POWER DOOR LOCK SYSTEM
BL-29
C
D
E
F
G
H
J
K
L
MA
B
BL

Terminals and Reference Value for BCMBIS000W1
*1: with intelligent key*2: without intelligent key
Work FlowBIS000W2
1. Check the symptom and customer's requests.
2. Understand the outline of system. Refer to BL-22, "
System Description" .
3. According to the trouble diagnosis chart by symptom, repair or replace the cause of the malfunction.
Refer to BL-31, "
Trouble Diagnosis Chart by Symptom" .
4. Does power door lock system operate normally?
YES: GO TO 5.
NO: GO TO 3.
5. INSPECTION END
Te r m i -
nalWire
colorItemSignal
Input/
OutputConditionVoltage (V)
(Approx.)
7 LG/R Door unlock sensor signal InputDriver side door
lock knobON (Lock) 5
OFF (Unlock) 0
12 R/LFront door switch
(Passenger side) signalInputFront door
(Passenger side)ON (Open) 0
OFF (Close) Battery voltage
13 R/B Rear door switch RH signal Input Rear door RHON (Open) 0
OFF (Close) Battery voltage
37B/R
*1
BR*2Key switch signal Input KeyInserted Battery voltage
Removed 0
39 L CAN-HInput/
Output——
40 P CAN-LInput/
Output——
42 Y/R Power source (Fuse) Input — Battery voltage
50 VDoor lock actuator
LOCK output signalOutputDoor lock and unlock switch
(Free → Lock)0 → Battery voltage → 0
51 G/YDoor lock actuator
UNLOCK output signalOutputDoor lock and unlock switch
(Free → Unlock)0 → Battery voltage → 0
52 B Ground — — 0
55 W/B Power source (Fusible link) Input — Battery voltage
60 GRDoor lock and unlock switch
LOCK signalInputDoor lock and
unlock switchLock 0
Other than above Battery voltage
61 GR/RDoor lock and unlock switch
UNLOCK signalInputDoor lock and
unlock switchUnlock 0
Other than above Battery voltage
62 SBFront door switch
(Driver side) signalInputFront door
(Driver side)ON (Open) 0
OFF (Close) Battery voltage
63 R/W Rear door switch LH signal Input Rear door LHON (Open) 0
OFF (Close) Battery voltage

BL-152
NATS(NISSAN ANTI-THEFT SYSTEM)

Trouble Diagnosis Symptom ChartBIS000YL
*: When NATS detects trouble, the security indicator lights up while electronic key is in the “ON” position.
Security Indicator InspectionBIS000YM
*: CONSULT-II self-diagnostic results display screen “no malfunction is detected”.SYMPTOMDisplayed “SELF-DIAG
RESULTS” on CON-
SULT-II screen.DIAGNOSTIC PROCE-
DURESYSTEM (Malfunctioning part or mode)

Security indicator
lighting up*

Engine hard to startCHAIN OF ECM-IMMU
[P1612]Refer to BL-153, "
Diag-
nostic Procedure 1" .Open circuit in battery voltage line of BCM (NATS
IMMU) circuit
Open circuit in ignition line of BCM circuit
Open circuit in ground line of BCM circuit
Open or short circuit between BCM and ECM com-
munication line.
ECM
BCM
DIFFERENCE OF KEY
[P1615]Refer to BL-154, "
Diag-
nostic Procedure 2" .Unregistered key
BCM
CHAIN OF IMMU-KEY
[P1614]Refer to BL-157, "
Diag-
nostic Procedure 5" .Open or short circuit between BCM and NATS
antenna amp.
Malfunction of key ID chip
BCM
NATS antenna amp
ID DISCORD, IMM-ECM
[P1611]Refer to BL-155, "
Diag-
nostic Procedure 3" .System initialization has not yet been completed.
ECM
LOCK MODE
[P1610]Refer to BL-156, "
Diag-
nostic Procedure 4" .LOCK MODE

MIL staying ON

Security indicator
lighting up*DON'T ERASE
BEFORE CHECKING
ENG DIAGRefer to BL-151, "WORK FLOW" .Engine trouble data and NATS trouble data have
been detected in ECM
SYMPTOMSYSTEM
(Malfunctioning part or mode)DIAGNOSTIC PROCEDURE
Security indicator does not operate*Security indicator
Refer to BL-159, "
Diagnostic
Procedure 6" . Open circuit between Fuse and BCM (NATS
IMMU)
Continuation of initialization mode
BCM (NATS IMMU)

NATS(NISSAN ANTI-THEFT SYSTEM)
BL-153
C
D
E
F
G
H
J
K
L
MA
B
BL

Diagnostic Procedure 1BIS000YN
Self-diagnostic results:
“CHAIN OF ECM-IMMU” display on CONSULT-II screen
First perform the “SELF-DIAG RESULTS” in “BCM” with CONSULT-II, then perform the trouble diagno-
sis of malfunction system indicated “SELF-DIAG RESULTS” of “BCM”. Refer to BCS-14, "
CAN Com-
munication Inspection Using CONSULT-II (Self-Diagnosis)" .
1. CHECK SELF-DIAGNOSTIC RESULTS
Check SELF-DIAGNOSTIC RESULTS “CHAIN OF ECM-IMMU” dis-
played on the screen?
Is CONSULT-II screen displayed as above?
YES >> GO TO 2.
NO >> GO TO BL-152, "
Trouble Diagnosis Symptom Chart" .
2. CHECK POWER SUPPLY CIRCUIT FOR BCM
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check voltage between BCM connector M4 terminal 42 (Y/R),
55 (W/B) and ground.
OK or NG
OK >> GO TO 3.
NG >> Check the following.

50A fusible link [Letter M , located in fuse block (J/B)]

15A fuse [No.17, located in fuse block (J/B)]

Harness for open or short between fusible link or fuse
and BCM.
3. CHECK IGNITION SWITCH ON SIGNAL
1. Turn ignition switch ON.
2. Check voltage between BCM connector M3 terminal 38 (R) and
ground.
OK or NG
OK >> GO TO 4.
NG >> Check the following.

10A fuse [No.1, located in fuse block (J/B)]

Harness for open or short between fuse and BCM.
PIIA1260E
42 (Y/R) – Ground : Battery voltage
55 (W/B) – Ground : Battery voltage
PIIA6143E
38 (R) – Ground : Battery voltage
PIIA6144E

COMBINATION METERS
DI-17
C
D
E
F
G
H
I
J
L
MA
B
DI

SYMPTOM CHART 1
SYMPTOM CHART 2
Symptom Check item
Indication is inaccurate for the speedometer and odo/trip meter. Refer to DI-20, "
Vehicle Speed Signal Inspection" .
Tachometer indication is inaccurate. Refer to DI-21, "
Engine Speed Signal Inspection" .
Water temperature gauge indication is inaccurate. Refer to DI-21, "
Engine Coolant Temperature Signal Inspection" .
Fuel gauge indication is inaccurate.
Refer to DI-22, "
Fuel Level Sensor Signal Inspection" .
Low-fuel warning lamp indication is inaccurate.
A/T indicator does not illuminate. Refer to DI-48, "
A/T INDICATOR" .
CVT indicator does not illuminate Refer to DI-52, "
CVT INDICATOR"
Illumination control does not operate. Replace combination meter.
Displayed item [Code] Inspection contents Check item
CAN COMM CIRC [U1000] Inspect the CAN communication.Refer to DI-32, "
DTC [U1000] CAN Communication Circuit" .
CAUTION:
Even when there is no malfunction on CAN communica-
tion system, malfunction may be misinterpreted when bat-
tery has low voltage (when maintaining 7-8V for about 2
seconds) or 10A fuse [No. 19, located in the fuse block (J/
B)] is disconnected.
METER COMM CIRC [B2202]Inspect the communication line
between the combination meter
and the unified meter and A/C
amp.Refer to DI-32, "
DTC [B2202] Meter Communication Circuit" .
VEHICLE SPEED CIRC [B2205]Inspect the vehicle speed input
signal.Refer to DI-34, "
DTC [B2205] Vehicle Speed Circuit" .
CAUTION:
Even when there is no malfunction on speed signal sys-
tem, malfunction may be misinterpreted when battery has
low voltage (when maintaining 7-8V for about 2 seconds).

DI-66
WARNING CHIME

Display Item List
ACTIVE TEST
Operation procedure
1. Touch “BUZZER” on “SELECT TEST ITEM” screen.
2. Touch “ACTIVE TEST” on “SELECT DIAG MODE” screen.
3. Touch the item to be tested, and check the operation.
4. During the operation check, touching “OFF” deactivates the operation.
Display Item LIst
Trouble DiagnosisBKS001T7
HOW TO PROCEED WITH TROUBLE DIAGNOSIS
1. Confirm the malfunction symptom or customer complaint.
2. Understand the outline of system. Refer to DI-56, "
System Description" .
3. Perform preliminary check. Refer to DI-66, "
PRELIMINARY CHECK" .
4. Select “METER A/C AMP” on CONSULT-II, and then perform self-diagnosis of unified meter and A/C
amp. Refer to DI-29, "
CONSULT-II Function (METER A/C AMP)" . When no malfunction detected, go to
next step 5. When malfunction detected, go to DI-17, "
SYMPTOM CHART 2" in “COMBINATION
METER”.
5. Check symptom and repair or replace the cause of malfunction.
6. Does the warning chime operate normally? If so, GO TO 7. If not, GO TO 5.
7. INSPECTION END
PRELIMINARY CHECK
1. CHECK FUSE AND FUSIBLE LINK
Check BCM fuses and fusible link for blown-out.
OK or NG
OK >> GO TO 2.
NG >> If fuse or fusible link is blown, be sure to eliminate cause of malfunction before installing new fuse
or fusible link. Refer to PG-3, "
POWER SUPPLY ROUTING CIRCUIT" .
Monitor item [Unit] ALL SIGNALSSELECTION
FROM MENUDescription
IGN ON SW [ON/OFF] X X Indicates [ON/OFF] condition of ignition switch.
KEY ON SW [ON/OFF] X X Indicates [ON/OFF] condition of key switch.
DOOR SW-DR [ON/OFF] X X Indicates [ON/OFF] condition of front door switch (driver side).
LIGHT SW 1ST [ON/OFF] X X Indicates [ON/OFF] condition of lighting switch.
FR FOG SW [ON/OFF] X X Indicates [ON/OFF] condition of front fog lamp switch.
Test item Malfunction is detected when···
IGN KEY WARN ALMThis test is able to check key warning chime operation. Key warning chime sounds for 2 seconds
after touching “ON” on CONSULT-ll screen.
LIGHT WARN ALMThis test is able to check light warning chime operation. Light warning chime sounds for 2 seconds
after touching “ON” on CONSULT-ll screen.
Unit Power source Fuse and fusible link No.
BCMBatteryM
17
Ignition switch ON or START 1

GI-18
HOW TO USE THIS MANUAL

14 Wire color

This shows a code for the color of the wire.
B = Black
W = White
R = Red
G = Green
L = Blue
Y = Yellow
LG = Light GreenBR = Brown
OR or O = Orange
P = Pink
PU or V (Violet) = Purple
GY or GR = Gray
SB = Sky Blue
CH = Dark Brown
DG = Dark Green
When the wire color is striped, the base color is given first, followed by the stripe color as shown
below:
Example: L/W = Blue with White Stripe
15 Option description

This shows a description of the option abbreviation used on the page.
16 Switch

This shows that continuity exists between terminals 1 and 2 when the switch is in the A posi-
tion. Continuity exists between terminals 1 and 3 when the switch is in the B position.
17 Assembly parts

Connector terminal in component shows that it is a harness incorporated assembly.
18 Cell code

This identifies each page of the wiring diagram by section, system and wiring diagram page
number.
19 Current flow arrow

Arrow indicates electric current flow, especially where the direction of standard flow (vertically
downward or horizontally from left to right) is difficult to follow.

A double arrow “ ” shows that current can flow in either direction depending on cir-
cuit operation.
20 System branch

This shows that the system branches to another system identified by cell code (section and
system).
21 Page crossing

This arrow shows that the circuit continues to another page identified by cell code.

The C will match with the C on another page within the system other than the next or preced-
ing pages.
22 Shielded line

The line enclosed by broken line circle shows shield wire.
23Component box in
wave line

This shows that another part of the component is also shown on another page (indicated by
wave line) within the system.
24 Component name

This shows the name of a component.
25 Connector number

This shows the connector number.

The letter shows which harness the connector is located in.

Example: M : main harness. For detail and to locate the connector, refer to PG section "Main
Harness", “Harness Layout”. A coordinate grid is included for complex harnesses to aid in
locating connectors.
26 Ground (GND)

The line spliced and grounded under wire color shows that ground line is spliced at the
grounded connector.
27 Ground (GND)

This shows the ground connection. For detailed ground distribution information, refer to
"Ground Distribution" in PG section.
28 Connector views

This area shows the connector faces of the components in the wiring diagram on the page.
29 Common component

Connectors enclosed in broken line show that these connectors belong to the same compo-
nent.
30 Connector color

This shows a code for the color of the connector. For code meaning, refer to wire color codes,
Number 14 of this chart.
31Fusible link and fuse
box

This shows the arrangement of fusible link(s) and fuse(s), used for connector views of
"POWER SUPPLY ROUTING" in PG section.
The open square shows current flow in, and the shaded square shows current flow out.
32 Reference area

This shows that more information on the Super Multiple Junction (SMJ) and Joint Connectors
(J/C) exists on the PG section. Refer to "Reference Area" for details. Num-
berItem Description

GW-62
REAR WINDOW DEFOGGER

Terminal and Reference Value for BCMBIS00102
Terminal and Reference Value for IPDM E/RBIS00103
Work FlowBIS00104
1. Check the symptom and customer's requests.
2. Understand the outline of system. Refer to GW-54, "
System Description" .
3. According to the trouble diagnosis chart, repair or replace the cause of the malfunction.
Refer to GW-63, "
Trouble Diagnoses Symptom Chart" .
4. Does rear window defogger operate normally?
YES: GO TO 5.
NO: GO TO 3.
5. INSPECTION END
Te r m i -
nalWire
colorItemSignal
Input/
OutputConditionVoltage [V]
(Approx.)
9GR/LRear window defogger
switch signalInputWhen rear window defogger switch is pressed. 0
When rear window defogger switch is OFF. 5
38 R Ignition switch ON or START Input Ignition switch (ON or START position) Battery voltage
39 L CAN− HInput/
Output——
40 P CAN− LInput/
Output——
42 Y/R Power source (Fuse) Input — Battery voltage
52 B Ground — — 0
55 W/B Power source (Fusible link) Input — Battery voltage
Te r m i -
nalWire
colorItemSignal
Input/
OutputConditionVoltage [V]
(Approx.)
6 L Battery power supply Output — Battery voltage
38 B Ground (Power) Output — 0
48 L CAN− HInput/
Output——
49 P CAN− LInput/
Output——
52 G/RRear window defogger relay
control signalInputWhen rear window defogger switch is ON. 0
When rear window defogger switch is OFF. Battery voltage
60 B Ground (Signal) — — 0

IDX-4
ALPHABETICAL INDEX
Electric throttle control actuator (VQ23DE and VQ35DE)
EM-137
Electrical load signal circuit ................ EC-280, EC-670
Electrical unit ..................................................... PG-74
Electrical units location ...................................... PG-67
Electronic ignition (EI) system ............. EC-23, EC-360
EMNT - Wiring diagram ................................... EC-673
ENG SS - Wiring diagram ................................ AT-117
Engine control circuit diagram ............. EC-70, EC-413
Engine control component parts location .......... EC-64,
EC-406
Engine control module (ECM) ............ EC-190, EC-538
Engine control system diagram and chart ........ EC-20,
EC-357
Engine coolant temperature sensor (ECTS) ... EC-131,
EC-474
Engine coolant(QR20DE) ................................. CO-10
Engine coolant(VQ23DE and VQ35DE) ........... CO-34
Engine fail-safe system ........................ EC-59, EC-401
Engine mounting control (Front) ...................... EC-672
Engine oil filter replacement(QR20DE) ............. MA-21
Engine oil filter replacement(VQ23DE and VQ35DE) ...
MA-31
Engine oil precautions .......................................... GI-8
Engine oil replacement(QR20DE) .................... MA-20
Engine oil replacementVQ23DE and VQ35DE . MA-30
Engine oil(QR20DE) ............................................ LU-7
Engine oil(VQ23DE and VQ35DE) .................... LU-19
Engine removal(QR20DE) ................................ EM-77
Engine removal(VQ23DE and VQ35DE) ........ EM-223
Engine trouble diagnoses ................................ EC-394
ETC1 - Wiring diagram ...................... EC-201, EC-556
ETC2 - Wiring diagram ...................... EC-209, EC-564
ETC3 - Wiring diagram ...................... EC-214, EC-569
EVAP canister ...................................... EC-29, EC-369
EVAP canister purge volume control solenoid valve ....
EC-282
, EC-677
EVAP vapor lines inspection ............................. MA-23
EVAP vapor lines inspection(VQ23DE and VQ35DE) ..
MA-34
EVAP vapor lines inspectionVQ23DE and VQ35DE ....
MA-33
Evaporative emission (EVAP) system . EC-27, EC-366
Evaporator ..................................................... ATC-144
Exhaust manifold(QR20DE) ............................. EM-23
Exhaust manifold(VQ23DE and VQ35DE) ..... EM-140
Exhaust system ................................................... EX-2
Exhaust system inspection ..................... EX-2, MA-35
Expansion valve ............................................. ATC-145
F
F/FOG - Wiring diagram ................................... LT-129
F/LID - Wiring diagram ....................................... BL-45
F/PUMP - Wiring diagram .................. EC-296, EC-691
Floor trim ............................................................. EI-52
Flow charts ......................................................... GI-24
Fluid temparature sensor (CVT) ...................... CVT-69
Fluids ................................................................ MA-14
Fluorescent leak detector ............................. ATC-146
Fog lamp, front ................................................. LT-126
Freeze frame data .............................. EC-35, EC-376
FRO2 - Wiring diagram ..................... EC-302, EC-309
FRO2B1 - Wiring diagram ................ EC-697, EC-707
FRO2B2 - Wiring diagram ................ EC-699, EC-709
Front bumper ...................................................... EI-14
Front door ............................. BL-119, BL-123, GW-46
Front fog lamp .................................................. LT-126
Front passenger air bag .................................. SRS-39
Front seat belt ...................................................... SB-3
Front seat belt pre-tensioner ..... SB-2, SRS-3, SRS-46
Front side air bag ............................................ SRS-40
Front washer ...................................................... WW-4
Front wiper ......................................................... WW-4
FTS - Wiring diagram ...................................... CVT-70
Fuel cut control (at no load high engine speed) EC-24,
EC-361
Fuel gauge ............................................................ DI-4
Fuel injector and fuel tube(QR20DE) ................ EM-34
Fuel injector and fuel tube(VQ23DE and VQ35DE) ......
EM-155
Fuel lid opener, electric ...................................... BL-44
Fuel line inspection .............................................. FL-3
Fuel line inspection(QR20DE) .......................... MA-20
Fuel line inspectionVQ23DE and VQ35DE ....... MA-30
Fuel pressure check ........................... EC-49, EC-392
Fuel pressure release ......................... EC-49, EC-392
Fuel pump ......................................... EC-295, EC-690
Fuel pump and gauge .......................................... FL-4
Fuel system ......................................................... FL-3
Fuel tank .............................................................. FL-8
Fuel tank vacuum relief valve ............. EC-29, EC-369
Fuse .................................................................. PG-16
Fuse and fusible link box .................................. PG-80
Fusible link ........................................................ PG-16
G
Gauges ................................................................. DI-4
Glass ...................................... GW-11, GW-46, GW-50
Grease .............................................................. MA-14
Grille - See Exterior ............................................ EI-20
Ground distribution ........................................... PG-29
H
H/AIM - Wiring diagram ................................... LT-122
H/LAMP - Wiring diagram .................................. LT-42
Harness connector ............................................ PG-71
Harness layout .................................................. PG-42
Hazard warning lamp ....................................... LT-152
Headlamp aiming control ...................... LT-99, LT-122
Headlamp leveler - See Headlamp aiming control ........
LT-122
Headlining - See Roof trim .................................. EI-54
Heated oxygen sensor 1 ..... EC-143, EC-150, EC-301
Heated oxygen sensor 1 (bank 1) .... EC-486, EC-496,
EC-696
