Page 2337 of 3502
![NISSAN TEANA 2003 Service Manual CYLINDER BLOCK
EM-229
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
DISASSEMBLY
NOTE:
Show VQ35DE (with main bearing beam, connecting rod bearing cap is tighten by bolts) as an example unless
the figure includes s NISSAN TEANA 2003 Service Manual CYLINDER BLOCK
EM-229
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
DISASSEMBLY
NOTE:
Show VQ35DE (with main bearing beam, connecting rod bearing cap is tighten by bolts) as an example unless
the figure includes s](/manual-img/5/57392/w960_57392-2336.png)
CYLINDER BLOCK
EM-229
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
DISASSEMBLY
NOTE:
Show VQ35DE (with main bearing beam, connecting rod bearing cap is tighten by bolts) as an example unless
the figure includes specification.
1. Remove engine assembly from vehicle, and separate front suspension member and transaxle from
engine. Refer to EM-223, "
ENGINE ASSEMBLY" .
2. Remove exhaust manifolds (right and left banks). Refer to EM-140, "
EXHAUST MANIFOLD AND THREE
WAY CATALYST" .
3. Install engine sub-attachment with engine stand shaft (SST) to
right side of cylinder block.
Use spacer to engine front side.
4. Lift engine, and mount it onto engine stand (SST).
1. Reinforcement plate 2. Drive plate 3. Rear oil seal retainer
4. Knock sensor 5. Cylinder block 6. Thrust bearing (upper)
7. Main bearing (upper) 8. Crankshaft 9. Key
10. Thrust bearing (lower) 11. Main bearing (lower) 12. Main bearing cap
13. Main bearing cap bolt 14. Main bearing beam 15. Baffle plate
16. Connecting rod nut 17. Connecting rod bolt 18. Connecting rod bearing cap
19. Connecting rod bearing 20. Connecting rod 21. Snap ring
22. Piston pin 23. Piston 24. Oil ring
25. Second ring 26. Top ring 27. Pilot converter
28. Oil jet
PBIC2486E
PBIC2618E
Page 2338 of 3502
![NISSAN TEANA 2003 Service Manual EM-230
[VQ]
CYLINDER BLOCK
A widely use engine stand can be used.
CAUTION:
Use engine stand that has a load capacity [approximately
220 kg (441 lb) or more] large enough for supporting the
engine w NISSAN TEANA 2003 Service Manual EM-230
[VQ]
CYLINDER BLOCK
A widely use engine stand can be used.
CAUTION:
Use engine stand that has a load capacity [approximately
220 kg (441 lb) or more] large enough for supporting the
engine w](/manual-img/5/57392/w960_57392-2337.png)
EM-230
[VQ]
CYLINDER BLOCK
A widely use engine stand can be used.
CAUTION:
Use engine stand that has a load capacity [approximately
220 kg (441 lb) or more] large enough for supporting the
engine weight.
NOTE:
This example is engine stand for holding at transaxle mount-
ing side with drive plate removed.
5. Drain engine oil. Refer to LU-21, "
Changing Engine Oil" .
6. Drain engine coolant by removing water drain plugs from cylin-
der block both sides at “A” and “D” and cylinder block front side
at “B” as shown in the figure.
NOTE:
Water drain plug at the right bank side for VQ35DE is also used
as a connector of water pipe for oil cooler. Refer to LU-23, "
OIL
COOLER (VQ35DE)" .
7. Remove drive plate. Fix crankshaft pulley with pulley holder [SST: KV10109300], and remove mounting
bolts.
Loosen mounting bolts in diagonal order.
CAUTION:
Do not disassemble drive plate.
Do not place drive plate with signal plate facing down.
When handling signal plate, take care not to damage or
scratch it.
Handle signal plate in a manner that prevents it from
becoming magnetized.
8. Remove cylinder head. Refer to EM-210, "
CYLINDER HEAD" .
9. Remove knock sensor.
CAUTION:
Carefully handle sensor avoiding shocks.
PBIC0085E
PBIC2487E
SEM760G
Page 2339 of 3502
![NISSAN TEANA 2003 Service Manual CYLINDER BLOCK
EM-231
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
10. Remove pilot converter using pilot bushing puller (SST) or suit-
able tool as necessary.
11. Remove rear oil seal retainer.
Remove by insert NISSAN TEANA 2003 Service Manual CYLINDER BLOCK
EM-231
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
10. Remove pilot converter using pilot bushing puller (SST) or suit-
able tool as necessary.
11. Remove rear oil seal retainer.
Remove by insert](/manual-img/5/57392/w960_57392-2338.png)
CYLINDER BLOCK
EM-231
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
10. Remove pilot converter using pilot bushing puller (SST) or suit-
able tool as necessary.
11. Remove rear oil seal retainer.
Remove by inserting screwdriver between main bearing cap and rear oil seal retainer.
CAUTION:
If rear oil seal retainer is removed, replace it with new one.
NOTE:
Regard both rear oil seal and retainer as an assembly.
12. Remove piston and connecting rod assembly as follows:
Before removing piston and connecting rod assembly, check the connecting rod side clearance. Refer
to EM-245, "
CONNECTING ROD SIDE CLEARANCE" .
a. Position crankshaft pin corresponding to connecting rod to be removed onto the bottom dead center.
b. Remove connecting rod bearing cap.
c. Using hammer handle or similar tool, push piston and connect-
ing rod assembly out to the cylinder head side.
CAUTION:
Be careful not to damage the cylinder wall and crankshaft
pin, resulting from an interference of the connecting rod big
end.
13. Remove connecting rod bearings from connecting rod and connecting rod bearing cap.
CAUTION:
Identify installation position, and store them without mixing them up.
14. Remove piston rings form piston.
Before removing piston rings, check the piston ring side clearance. Refer to EM-246, "PISTON RING
SIDE CLEARANCE" .
Use piston ring expander (commercial service tool).
CAUTION:
When removing piston rings, be careful not to damage
piston.
Be careful not to damage piston rings by expanding them
excessively.
15. Remove piston from connecting rod as follows:
PBIC1618E
EMQ0191D
PBIC0087E
Page 2340 of 3502
EM-232
[VQ]
CYLINDER BLOCK
a. Using snap ring pliers, remove snap ring.
b. Heat piston to 60 to 70°C (140 to 158°F) with industrial use drier
or equivalent.
c. Push out piston pin with stick of outer diameter approximately 20
mm (0.79 in).
16. Remove main bearing cap bolts.
NOTE:
Use TORX socket (size E14).
Before loosening main bearing cap bolts, measure crankshaft end play. Refer to EM-245, "CRANK-
SHAFT END PLAY" .
Loosen bolts in reverse order as shown in the figure in several
different steps.
PBIC1638E
PBIC1639E
PBIC0262E
PBIC1800E
Page 2341 of 3502
CYLINDER BLOCK
EM-233
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
17. Remove main bearing beam. (VQ35DE)
18. Remove main bearing caps.
Using main bearing cap bolts, remove main bearing cap while
shaking it back-and-forth.
19. Remove crankshaft.
20. Remove main bearings and thrust bearings from cylinder block and main bearing caps.
CAUTION:
Identify installation positions, and store them without mixing them up.
21. Remove oil jet. (VQ35DE)
ASSEMBLY
NOTE:
Show VQ35DE (with main bearing beam, connecting rod bearing cap is tighten by bolts) as an example unless
the figure includes specification.
1. Fully air-blow engine coolant and engine oil passages in cylinder block, cylinder bore and crankcase to
remove any foreign material.
CAUTION:
Use a goggles to protect your eye.
PBIC2490E
EMQ0195D
Page 2342 of 3502
![NISSAN TEANA 2003 Service Manual EM-234
[VQ]
CYLINDER BLOCK
2. Install each plug to cylinder block as shown in the figure.
NOTE:
Water drain plug at the right bank side for VQ35DE is also used
as a connector of water pipe for oil c NISSAN TEANA 2003 Service Manual EM-234
[VQ]
CYLINDER BLOCK
2. Install each plug to cylinder block as shown in the figure.
NOTE:
Water drain plug at the right bank side for VQ35DE is also used
as a connector of water pipe for oil c](/manual-img/5/57392/w960_57392-2341.png)
EM-234
[VQ]
CYLINDER BLOCK
2. Install each plug to cylinder block as shown in the figure.
NOTE:
Water drain plug at the right bank side for VQ35DE is also used
as a connector of water pipe for oil cooler. Refer to LU-23, "
OIL
COOLER (VQ35DE)" .
Apply sealant to the thread of water drain plug “A”.
Use Anaerobic Liquid Gasket or equivalent.
Apply sealant to the thread of water drain plugs “B” and “D”.
Use Genuine Liquid Gasket or equivalent.
Apply sealant to the thread of plug “C”.
Use Thread Locking Sealant or equivalent.
Replace washers with new one.
Tighten each plug as specified below.
3. Install oil jet. (VQ35DE)
Insert oil jet dowel pin into cylinder block dowel pin hole, and
tighten mounting bolts.
4. Install main bearings and thrust bearings as follows:
a. Remove dust, dirt, and engine oil on bearing mating surfaces of cylinder block and main bearing caps.
PBIC2487E
Part WasherTightening torque
VQ23DE VQ35DE
A Yes 62.0 N·m (6.3 kg-m, 46 ft-lb)
B No 9.8 N·m (1.0 kg-m, 87 in-lb)
C Yes 62.0 N·m (6.3 kg-m, 46 ft-lb)
D No 19.6 N·m (2.0 kg-m, 14 ft-lb) 39.2 N·m (4.0 kg-m, 29 ft-lb)
PBIC2488E
Page 2343 of 3502
![NISSAN TEANA 2003 Service Manual CYLINDER BLOCK
EM-235
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
b. Install thrust bearings to the both sides of the No. 3 journal hous-
ing on cylinder block and main bearing cap.
Install thrust bearings with NISSAN TEANA 2003 Service Manual CYLINDER BLOCK
EM-235
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
b. Install thrust bearings to the both sides of the No. 3 journal hous-
ing on cylinder block and main bearing cap.
Install thrust bearings with](/manual-img/5/57392/w960_57392-2342.png)
CYLINDER BLOCK
EM-235
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM
b. Install thrust bearings to the both sides of the No. 3 journal hous-
ing on cylinder block and main bearing cap.
Install thrust bearings with the oil groove facing crankshaft
arm (outside).
Install thrust bearing with a protrusion on one end on cylinder
block, and thrust bearing with a protrusion at center on main
bearing cap. Align each protrusion with mating notch.
c. Install main bearings paying attention to the direction.
Main bearing with oil hole and groove goes on cylinder block.
The one without them goes on main bearing cap.
Before installing main bearings, apply engine oil to the bear-
ing surface (inside). Do not apply engine oil to the back sur-
face, but thoroughly clean it.
When installing, align main bearing stopper protrusion to cut-
out of cylinder block and main bearing caps.
Ensure the oil holes on cylinder block and those on the corre-
sponding bearing are aligned.
5. Install crankshaft to cylinder block.
While turning crankshaft by hand, check that it turns smoothly.
6. Install main bearing caps.
Main bearing caps are identified by identification mark cast on
them. For installation, face front mark to front side.
NOTE:
Main bearing cap cannot be replaced as a single part, because it
is machined together with cylinder block.
7. Install main bearing beam. (VQ35DE)
Install main bearing beam with front mark facing downward (oil pan side).
Install main bearing beam with front mark facing front of
engine.
8. Inspect outer diameter of main bearing cap bolts. Refer to EM-253, "
MAIN BEARING CAP BOLT OUTER
DIAMETER" .
PBIC0807E
PBIC2489E
SEM456G
PBIC2490E
Page 2344 of 3502
![NISSAN TEANA 2003 Service Manual EM-236
[VQ]
CYLINDER BLOCK
9. Tighten main bearing cap bolts in numerical order as shown in
the figure as follows:
a. Apply new engine oil to threads and seat surfaces of main bear-
ing cap bolts.
b NISSAN TEANA 2003 Service Manual EM-236
[VQ]
CYLINDER BLOCK
9. Tighten main bearing cap bolts in numerical order as shown in
the figure as follows:
a. Apply new engine oil to threads and seat surfaces of main bear-
ing cap bolts.
b](/manual-img/5/57392/w960_57392-2343.png)
EM-236
[VQ]
CYLINDER BLOCK
9. Tighten main bearing cap bolts in numerical order as shown in
the figure as follows:
a. Apply new engine oil to threads and seat surfaces of main bear-
ing cap bolts.
b. Tighten main bearing cap bolts in several different steps.
c. Turn all main bearing cap bolts 90 degrees clockwise. (Angle
tightening)
CAUTION:
Use angle wrench [SST: KV10112100] to check tightening
angle. Do not make judgment by visual inspection.
After installing main bearing cap bolts, make sure that crank-
shaft can be rotated smoothly by hand.
Check crankshaft end play. Refer to EM-245, "CRANKSHAFT
END PLAY" .
10. Inspect outer diameter of connecting rod bolts. Refer to EM-253, "
CONNECTING ROD BOLT OUTER
DIAMETER" .
11. Install piston to connecting rod as follows:
a. Using snap ring pliers, install new snap ring to the groove of piston rear side.
Insert it fully into groove to install.
b. Install piston to connecting rod.
Using industrial use drier or similar tool, heat piston until piston pin can be pushed in by hand without
excess force [approx. 60 to 70°C (140 to 158°F)]. From the front to the rear, insert piston pin into piston
and connecting rod.
Assemble so that the front mark on the piston head and the
cylinder number on connecting rod are positioned as shown in
the figure.
c. Install new snap ring to the groove of the piston front side.
Insert it fully into groove to install.
After installing, make sure that connecting rod moves
smoothly.
12. Using piston ring expander (commercial service tool), install pis-
ton rings.
CAUTION:
When installing piston rings, be careful not to damage
piston.
Be careful not to damage piston rings by expending them
excessively. : 35.3 N·m (3.6 kg-m, 26 ft-lb)
PBIC1800E
PBIC0921E
SEM838F
PBIC0087E
