TROUBLE DIAGNOSIS FOR SYMPTOMS
CVT-171
D
E
F
G
H
I
J
K
L
MA
B
CVT
Cannot Be Changed to Manual ModeBCS001MJ
SYMPTOM:
Does not change to manual mode when manual shift gate is used.
DIAGNOSTIC PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis check. Refer to CVT-47, "
SELF-DIAGNOSTIC RESULT MODE" .
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system. Refer to CVT-47, "Display Items List" .
NO >> GO TO 2.
2. CHECK MANUAL MODE SWITCH
Check manual mode switch circuit. Refer to CVT-113, "
DTC P0826 MANUAL MODE SWITCH CIRCUIT" .
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3. CHECK SYMPTOM
Check again. Refer to CVT-38, "
Cruise Test" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 4.
4. CHECK TCM
1. Check TCM input/output signal. Refer to CVT-40, "
TCM Input/Output Signal Reference Values" .
2. If NG, re-check TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >>INSPECTION END
NG >> Repair or replace damaged parts.
CVT Does Not Shift in Manual ModeBCS001MK
SYMPTOM:
Speed does not change even if the selector lever is put in the manual shift gate position and the selec-
tor lever is operated to + side or to - side.
DIAGNOSTIC PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis check. Refer to CVT-47, "
SELF-DIAGNOSTIC RESULT MODE" .
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system. Refer to CVT-47, "Display Items List" .
NO >> GO TO 2.
2. CHECK MANUAL MODE SWITCH
Check manual mode switch circuit. Refer to CVT-113, "
DTC P0826 MANUAL MODE SWITCH CIRCUIT" .
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
Page 1178 of 3502

CVT-172
TROUBLE DIAGNOSIS FOR SYMPTOMS
3. CHECK CVT POSITION
Check CVT position. Refer to CVT-179, "
Checking of CVT Position"
OK or NG
OK >> GO TO 4.
NG >> Adjust CVT position. Refer to CVT-178, "
Adjustment of CVT Position" .
4. CHECK CVT FLUID LEVEL
Check CVT fluid level. Refer to CVT-13, "
Checking CVT Fluid" .
OK or NG
OK >> GO TO 5.
NG >> Refill CVT fluid.
5. CHECK LINE PRESSURE
Check line pressure at idle. Refer to CVT-33, "
LINE PRESSURE TEST" .
OK or NG
OK >> GO TO 6.
NG >> Check the malfunctioning item. Refer to CVT-34, "
Judgement of Line Pressure Test" .
6. CHECK SYMPTOM
Check again. Refer to CVT-38, "
Cruise Test" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 7.
7. CHECK TCM
1. Check TCM input/output signals. Refer to CVT-40, "
TCM Input/Output Signal Reference Values" .
2. If NG, re-check TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the transaxle assembly. Refer to CVT-193, "Removal and Installation" .
NG >> Repair or replace damaged parts.
Vehicle Does Not Decelerate by Engine BrakeBCS001ML
SYMPTOM:
No engine brake is applied when the gear is shifted from the “M2” to “M1” position.
DIAGNOSTIC PROCEDURE
1. CHECK SELF-DIAGNOSTIC RESULTS
Perform self-diagnosis check. Refer to CVT-47, "
SELF-DIAGNOSTIC RESULT MODE" .
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system. Refer to CVT-47, "Display Items List" .
NO >> GO TO 2.
2. CHECK CVT POSITION
Check CVT position. Refer to CVT-179, "
Checking of CVT Position"
OK or NG
OK >> GO TO 3.
NG >> Adjust CVT position. Refer to CVT-178, "
Adjustment of CVT Position" .
Page 1179 of 3502

TROUBLE DIAGNOSIS FOR SYMPTOMS
CVT-173
D
E
F
G
H
I
J
K
L
MA
B
CVT
3. CHECK CVT FLUID LEVEL
Check CVT fluid level. Refer to CVT-13, "
Checking CVT Fluid" .
OK or NG
OK >> GO TO 4.
NG >> Refill CVT fluid.
4. CHECK LINE PRESSURE
Check line pressure at idle. Refer to CVT-33, "
LINE PRESSURE TEST" .
OK or NG
OK >> GO TO 5.
NG >> Check the malfunctioning item. Refer to CVT-34, "
Judgement of Line Pressure Test" .
5. CHECK MANUAL MODE SWITCH
Check manual mode switch circuit. Refer to CVT-113, "
DTC P0826 MANUAL MODE SWITCH CIRCUIT" .
OK or NG
OK >> GO TO 6.
NG >> Repair or replace damaged parts.
6. CHECK SYMPTOM
Check again. Refer to CVT-38, "
Cruise Test" .
OK or NG
OK >>INSPECTION END
NG >> GO TO 7.
7. CHECK TCM
1. Check TCM input/output signals. Refer to CVT-40, "
TCM Input/Output Signal Reference Values" .
2. If NG, re-check TCM pin terminals for damage or loose connection with harness connector.
OK or NG
OK >> Replace the transaxle assembly. Refer to CVT-193, "Removal and Installation" .
NG >> Repair or replace damaged parts.
Page 1180 of 3502
CVT-174
TRANSMISSION CONTROL MODULE
TRANSMISSION CONTROL MODULEPFP:31036
Removal and InstallationBCS0026K
COMPONENTS
REMOVAL
1. Disconnect the battery cable from the negative terminal.
2. Remove Instrument passenger lower panel. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
3. Disconnect connector (1) and (2).
1. TCM 2. ECM
Refer to GI section make sure icons (symbol marks) in the figure. Refer to GI-10, "
Components" .
SCIA7873E
SCIA7874E
Page 1181 of 3502
TRANSMISSION CONTROL MODULE
CVT-175
D
E
F
G
H
I
J
K
L
MA
B
CVT
4. Disconnect TCM harness connectors (1) and ECM harness
connectors (2).
: nut (2)
5. Remove TCM (1) with ECM (2).
: nut (3)
6. Remove TCM (1) from ECM.
INSTALLATION
Install in the reverse order of removal.
SCIA7875E
SCIA7876E
SCIA7877E
Page 1182 of 3502
CVT-176
SHIFT CONTROL SYSTEM
SHIFT CONTROL SYSTEMPFP:34901
Removal and InstallationBCS001MM
CONTROL DEVICE COMPONENTS
1. Selector lever knob 2. Knob cover 3. Control device assembly
4. A/T console finisher 5. Lock pin
Refer to GI section to make sure icons (symbol marks) in the figure. Refer to GI-10, "
Components" .
SCIA7850E
Page 1183 of 3502
SHIFT CONTROL SYSTEM
CVT-177
D
E
F
G
H
I
J
K
L
MA
B
CVT
CONTROL CABLE COMPONENTS
Refer to the figure below for control cable removal and installation procedure.
REMOVAL
1. Remove knob cover (1) below selector lever downward.
2. Pull lock pin (2) out of selector lever knob (3).
3. Remove selector lever knob (3).
4. Remove A/T console finisher.
Refer to IP-11, "Removal and Installation" .
5. Remove center console assembly.
Refer to IP-11, "Removal and Installation" .
6. Disconnect control cable of control device.
7. Disconnect control device harness connector.
1. Selector lever knob 2. Control device assembly 3. Lock plate
4. Control cable 5. Lock plate 6. Transaxle assembly
7. Bracket 8. Floor
Refer to GI section to make sure icons (symbol marks) in the figure. Refer to GI-10, "
Components" .
SCIA7719E
SCIA7840E
SCIA5963E
Page 1184 of 3502

CVT-178
SHIFT CONTROL SYSTEM
8. Remove control device assembly.
INSTALLATION
Note the following, and install in the reverse order of removal.
The knurled surface of rib should be upward when installing the
control cable to the control device assembly. And insert the con-
trol cable securely.
After installation is completed, adjust and check CVT position.
Refer to CVT-178, "
Adjustment of CVT Position" and CVT-179,
"Checking of CVT Position" .
Adjustment of CVT PositionBCS001MN
1. Place selector lever in “P” position.
2. Loosen control cable nut and place manual lever in “P” position.
CAUTION:
Turn wheels more than 1/4 rotations and apply the park
lock.
3. Hold the control cable at the end. Push and pull it twice or three
times, and then push it with a load of 9.8N (approximately 1 kg,
2.2 lb). Temporarily tighten the lock nut with the control cable
loose.
4. Connect control cable on manual lever.
CAUTION:
No application of a force to the manual lever.
5. Tighten control cable nut.
CAUTION:
Fix the manual lever when tightening.
SCIA5964E
SCIA5990E
: 12.7 N·m (1.3 kg-m, 9 ft-lb)
SCIA2001E
