Page 777 of 3502

NISSAN TEANA 2003 Service Manual DOOR BL-119 C D E F G H J K L MA B BL DOORPFP:80100 Fitting AdjustmentBIS000XR FRONT DOOR Longitudinal Clearance and Surface Height Adjustment at Front End 1. Remove the fender protector. Refer toEI

Page 778 of 3502

NISSAN TEANA 2003 Service Manual BL-120 DOOR STRIKER ADJUSTMENT Adjust the striker so that it becomes parallel with the lock insertion direction. Removal and Installation of Front DoorBIS000XS CAUTION: When removing and installing

Page 779 of 3502

NISSAN TEANA 2003 Service Manual DOOR BL-121 C D E F G H J K L MA B BL Operate with two workers, because of its heavy weight. Check the hinge rotating part for poor lubrication. If necessary, apply “body grease”. After insta

Page 780 of 3502

NISSAN TEANA 2003 Service Manual BL-122 DOOR INSTALLATION Install in the reverse order of removal.

Page 781 of 3502

NISSAN TEANA 2003 Service Manual FRONT DOOR LOCK BL-123 C D E F G H J K L MA B BL FRONT DOOR LOCKPFP:80502 Component StructureBIS000XV Removal and Installation BIS000XW REMOVAL 1. Remove the front door finisher. Refer to EI-35, "DO

Page 782 of 3502

NISSAN TEANA 2003 Service Manual BL-124 FRONT DOOR LOCK 3. Remove the front door glass and front door module assembly. Refer to GW-46, "FRONT DOOR GLASS AND REGULATOR" . 4. Remove key cylinder connecting rod (key cylinder side). (D

Page 783 of 3502

NISSAN TEANA 2003 Service Manual FRONT DOOR LOCK BL-125 C D E F G H J K L MA B BL 11. Remove the TORX bolt (T30) of the outside handle bracket. 12. While pulling outside handle bracket, slide toward front of vehi- cle to remove out

Page 784 of 3502

NISSAN TEANA 2003 Service Manual BL-126 FRONT DOOR LOCK INSTALLATION Note the following, and install in the reverse order of removal. CAUTION: Install each rod by rotating the rod holder until it engages with a tactile feel. Befo
