Page 1225 of 3502
COMBINATION METERS
DI-19
C
D
E
F
G
H
I
J
L
MA
B
DI
3. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect combination meter connector and unified meter and A/C amp. connector.
3. Check continuity between combination meter harness connector
M70 terminals 10, 11, 12 and ground.
4. Check continuity between unified meter and A/C amp. harness
connector M42 terminal 29, 30 and ground.
OK or NG
OK >> INSPECTION END
NG >> Repair harness or connector.10 – Ground
: Continuity should exist. 11 – Ground
12 – Ground
SKIA8715E
29 – Ground
: Continuity should exist.
30 – Ground
SKIA5202E
Page 1226 of 3502

DI-20
COMBINATION METERS
Vehicle Speed Signal InspectionBKS001S8
1. CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) SELF-DIAGNOSIS
Perform the ABS actuator and electric unit (control unit) self-diagnosis. Refer to BRC-57, "
CONSULT-II Func-
tions" (with VDC system) or BRC-17, "CONSULT-II Functions (ABS)" (without VDC system).
Self
-diagnostic results content
No malfunction detected>>GO TO 2.
Malfunction detected>>Check applicable parts, and repair or replace corresponding parts.
2. CHECK UNIFIED METER AND A/C AMP. OUTPUT SIGNAL
1. Start engine and drive vehicle at approximately 40 km/h (25 MPH).
2. Check voltage signal between unified meter and A/C amp. har-
ness connector M42 terminal 26 and ground with simple oscillo-
scope of CONSULT-II.
OK or NG
OK >> GO TO 3.
NG >>
If monitor indicates “0V” constantly, repair or replace malfunctioning parts after checking each
unit inputting vehicle speed signal (8 pulse), harness and connector between each unit and uni-
fied meter and A/C amp.
If monitor indicates “5V” or “12V” constantly, replace unified meter and A/C amp. Refer to DI-34,
"Removal and Installation of Unified Meter and A/C Amp." .
3. CHECK CONTINUITY BETWEEN COMBINATION METER AND UNIFIED METER AND A/C AMP.
1. Turn ignition switch OFF.
2. Disconnect combination meter connector and unified meter and A/C amp. connector.
3. Check continuity between combination meter harness connector
M70 terminal 20 and unified meter and A/C amp. harness con-
nector M42 terminal 26.
OK or NG
OK >> Replace combination meter.
NG >> Repair harness or connector.26 – Ground:NOTE:
Maximum voltage may be
12V due to specifications
(connected units).
SKIB0338E
SKIA6649J
20 – 26 : Continuity should exist.
SKIB0339E
Page 1227 of 3502

COMBINATION METERS
DI-21
C
D
E
F
G
H
I
J
L
MA
B
DI
Engine Speed Signal Inspection BKS001S9
1. CHECK UNIFIED METER AND A/C AMP. OUTPUT SIGNAL
1. Start an engine and select “METER A/C AMP” on CONSULT-II.
2. Using “TACHO METER” on “DATA MONITOR”, compare the
value of “DATA MONITOR” with tachometer pointer of combina-
tion meter.
OK or NG
OK >> GO TO 2.
NG >> Replace combination meter.
2. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Select “ENGINE” on CONSULT-II.
2. Using “ENG SPEED” on “DATA MONITOR”, print out the CON-
SULT-II screen when the engine is idling.
3. Select “METER A/C AMP” on CONSULT-II.
4. Using “TACHO METER” on “DATA MONITOR”, compare the
value of “DATA MONITOR” of the idling speed with that of the
“ENG SPEED”.
OK or NG
OK >> Perform ECM self-diagnosis. Refer to EC-425, "CON-
SULT-II Function (ENGINE)" . Check applicable parts,
and repair or replace corresponding parts.
NG >> Replace unified meter and A/C amp. Refer to DI-34,
"Removal and Installation of Unified Meter and A/C Amp." .
Engine Coolant Temperature Signal InspectionBKS001SA
1. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Start engine and select “METER A/C AMP” on CONSULT-II.
2. Using “W TEMP METER” on “DATA MONITOR”, compare the
value of “DATA MONITOR” with low water temperature indicator
lamp and high water temperature warning lamp of combination
meter.
OK or NG
OK >> GO TO 2.
NG >> Replace combination meter.
PKIA2090E
SKIA4367E
Low water temperature indicator lamp
and high water temperature warning
lamp conditionsReference value of data monitor °C (°F)
High water temperature warning lamp
turns on. (Red)Approx. more than 114 (237)
Both turn off. Approx. 55 - 108 (131 - 226)
Low water temperature indicator lamp
turns on. (Blue)Approx. less than 50 (122)
PKIA2091E
Page 1228 of 3502

DI-22
COMBINATION METERS
2. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Select “ENGINE” on CONSULT-II.
2. Using “COOLAN TEMP/S” on “DATA MONITOR”, print out the
CONSULT-II screen.
3. Select “METER A/C AMP” on CONSULT-II.
4. Using “W TEMP METER” on “DATA MONITOR”, compare the
value of “DATA MONITOR” with that of the “COOLAN TEMP/S”.
OK or NG
OK >> Perform ECM self-diagnosis. Refer to EC-425, "CON-
SULT-II Function (ENGINE)" . Check applicable parts,
and repair or replace corresponding parts
NG >> Replace unified meter and A/C amp. Refer to DI-34,
"Removal and Installation of Unified Meter and A/C
Amp." .
Fuel Level Sensor Signal InspectionBKS001SB
NOTE:
The following symptoms are not malfunction.
Fuel gage
–Depending on vehicle position or driving circumstance, the fuel level in the tank various, and the pointer
may fluctuate.
–If the vehicle is fueled with the ignition switch ON, the pointer will move slowly.
Low-fuel warning lamp
–Depending on vehicle position or driving circumstance, the fuel in the tank flows and the warning lamp ON
timing may change.
1. CHECK UNIFIED METER AND A/C AMP. INPUT SIGNAL
1. Select “METER A/C AMP” on CONSULT-II.
2. Using “FUEL METER” on “DATA MONIOR”, compare the value
of “DATA MONITOR” with fuel gauge pointer of combination
meter.
OK or NG
OK >> GO TO 2.
NG >> Replace combination meter.
2. CHECK FUEL LEVEL SENSOR UNIT
1. Turn ignition switch OFF.
2. Check fuel level sensor unit. Refer to DI-24, "
CHECK FUEL LEVEL SENSOR UNIT" .
OK or NG
OK >> GO TO 3.
NG >> Replace the corresponding parts.
SKIA4368E
Fuel gauge pointer Reference value of data monitor [lit.]
Full Approx. 66
Three quarters Approx. 53
Half Approx. 36
A quarter Approx. 18
Empty Approx. 8
PKIA2088E
Page 1229 of 3502

COMBINATION METERS
DI-23
C
D
E
F
G
H
I
J
L
MA
B
DI
3. CHECK FUEL LEVEL SENSOR SIGNAL CIRCUIT
1. Disconnect unified meter and A/C amp. connector and fuel level sensor unit and fuel pump connector.
2. Check continuity between unified meter and A/C amp. harness
connector M42 terminal 28 and fuel level sensor unit and fuel
pump harness connector B223 terminal 2.
3. Check continuity between unified meter and A/C amp. harness
connector M42 terminal 28 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair harness or connector.
4. CHECK FUEL LEVEL SENSOR GROUND CIRCUIT
1. Check continuity between fuel level sensor unit and fuel pump
harness connector B223 terminal 5 and unified meter and A/C
amp. harness connector M42 terminal 36.
2. Check continuity between fuel level sensor unit and fuel pump
harness connector B223 terminal 5 and ground.
OK or NG
OK >> GO TO 5.
NG >> Repair harness or connector.
5. CHECK INSTALLATION CONDITION
Check fuel level sensor unit and fuel pump installation, and check whether the float arm interferes or binds
with any of the internal components in the fuel tank.
OK or NG
OK >> Replace unified meter and A/C amp. Refer to DI-34, "Removal and Installation of Unified Meter
and A/C Amp." .
NG >> Install the fuel level sensor unit and fuel pump properly.
Fuel Gauge Does Not Move to FULL positionBKS001SG
1. QUESTION 1
Does it take a long time for the pointer to move to FULL position?
YES >> GO TO 2.
NO >> GO TO 3.
2. QUESTION 2
Was the vehicle fueled with the ignition switch ON?
YES >> Be sure to fuel the vehicle with the ignition switch OFF. Otherwise, it will take a long time to move
to FULL position because of the characteristic of the fuel gauge.
NO >> GO TO 3.28 – 2 : Continuity should exist.
28 – Ground : Continuity should not exist.
SKIA8723E
5 – 36 : Continuity should exist.
5 – Ground : Continuity should not exist.
SKIB0036E
Page 1230 of 3502

DI-24
COMBINATION METERS
3. QUESTION 3
Is the vehicle parked on an incline?
YES >> Check the fuel level indication with vehicle on a level surface.
NO >> GO TO 4.
4. QUESTION 4
During driving, does the fuel gauge pointer move gradually toward EMPTY position?
YES >> Check the fuel level sensor unit and fuel pump. Refer to DI-24, "CHECK FUEL LEVEL SENSOR
UNIT" .
NO >> The float arm may interfere or bind with any of the components in the fuel tank.
Electrical Components InspectionBKS001SH
CHECK FUEL LEVEL SENSOR UNIT
For removal, refer to FL-4, "FUEL LEVEL SENSOR UNIT, FUEL FILTER AND FUEL PUMP ASSEMBLY" .
Check Fuel Level Sensor Unit and Fuel Pump
Check resistance between terminals 2 and 5.
*1 and *2: When float rod is in contact with stopper.
If the results of check are NG, check the fuel level sensor unit
and fuel pump harness.
Check Fuel Level Sensor Unit and Pump Harness
Check continuity at following terminals.
If the results of check are NG, replace fuel pump assembly. If the
results of check are OK, replace fuel level sensor unit.
Terminal Float position [mm (in)] Resistance value [Ω]
25*1 Empty 38 (1.5) Approx. 80
*2 Full 168 (6.61) Approx. 6
SKIB0776E
Terminal Continuity
2 - Signal terminal
Ye s
5 - Ground terminal
SKIB0083E
Page 1231 of 3502
COMBINATION METERS
DI-25
C
D
E
F
G
H
I
J
L
MA
B
DI
Removal and Installation of Combination MeterBKS001SI
REMOVAL
1. Remove cluster lid A. Refer to IP-11, "Removal and Installation" .
2. Remove screws (3) and remove combination meter.
INSTALLATION
Installation is the reverse order of removal.
Disassembly and Assembly of Combination MeterBKS001SJ
SKIB0867E
SKIB0868E
1. Unified meter control unit assembly 2. Upper housing 3. Front cover
4. Odo/trip meter 5. Screw
SKIA6276J
Page 1232 of 3502
DI-26
COMBINATION METERS
DISASSEMBLY
1. Disengage the tabs (8) to separate front cover.
2. Disconnect odo/trip meter connector.
3. Disengage the tabs (8) to separate upper housing.
4. Remove screws (1) and remove odo/trip meter.
ASSEMBLY
Assembly is the reverse order of disassembly.
SKIB0868E
SKIA7244E
