battery Replacement ................................ 67
INTELLIGENT KEY SYSTEM ................................... 68
Component Parts and Harness Connector Location ... 68
System Description ................................................. 70
DOOR LOCK/UNLOCK, TRUNK OPEN FUNC-
TION .................................................................... 70
REMOTE KEYLESS ENTRY FUNCTIONS ......... 71
ENGINE START FUNCTION ............................... 72
WARNING AND ALARM FUNCTION .................. 73
CHANGE SETTINGS FUNCTION ....................... 76
INTELLIGENT KEY REGISTRATION .................. 76
STEERING LOCK UNIT REGISTRATION .......... 77
CAN Communication System Description .............. 77
CAN Communication Unit ....................................... 77
Schematic ............................................................... 78
Wiring Diagram — I/KEY— .................................... 80
Terminals and Reference Value for Intelligent Key
Unit ......................................................................... 88
Terminals and Reference Value for Steering Lock Unit .......................................................................... 90
Terminals and Reference Value for BCM ................ 90
Diagnosis Procedure ............................................... 91
WORK FLOW ...................................................... 91
ENGINE START FUNCTION DIAGNOSTIC
PROCEDURE ...................................................... 92
CONSULT-II Functions (INTELLIGENT KEY) ......... 93
CONSULT-II Inspection Procedure ......................... 93
BASIC OPERATION ............................................ 93
CONSULT-II Application Items ................................ 93
SELF-DIAGNOSTIC RESULTS ........................... 93
DATA MONITOR .................................................. 93
WORK SUPPORT ............................................... 94
ACTIVE TEST ...................................................... 95
Trouble Diagnosis Symptom Chart ......................... 96
ALL FUNCTIONS OF THE INTELLIGENT KEY
ARE NOT OPERATING ....................................... 96
REMOTE KEYLESS ENTRY FUNCTION MAL-
FUNCTION .......................................................... 96
DOOR LOCK FUNCTION MALFUNCTION ......... 97
TRUNK OPEN FUNCTION MALFUNCTION ....... 97
HAZARD REMINDER FUNCTION MALFUNC-
TION .................................................................... 98
ENGINE START FUNCTION MALFUNCTION .... 98
WARNING CHIME FUNCTION MALFUNCTION ... 99
Check CAN Communication System ....................100
Check Intelligent Key Unit Power Supply and
Ground Circuit .......................................................100
Check Key Switch (Intelligent Key Unit Input) .......101
Check Key Switch (BCM Input) .............................102
Check Ignition knob Switch ...................................103
Check Door Switch ...............................................105
CHECK DOOR SWITCH (EXCEPT TRUNK
ROOM LAMP SWITCH) .....................................105
CHECK TRUNK ROOM LAMP SWITCH ...........107
Check Door Request Switch .................................109
Check Intelligent Key Warning Buzzer .................. 111
Check Outside Key Antenna .................................112
Check Inside Key Antenna ....................................114
Check Steering Lock Unit ......................................115
Check Headlamp Function ....................................117
Removal and Installation of Intelligent Key Unit ....117
REMOVAL ..........................................................117
INSTALLATION ..................................................117
Intelligent Key Battery Replacement .....................117
DISASSEMBLY AND ASSEMBLY OF INTELLI-
GENT KEY .........................................................117
INTELLIGENT KEY BATTERY INSPECTION ...118
DOOR ......................................................................119
Fitting Adjustment .................................................119
FRONT DOOR ...................................................119
REAR DOOR .....................................................119
STRIKER ADJUSTMENT ..................................120
Removal and Installation of Front Door ................120
REMOVAL ..........................................................120
INSTALLATION ..................................................120
Removal and Installation of Rear Door .................120
REMOVAL ..........................................................121

Page 661 of 3502

NISSAN TEANA 2003 Service Manual BL-3
C
D
E
F
G
H
J
K
L
MA
B
BL
INSTALLATION ................................................. 121
Removal and Installation of Door Weatherstrip .... 121
REMOVAL .....................................

BL-3
C
D
E
F
G
H
J
K
L
MA
B
BL
INSTALLATION ................................................. 121
Removal and Installation of Door Weatherstrip .... 121
REMOVAL ......................................................... 121
INSTALLATION ................................................. 122
FRONT DOOR LOCK ............................................. 123
Component Structure ........................................... 123
Removal and Installation ...................................... 123
REMOVAL ......................................................... 123
INSTALLATION ................................................. 126
Disassembly and Assembly ................................. 126
DOOR KEY CYLINDER ASSEMBLY ................ 126
OUTSIDE HANDLE ........................................... 127
REAR DOOR LOCK ............................................... 128
Component Structure ........................................... 128
Removal and Installation ...................................... 128
REMOVAL ......................................................... 128
INSTALLATION ................................................. 130
TRUNK LID ............................................................. 131
Fitting Adjustment ................................................ 131
LONGITUDINAL AND LATERAL CLEARANCE
ADJUSTMENT .................................................. 131
SURFACE HEIGHT ADJUSTMENT ................. 131
Removal and Installation of Trunk Lid Assembly . 132
REMOVAL ......................................................... 132
INSTALLATION ................................................. 133
Trunk Lid Stay Removal and Installation .............. 133
REMOVAL ......................................................... 133
INSTALLATION ................................................. 133
Removal and Installation of Trunk Lid Lock ......... 134
REMOVAL ......................................................... 134
INSTALLATION ................................................. 134
Trunk Lid Striker Removal and Installation ........... 134
REMOVAL ......................................................... 134
INSTALLATION ................................................. 134
Removal and Installation of Trunk Lid Weatherstrip . 135
REMOVAL ......................................................... 135
INSTALLATION ................................................. 135
TRUNK LID OPENER ............................................. 136
Component Parts and Harness Connector Location . 136
System Description .............................................. 136
TRUNK LID OPENER OPERATION ................. 136Wiring Diagram — TLID — ...................................137
Terminal and Reference Value for BCM ...............138
CONSULT-II Function (BCM) ...............................138
CONSULT-II STRAT PROCEDURE ..................138
CONSULT-II APPLICATION ITEMS ..................138
NATS(NISSAN ANTI-THEFT SYSTEM) .................139
Component Parts and Harness Connector Location .139
System Description ...............................................140
DESCRIPTION ..................................................140
SECURITY INDICATOR ....................................141
System Composition .............................................141
ECM Re-Communicating Function .......................142
Wiring Diagram – NATS – ....................................143
MODELS WITH INTELLIGENT KEY SYSTEM . 143
MODELS WITHOUT INTELLIGENT KEY SYS-
TEM ...................................................................145
Terminals and Reference Value for Steering Lock
Unit/with Intelligent Key System ...........................146
Terminals and Reference Value for Intelligent Key
Unit/with Intelligent Key System ...........................146
Terminals and Reference Value for BCM .............147
CONSULT-II ..........................................................148
CONSULT-II INSPECTION PROCEDURE ........148
CONSULT-II DIAGNOSTIC TEST MODE FUNC-
TION ..................................................................149
HOW TO READ SELF-DIAGNOSTIC RESULTS .149
NATS SELF-DIAGNOSTIC RESULT ITEM
CHART ..............................................................149
Diagnosis Procedure ............................................151
WORK FLOW ....................................................151
Trouble Diagnosis Symptom Chart .......................152
Security Indicator Inspection ................................152
Diagnostic Procedure 1 ........................................153
Diagnostic Procedure 2 ........................................154
Diagnostic Procedure 3 ........................................155
Diagnostic Procedure 4 ........................................156
Diagnostic Procedure 5 ........................................157
Diagnostic Procedure 6 ........................................159
Removal and Installation NATS Antenna Amp. ....160
REMOVAL .........................................................160
INSTALLATION .................................................160

Page 662 of 3502

NISSAN TEANA 2003 Service Manual BL-4
INDEX FOR DTC

INDEX FOR DTCPFP:00024
DTC No. Index BIS001TQ
NOTE:
When CAN COMM CIRCUIT [U1000] or CONTROL UNIT (CAN) [U1010] displayed, give priority to performing
trouble diagnosis.
INTELLIGE

Page 663 of 3502

NISSAN TEANA 2003 Service Manual PRECAUTIONS
BL-5
C
D
E
F
G
H
J
K
L
MA
B
BL

PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
BIS000VH
The Supplemental Restrai

PRECAUTIONS
BL-5
C
D
E
F
G
H
J
K
L
MA
B
BL

PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
BIS000VH
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SRS and SB section of
this Service Manual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions Necessary for Steering Wheel Rotation After Battery DisconnectBIS000VI
NOTE:
This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT
SYSTEM).
Remove and install all control units after disconnecting both battery cables with the ignition knob in the
″LOCK″ position.
Always use CONSULT-II to perform self-diagnosis as a part of each function inspection after finishing
work. If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mech-
anism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.
4. Perform the necessary repair operation.
5. When the repair work is completed, return the ignition switch to the ″LOCK″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of all control units using CONSULT-II.
Precautions for WorkBIS000VJ
After removing and installing the opening/closing parts, be sure to carry out fitting adjustments to check
their operation.
Check the lubrication level, damage, and wear of each part. If necessary, grease or replace it.

Page 664 of 3502

NISSAN TEANA 2003 Service Manual BL-6
PREPARATION

PREPARATIONPFP:00002
Commercial Service ToolsBIS000VL
Tool name Description
Engine ear Location the noise
Power tool Loosening bolts and nuts
SIIA0995E
PBIC0191E

Load next 8 pages

Page: < prev 1-10 ... 625-632 633-640 641-648 649-656 657-664 665-672 673-680 681-688 689-696 ... 3504 next >

length trip computer gearbox jacking cooling recommended oil
